Pole, Wall, and Pedestal Mounting Kits for Fiber Dome
Terminal and Closure Series FDC/FDTC/FDST 08M & 08S
P/N 78-0013-4546-7
Issue 2
related literature | Search corning.com/opcomm.
INSTRUCTIONS FOR:
POLE MOUNT, WALL MOUNT, BD4,BD5, CHNL MAH1010 PED MOUNT BRKT
FDST/FDT-08-POLE/PED-H
80-6113-3205-9
FDC 08M BD4/5 CHANNEL PED BRACKET
FDC-08M-PED-BRKT
80-6113-8081-9
Click on "Resources/Standard Recommended Procedures."
Standard Recommended Procedure 78-0013-4546-7 | Issue 2 | October 2019 | Page 1 of 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CORNING FDC-08M-PED-BRKT
Summary of Contents for CORNING FDC-08M-PED-BRKT
- Page 1 Pole, Wall, and Pedestal Mounting Kits for Fiber Dome Terminal and Closure Series FDC/FDTC/FDST 08M & 08S P/N 78-0013-4546-7 Issue 2 related literature | Search corning.com/opcomm. Click on “Resources/Standard Recommended Procedures.” INSTRUCTIONS FOR: POLE MOUNT, WALL MOUNT, BD4,BD5, CHNL MAH1010 PED MOUNT BRKT...
- Page 2 G. Lanyard H. Instruction Manual 78-0013-4546-7-A (not shown) Note: Visually inspect all components. If any component is missing or appears damaged, do not install. Call Corning Customer Care at 800-743-2675 for a replacement product. 3.0 EMERSON BD4 AND BD5 PEDESTAL INSTALLATION USING FIBER DOME TERMINAL AND CLOSURE MOUNTING KIT FDC-08M-PED-BRKT 3.1 Remove the pedestal cover.
- Page 3 3.4 Secure cable ends in pedestal base. 4.0 CHANNEL MH1010 PEDESTAL INSTALLATION USING FIBER DOME TERMINAL AND CLOSURE MOUNTING KIT FDC-08M-PED-BRKT 4.1 Remove pedestal cover. Remove pedestal components that may interfere with installation. Determine the location of the terminal and install the carriage bolt with the head on the outside of the mounting frame. The bolt can be secured using the plastic screw retainer washer.
- Page 4 4.2 Refer to sections 3.2 and 3.3 for installation of closure/ terminal in mounting bracket. Tighten nuts on both clamp brackets to 35 ± 5 in.-lbs. 5.0 POLE AND WALL MOUNTING INSTALLATION USING FIBER DOME TERMINAL AND CLOSURE KIT FDST/FDT-08-POLE/PED-HB 5.1 Use two ¼ inch diameter (10 mm) bolts (not supplied) to mount the closure/terminal to a wall or wood pole.
- Page 5 5.3 Mount the long tie wrap around the dome and through the loop on one end of the lanyard. Position the cable tie at the TOP of the dome and fully tighten. Push the cable tie down near the latch on the dome for a tight fit. Standard Recommended Procedure 78-0013-4546-7 | Issue 2 | October 2019 | Page 5 of 8...
- Page 6 NOTES: Standard Recommended Procedure 78-0013-4546-7 | Issue 2 | October 2019 | Page 6 of 8...
- Page 7 NOTES: Standard Recommended Procedure 78-0013-4546-7 | Issue 2 | October 2019 | Page 7 of 8...
- Page 8 800-743-2675 • FAX: 828-325-5060 • International: +1-828-901-5000 • www.corning.com/opcomm Corning Optical Communications reserves the right to improve, enhance, and modify the features and specifications of Corning Optical Communications products without prior notification. A complete listing of the trademarks of Corning Optical Communications is available at www.corning.com/opcomm/trademarks. All other trademarks are the properties of their respective owners.
