Summary of Contents for My Geko Gear ORBIT 1400
- Page 1 DASH CAMERA ORBIT 1400 Quick User Manual...
- Page 2 Disclaimer 1. Please follow the set-up and usage instructions in the print material that came with this Dashboard Camera (dash cam) product. 2. You should not set/install this dash cam at a place that would obstruct or reduce a driver’s view;...
-
Page 3: About Micro Sd Card
Attention Please! 【About Usage】 1. The embedded super capacitor can help to save your recorded file even if the power is off. 2. To avoid breaking down the file recorded, don’t eject the micro SD card immediately after powering off. 3. -
Page 4: Product Overview
Please read this manual carefully before using. Product Overview This product is a high-definition digital display with up to four cameras , with high- quality digital audio Package Contents Orbit 1400 Monitor Cameras x4 Bracket 32GB Micro SD Card 5m power cables x3... -
Page 5: Product Features
Product Features 4 cameras, 142 degree high resolution wide angle lens DDR3 512M Memory 10.1 inch IPS screen Built-in Microphone Built-in Speaker Support Micro SD card up to 128GB SOS File Locking Function Loop Recording, Time and Date Stamp 50Hz/60Hz Refresh Rate Supports PC USB Connection Dash Cam Monitor Button Layout 1. - Page 6 3. Affix the mount onto the inside of the cabin with a clear view of the windshield. 4. Connect the power cord to one of the power connectors of the Orbit 1400 5. Carefully manage and run your wiring along the window trim.
-
Page 7: Trigger Lines
Wiring 1. Please wire the cables into the corresponding fuse box interface Yellow – 12V-24V (battery) Red – Ignition Black - ground. Trigger Lines The corresponding 12 – 36V trigger signal source such as reversing, turn signal. 1. Channel 1 – Front 2. - Page 8 1. To enter menu, press the Menu button or the Home button on the screen. 2. Use the Up and Down arrow buttons to navigate or press the option you desire on the screen. 3. To exit the menu, short press the menu button again to exit.
-
Page 9: Recording Mode
13. Screen Saver • Turn off/1 minute/5 minutes 14. Language • English/French/Chinese 15. Storage Info • 2 minutes/3 minutes/5 minutes 16. Format • Format/Cancel (Formats the SD Card) 17. Factory Reset • Confirm/Cancel 18. Firmware Version • Displays current firmware version 19. -
Page 10: Screen Layout Options
Screen Layout Options • Short press the Up arrow button to switch the 4-screen interface • Short press the up arrow button to switch to the next display mode • Press the screen layout button on the screen (5 button from the left) to change the layout Specifications Screen... -
Page 11: Common Troubleshooting Issues
Common Troubleshooting Issues 1. Camera is not recording • Format the TF card through the machine. • Format the SD card in a PC/Mac to the FAT32 file system. • Replace with a new memory card. 2. Memory error or file error •... -
Page 12: Firmware Updates
card, to ensure the camera is functioning and recordings are captured properly. On each use, you should verify that the camera assembly, indicator lights, and sounds are functioning. If there are any signs of non- operation or malfunction, immediately seek a replacement product or check if it is covered by any applicable warranty.
