Toshiba Portege R500-S5005 Specifications

Portégé R500-S5005 Detailed Product Specification
Model Name Description
R500-S5005 Genuine Windows Vista™ Business, Intel® Core™ 2 Duo Processor U7600, 2048MB
DDR2, 120GB (5400 RPM), DVD-SuperMulti, 12.1" widescreen WXGA, Mobile Intel®
Graphics Media Accelerator 950 with 8MB-251MB VRAM, Intel® Wireless WiFi Link
4965AGN, Bluetooth v2.0 + EDR, 3 year limited warranty
C1 2
Operating System
• Genuine Windows Vista™ Business (32-bit version)
Processor and Chipset
Intel® Centrino® Duo processor technology featuring:
• Processor
o Intel® Core™ 2 Duo Processor U7600
1.20GHz, 2MB L2, 533MHz FSB with 64-bit
• Chipset
o Mobile Intel® 945GMS Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
5
Memory
• Configured with 2048MB PC2-5300 DDR2 SDRAM (Single memory slot
occupied)
• 2048MB (Min)/2048MB (Max), 1024MB on motherboard with one
available memory slot occupied with 1024MB PC2-5300 memory
module
6
Hard Disk Drive
• 120GB (5400 RPM); Serial ATA hard disk drive; 9.5mm height
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R) drive supporting 9 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (10x), DVD-ROM (8x), DVD-R (8x), DVD-RW (4x),
DVD+R (8x), DVD+RW (4x), DVD-RAM (3x)
8
Display
• 12.1" diagonal widescreen high brightness display at 1280 x 800
resolution(WXGA) – Transreflective type
o LED backlight
9
Graphics
• Intel® Graphics Media Accelerator 950 with 64MB-251MB dynamically
allocated shared graphics memory
Sound
• Built-in monaural speaker
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• 85 key US keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Toshiba Assist button
o Outdoor Display Switch
Communications
• Intel® PRO/1000 - 10/100/1000 Ethernet
• Integrated Wi-Fi® compliant wireless:
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
• Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
Expandability
• One PCMCIA – Type II/Type I Card Slot
• Secure Digital slot (supports SDIO)
Ports
• Video
o RGB (monitor) output port
3
4
7
10
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R500-S5005 BTS Rev. 1.01 2007-09-07 CM T20070402 CB1.40
This product specification is variable and subject to change prior to product launch.
1
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
o USB v2.0 – 3 ports
o 64-pin docking connector
• Security
C1
o Fingerprint reader
Physical Description
• Dimensions (WxDxH Front/H Rear): 11.1" x 8.5" x .77"(f)/1.0"(r) without
feet
• Weight: Starting at 2.4 lbs depending upon configuration
• LCD Cover Color: Aluminum Silver
Power
• 45W (15V x 3A) 100-240V AC Adapter.
• Dimensions (WxDxH): 3.66" x 1.09" x 1.57"
• Weight: starting at 0.4 lbs
12
Battery
• (5800mAh) Lithium Ion battery pack
• Dimensions (WxDxH): 8.1" x .79" x 1.72"
• Weight: starting at 0.69 lbs
• Battery Life (measured by MobileMark™)
o Included 6-cell battery: 7 hours, 17 minutes
Toshiba EasyGuard®
• Protect & Fix
o Shock Absorbing Design
o Hard Disk Drive Protection
o Spill-Resistant Keyboard
o Magnesium Alloy Casework
• Secure
o Multiple-Level Password Utilities
o Fingerprint Reader (includes software for password and identity
management)
o AuthenTec EntréPad® TruePrint® technology
o Infineon TPM Software Professional Package
o Trusted Platform Module (TPM v1.2)
o TOSHIBA Secure Digital Token Utility
o Execute Disable Bit
o Optional Services and Accessories (additional purchase required)
• Connect
o Diversity Antenna
o TOSHIBA ConfigFree®
o Voice-over-IP Ready Design
o TOSHIBA Bluetooth® Stack
• Optimize
o TOSHIBA Zooming Utility
o One-touch Resolution Change
o TOSHIBA Power Saver Utility
o TOSHIBA Optical Disc Drive Power On/Off Utility
o Wireless On/Off Switch
o TOSHIBA Mouse Utility
o FN Shortcut Keys
Part Number UPC
PPR50U-02T01W 032017970595
13
14
15
HDD Shock Absorber
LCD Panel Shock Absorber
Chassis Shock Protector
3D Accelerometer
HDD Dome Shock Protector
HDD Shock Absorber
16
CompuTrace®
11
