Service and Maintenance Instructions
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . 2
UNIT ARRANGEMENT AND ACCESS . . . . . . . . . . . . 3
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 3
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SUPPLY FAN (BLOWER) SECTION . . . . . . . . . . . . . . 4
Supply Fan (Direct-Drive) . . . . . . . . . . . . . . . . . . . . . . 4
Staged Air Volume . . . . . . . . . . . . . . . . . . . . . . . . . . 10
COOLING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Condenser Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Recommendation . . . . . . . . . . . . . . . . . . . . . . . . . 10
Evaporator Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Evaporator Coil Metering Devices . . . . . . . . . . . . . . 12
TXV Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Replacing TXV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
PURON (R-410A) REFRIGERANT . . . . . . . . . . . . . . . 15
Refrigerant Charge . . . . . . . . . . . . . . . . . . . . . . . . . . 15
COOLING CHARGING CHARTS . . . . . . . . . . . . . . . . 15
COMPRESSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Replacing Compressor . . . . . . . . . . . . . . . . . . . . . . . 18
COMPRESSOR ROTATION . . . . . . . . . . . . . . . . . . . . 19
Filter Drier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Condenser-Fan Adjustment . . . . . . . . . . . . . . . . . . . 19
Troubleshooting Cooling System . . . . . . . . . . . . . . 20
CONVENIENCE OUTLETS . . . . . . . . . . . . . . . . . . . . 21
Convenience Outlets . . . . . . . . . . . . . . . . . . . . . . . . 21
Installing Weatherproof Cover . . . . . . . . . . . . . . . . . 21
Non-Powered Type . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Unit-Powered Type . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Duty Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Fuse on Powered Type . . . . . . . . . . . . . . . . . . . . . . . 22
ELECTRIC HEATERS . . . . . . . . . . . . . . . . . . . . . . . . 22
Completing Heater Installation . . . . . . . . . . . . . . . . 23
SMOKE DETECTORS . . . . . . . . . . . . . . . . . . . . . . . . 24
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Smoke Detector Sensor . . . . . . . . . . . . . . . . . . . . . . 24
Smoke Detector Locations . . . . . . . . . . . . . . . . . . . . 24
Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
