- Page 1 Assembly&Instruction Manual SKU:800-110 dirondack Chair Installation Guide Version:221111 Save this manual for future reference...
-
Page 2: Care And Maintenance
INTRODUCTION Thank you for purchasing Aoodor s Patio HDPE Adirondack Chair! We hope you will find joy in our products for many years to come. To ensure your personal safety during installation and to get the most out of your investment, please read this entire manual before beginning the installation process. - Page 3 Par ts Desc Ref No Par ts Desc Ref No 800-110-011 800 110 001 M6*80mm 800 110 002 800 110-012 M6*60mm 800 110-013 800 110-003 M6.3*50mm 800 110-004 800 110-014 M6*50mm 800 110-005 800 110-015 M6.3*30mm 800 110 016 800 110-006 800 110-007 800 110-017 800 110-018...
- Page 4 Assembly Attach the both side of Front Leg( C&D ) to Chair Seat ( B ) with bolt ( 2 ) , nut ( 7 ) and washer ( 6 ). Attach both side of the Chair Arm( E&F ) to Chair Backrest with bolt ( 1 ) Attach both side of Locking Blocks( I ) to Chair Backrest with bolt ( 3 ), to Chair Seat with bolt ( 4 ), nut( 7 ), washer( 6 )
- Page 5 Assembly Attach Front Race ( G ) to the Chair Legs with bolt ( 5 ),and attach Back Race to Chair Seat ( A) with bolt ( 3 ) Please don’t hesitate to contact us for any further questions, your satisfaction is guaranteed. customerservice@aoodor.com https://www.aoodor.com/...
