1 Technical data KERN 3K -3 6K -3 10K -3 30K -2 Weighing range (max) 3 kg 6 kg 15 kg 30 kg Readability (d) 10 g Reproducibility 10 g Linearity 10 g 20 g Recommended adjustment 3 kg 6 kg...
2 Appliance overview 2.1 Overview of display 2.1.1 Not verifiable models Display Designation Description Zeroing display Should the balance not display exactly zero despite empty scale pan, press the button. The balance will be set to zero after a short standby time. Stability display Scales are in a steady state Net weight display...
2.2 Keyboard overview Button Designation Function ON-button, zero Switch-on, set to zero button OFF-button Switching Off TARE button Tare balance Unit button Switch-over units Switch-over gross Switch-over button weight / net weight FXN-N-BA-e-1410...
In KERN’s accredited DKD calibration laboratory test weights and balances may be calibrated (return to the national standard) fast and at moderate cost. FXN-N-BA-e-1410...
4.1 Pay attention to the instructions in the Operation Manual Carefully read this operation manual before setup and commissioning, even if you are already familiar with KERN balances. All language versions contain a non-binding translation. The original German is binding.
6 Unpacking, Setup and Commissioning 6.1 Installation Site, Location of Use The balances are designed in a way that reliable weighing results are achieved in common conditions of use. You will work accurately and fast, if you select the right location for your balance. Therefore, observe the following for the installation site: ...
6.2 Unpacking and placing Carefully remove the balance from the packaging, remove plastic cover and setup balance at the intended workstation. Level balance with foot screws until the air bubble of the water balance is in the prescribed circle. Access to membrane Battery compartment Pressure compensation...
6.2.1 Scope of delivery Serial accessories: Balance Weighing pan Operating manual 4 x 1.5V size D batteries 6.3 Battery operation The operating time of the batteries with background illumination is 200 h, without background illumination 250 h. In menu you can activate the AUTO-OFF function, see chap.
Page 12
Insert 4 x 1.5V size D batteries. Close the battery compartment cover. Move both levers 90° to the right Ensure that the cables are not squeezed. FXN-N-BA-e-1410...
Info about test weights can be found on the Internet at: http://www.kern-sohn.com Procedure when adjusting: Observe stable environmental conditions. A warming up time (see chapter 1) is required for stabilization.
7.1.1 Adjustment Operation Start balance by pressing Press at the same time in weighing mode. 01 FnC appears Select 02 EC using button Confirm with button The adjustment weight to be used appears. Confirm by pressing the button (the displayed adjustment weight flashes) ...
8 Operation 8.1 Weighing Start balance by pressing The balance will carry out a self-test As soon as the weight display shows „0.0“ and the triangle symbol above the stability display appears, the scale is ready for weighing. ...
The tare weight is saved until it is deleted. Remove the load from the balance and press . The zero display appears and the triangle above the net weight symbol vanishes. Gross weight: Press as long as the weighing container and the object to be weighed are on the weighing plate.
9 The menu 9.1 Navigation in the menu Start balance by pressing In weighing mode press the and the button at the same time. 01 FnC appears Use the button to change between the main menu items. ...
9.2 Menu overview Menu item Function 01 FnC Access to the settings and functions of the balance. FnC 01 Setting of background lighting FnC 02 Setting Auto-off function FnC 03 Hi / Lo / OK function. (Check weighing) FnC 04 Reset to standard setting FnC 05 Not documented...
9.3 Set auto-OFF function Start balance by pressing Press at the same time in weighing mode. 01 FnC appears Confirm with button FnC 00 appears Use the button to change between the numeric values. ...
10 Error messages Display Description Remedy Zero range exceeded Unload the balance Resetting range has not been Check if the correct weighing reached. plate has been used. Unload the balance and Overload adjust again FXN-N-BA-e-1410...
11 Instant help In case of an error in the program process, briefly turn off the balance and disconnect from power supply. The weighing process must then be restarted from the beginning. Fault Possible cause The balance is not switched on. The displayed weight does not glow.
Spilled weighing goods must be removed immediately. 12.2 Servicing, maintenance The appliance may only be opened by trained service technicians who are authorized by KERN. Before opening, disconnect from power supply. 12.3 Disposal Disposal of packaging and appliance must be carried out by operator according to valid national or regional law of the location where the appliance is used.
