Toshiba Portege R500-S5007V Specifications

Portégé R500-S5007V Detailed Product Specification
Model Name Description
R500-S5007V Genuine Windows Vista® Business, Intel® Core™ 2 Duo Processor U7700, 2048MB
DDR2, 128GB SATA solid state drive, DVD-SuperMulti, 12.1" widescreen WXGA,
Intel® Wireless WiFi Link 4965AGN, Bluetooth v2.0 + EDR, 3 year standard limited
warranty (1-year warranty on battery)
C1 2
Operating System
• Genuine Windows Vista® Business (32-bit version)
o Downgrade media for Genuine Windows® XP Professional
Processor and Chipset
Intel® Centrino® processor technology featuring:
o Intel® Core™ 2 Duo Processor U7700
1.33GHz, 2MB L2, 533MHz FSB with 64-bit
• Chipset
o Mobile Intel® 945GMS Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
5
Memory
• Configured with 2048MB PC2-5300 DDR2 SDRAM (single memory slot
occupied)
• 2048MB (Min)/2048MB (Max), 1024MB on motherboard with single
available memory slot occupied with 1024MB PC2-5300 memory
module
6
Storage Disk Drive
• 128GB Serial ATA solid state drive; 3mm height
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R) drive supporting 9 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (10x), DVD-ROM (8x), DVD-R (8x), DVD-RW (4x),
DVD+R (8x), DVD+RW (4x), DVD-RAM (3x)
8
Display
• 12.1" diagonal widescreen high brightness display at 1280 x 800
resolution(WXGA) - Transreflective type
o LED backlight
9
Graphics
• Intel® Graphics Media Accelerator 950
Sound
• Built-in monaural speaker
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• 85 key US keyboard
• TouchPad™ pointing device
• Control Buttons:
o Toshiba Assist button
o Toshiba Outdoor Display Switch
Communications
• Intel® PRO/1000 - 10/100/1000 Ethernet
• Integrated Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
• Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
Expandability
• One PCMCIA – Type II Card Slot
• Secure Digital (SDHC) slot
Ports
• Video
o RGB (monitor) output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o USB v2.0 – 3 ports
3
4
7
© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
1
o 64-pin docking connector
• Security
o Fingerprint reader
Physical Description
• Dimensions (WxDxH Front/H Rear): 11.1" x 8.5" x .77"(f)/1.0"(r) with
feet
• Weight: Starting at 2.4 lbs depending upon configuration
• LCD Cover Color: Aluminum Silver
C1
Power
• 45W (15V x 3A) 100-240V AC Adapter.
• Dimensions (WxDxH): 3.66" x 1.09" x 1.57"
• Weight: starting at 0.4 lbs
12
Battery
• (5800mAh) Lithium Ion battery pack
• Dimensions (WxDxH): 8.1" x .79" x 1.72"
• Weight: starting at 0.69 lbs
• Battery Life (measured by MobileMark™)
o Included 6-cell battery: 7 hours, 30 minutes
Toshiba EasyGuard®
• Protect & Fix
o Shock Absorbing Design
o Hard Disk Drive Protection
o Spill-Resistant Keyboard
o Magnesium Alloy Casework
• Secure
o Multiple-Level Password Utilities
o Fingerprint Reader (includes software for password and identity
management)
o AuthenTec EntréPad® TruePrint® technology
o Infineon TPM Software Professional Package
o Trusted Platform Module (TPM v1.2)
o TOSHIBA Secure Digital Token Utility
o Execute Disable Bit
o Optional Services and Accessories (additional purchase required)
• Connect
o Diversity Antenna
o TOSHIBA ConfigFree®
o Voice-over-IP Ready Design
o TOSHIBA Bluetooth® Stack
10
• Optimize
o TOSHIBA Zooming Utility
o One-touch Resolution Change
o TOSHIBA Power Saver Utility
o TOSHIBA Optical Disc Drive Power On/Off Utility
o Wireless On/Off Switch
o TOSHIBA Fn-esse® Shortcut Utility
o TOSHIBA Mouse Utility
o FN Shortcut Keys
BIOS
• ACPI v2.0, PNP, VESA, DPMS, DDC, SM BIOS v2.4, PCI BIOS v2.1
support
Software
• Toshiba Software and Utilities
Portégé R500-S5007V 1.3
Part Number
PPR50U-08008R
13
14
15
HDD Shock Absorber
LCD Panel Shock Absorber
Chassis Shock Protector
3D Accelerometer
HDD Dome Shock Protector
HDD Shock Absorber
16
CompuTrace®
C1 17
UPC
883974114702
11
