Device Maintenance; Menu Structure - Light4Me HYPER BEAM User Manual

Always transport the product by holding the brackets. Do not transport the product by hold-
In the event of a malfunction, disconnect the device from the power supply immediately!

Device maintenance

1. The device may only be used by qualified personnel, damage caused by improper use or attempted
repair is not covered by the warranty. There are no service parts inside the packaging, repairs may
only be carried out by authorized service center.
2. Do not allow optical components to come into contact with oil, grease or any similar liquid. Optical
components should not come into direct contact with the skin!
3. Regular cleaning allows of long term use and maintains proper brightness. Use a soft cloth to clean
the optical system. Also clean the fans and air vents.

Menu structure

Main menu option
Addr
CHnd
SLnd
Pan
Tilt
SEne
LED
DISP
Ver
Faet
Fine-tune menu
When the device is hanged, attach the safety rope to a suitable mounting point.
Device operation mode selection – modes: DMX, auto, sound, master-
Microphone sensitivity adjustment in sound mode – values: 0-100
Display position – values: YES (default), NO (reversed)
Starting the menu for detailed control of Pan and Tilt movements –
press and hold the MENU button for 5 sec; after entering this menu,
there will be two values to choose from - PAN or TILT with sub-values
in each: 0-127 (detailed default moves), -1-127 (detailed inverted
ing body.
Option function
DMX address setting – values: A001-A512
13-channel DMX mode – value: 13CH
slave
Default Pan movements – value: YES
Reversed Pan movements – value: NO
Default Tilt movements – value: YES
Reversed Tilt movements – value: NO
Display backlighting – values: YES, NO
Device software version (V100)
Reset to factory settings – values: YES, NO
moves)
8
LIGHT4ME HYPER BEAM
Instrukcja obsługi / User Manual
