003-794
Pretium EDGE 1U and 4U Housings
1.
General
This document describes installation of the Pretium EDGE 1U and 4U housings onto an
overhead wire tray using mounting kit EDGE-BKT-WT-2RU and EDGE-BKT-WT-4RU
respectively or into a ladder rack using mounting kit EDGE-BKT-LR-2RU or EDGE-BKT-LR-4RU.
2.
Carton Contents
Use the part numbers below to determine the carton contents for your installation.
2.1
Wire Tray Mounting Kit 2U (EDGE-BKT-WT-2RU)
•
(1) Bottom Plate
•
Hardware kit containing:
•
(2) Waterfall 01U
•
(2) Omega bracket, Horizontal position
•
(2) Omega bracket, Vertical position
•
(8) 10-32 x .5 stainless-steel screw
•
(8) Split lock stainless-steel washer
•
(4) 4-40 x .125 stainless-steel screw
•
(2) 10-32 x .375 stainless-steel screw
2.2
Wire Tray Mounting Kit 4U (EDGE-BKT-WT-4RU)
•
(1) Bottom Plate and bar preinstalled
•
Hardware kit containing:
•
(2) Omega bracket, Horizontal position
•
(2) Omega bracket, Vertical position
•
(8) 10-32 x .5 stainless-steel screw
•
(8) Split lock stainless-steel washer
•
(2) 10-32 x .375 stainless-steel screw
2.3
Ladder Rack Mounting Kit (EDGE-BKT-LR-2RU)
•
(1) Bottom Plate / (2) Omega brackets preinstalled
•
Hardware kit containing:
•
(2) Waterfall 01U
•
(4) 4-40 x .125 stainless-steel screw
•
(2) 10-32 x .375 stainless-steel screw
2.4
Ladder Rack Mounting Kit 4U (EDGE-BKT-LR-4RU)
•
Bottom Plate / (2) Omega brackets and bar preinstalled
•
Hardware kit containing:
•
(2) 10-32 x .375 stainless-steel screw
STANDARD RECOMMENDED PROCEDURE 003-809 | ISSUE 4 | DECEMBER 2011 | PAGE 1 OF 4
Pretium EDGE™ Rackless
Mounting Kits
p/n 003-809, Issue 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CORNING Pretium EDGE
Summary of Contents for CORNING Pretium EDGE
- Page 1 Pretium EDGE 1U and 4U Housings General This document describes installation of the Pretium EDGE 1U and 4U housings onto an overhead wire tray using mounting kit EDGE-BKT-WT-2RU and EDGE-BKT-WT-4RU respectively or into a ladder rack using mounting kit EDGE-BKT-LR-2RU or EDGE-BKT-LR-4RU.
- Page 2 Tools and Materials Required • Phillips-head screwdriver Rackless Wire Tray Mounting Kit 2U or 4U Z axis bracket X axis bracket X axis Z axis KPA-2557 Figure 1 — Install Rackless Wire Tray Mounting Kit (2U or 4U) (2U kit shown) NOTE: This installation requires two people.
- Page 3 KPA-2558 ~4.5 inch ~4.5 inch Figure 2 — Install Housing(s) into Mounting Kit Step 6: Once the kit is secured in position, install the EDGE-01U or EDGE-04U housing, as applicable, or any other device that has the ability to be installed into a 19-inch rack space, by securing the mounting brackets on each side into the mounting holes on front of the kit.
- Page 4 Corning Cable Systems reserves the right to improve, enhance, and modify the features and specifications of Corning Cable Systems’ products without prior notification. Pretium EDGE is a trademark of Corning Cable Systems Brands, Inc.All other trademarks are the properties of their respective owners. Corning Cable Systems is ISO 9001 certified.
