EZSG8WS*1C
LZSG8WS*1C
INSTALLATION & USE MANUAL
Manual de instalación y uso
Manuel d'installation et d'utilisation
EZ™ & LZ ™ Series Bottle Filling Stations & Coolers
EZ™ & LZ™ Serie versatil Botella Bombas y Enfriadores
EZ™ & LZ™ Stations de Remplissage de Bouteille Série et Refroidisseurs
Page 1
1000002058 (Rev. B - 09/18)
Advertisement
Related Manuals for Elkay EZSG8WS 1C Series
Summary of Contents for Elkay EZSG8WS 1C Series
- Page 1 EZSG8WS*1C LZSG8WS*1C INSTALLATION & USE MANUAL Manual de instalación y uso Manuel d’installation et d’utilisation EZ™ & LZ ™ Series Bottle Filling Stations & Coolers EZ™ & LZ™ Serie versatil Botella Bombas y Enfriadores EZ™ & LZ™ Stations de Remplissage de Bouteille Série et Refroidisseurs Page 1 1000002058 (Rev.
- Page 2 EZSG8WS*1C LZSG8WS*1C Note: Danger! Electric shock hazard. Disconnect power before servicing unit. Nota: peligro! Peligro de descarga eléctrica. Desconecte antes de reparar la unidad. Remarque : Danger ! Risque d'électrocution. Débrancher avant de réparer l'appareil. Pictured is unit only without bottle filler. En la foto, la unidad sólo sin relleno botella.
- Page 3 EZSG8WS*1C LZSG8WS*1C Fig. 2 Page 3 1000002058 (Rev. B - 09/18)
-
Page 4: Entretien
EZSG8WS*1C LZSG8WS*1C HANGER BRACKETS INSTALLATION INSTALACIÓN DE SOPORTES PARA COLGAR SUPPORTS DE CROCHET DE SUSPENSION INSTALLATION Retire el soporte fijador que se encuentra conectado a 1) Remove hanger brackets fastened to back of cooler la parte posterior del enfriador sacando un (1) tornillo. 1) Retirez le support de suspension fixé... - Page 5 EZSG8WS*1C LZSG8WS*1C Service Instructions Lower and Upper Shroud To access the refrigeration system and plumbing connections, remove four screws from bottom of cooler to remove the lower shroud. To remove the upper shroud for access to the pushbars, regulator, solenoid valve or other components located in the top of the unit, remove lower shroud, disconnect drain, remove four screws from tabs along lower edge of upper shroud, unplug two wires and water tube.
- Page 6 EZSG8WS*1C LZSG8WS*1C 7/16” BOLT HOLES FOR MOUNTING TOP COVER FASTENING UNIT TO WALL SCREWS UNIT CENTER LINE Fig. 4 Fig. 5 BRACKET & SCREWS Fig. 7 Fig. 6 Bottle Filler Installation Instructions 1) Remove two (2) mounting screws with 5/32” Allen wrench holding top cover to Bottle Filler (See Fig. 5). Remove top cover. Note do not discard mounting screws, they will be needed to reinstall top cover.
- Page 7 EZSG8WS*1C LZSG8WS*1C BF11 - BF12 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE Continued from below: 1) To verify the software program of the control board the unit will 2) When the display changes to “SETTINGS”, depress the button again. need to be shut down and restarted.
- Page 8 EZSG8WS*1C LZSG8WS*1C NOTE: When installing replacement bubbler and pedestal, tighten nut only to hold parts snug in position. Do Not Overtighten. NOTA: Al instalar el grifo y pedestal de reemplazo, apriete la tuerca unicamente para mantener las piezas en una Basin posicion adjustada.
- Page 9 EZSG8WS*1C LZSG8WS*1C OPERATION OF QUICK CONNECT FITTINGS OPERATION OF QUICK CONNECT FITTINGS SIMPLY PUSH IN TUBE IS SECURED PUSH IN COLLET SIMPLY PUSH IN TUBE IS SECURED PUSH IN COLLET TUBE TO ATTACH IN POSITION TUBE TO ATTACH IN POSITION TO RELEASE TUBE TO RELEASE TUBE PUSHING TUBE IN BEFORE...
- Page 10 INFORMATIONS POUR LE SERVICE PAR NUMERO SANS FRAIS 1.800.260.6640 PRINTED IN U.S.A. IMPRESO EN LOS E.E.U.U. ELKAY MANUFACTURING COMPANY • 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484 • www.elkay.com IMPRIMÉ AUX É.-U. 1000002058 (Rev. B - 09/18)
