Toshiba Portege R500-S5006X Specifications

Portégé R500-S5006X Detailed Product Specification
Model Name Description
R500-S5006X Genuine Windows® XP Professional, Intel® Core™ 2 Duo Processor U7700, 2048MB
DDR2, 160GB 5400rpm SATA, DVD-SuperMulti, 12.1" widescreen WXGA, Intel®
Wireless WiFi Link 4965AGN, Bluetooth v2.0 + EDR, 3 year standard limited warranty
C1 2
Operating System
• Genuine Windows® XP Professional
Processor and Chipset
Intel® Centrino® processor technology featuring:
o Intel® Core™ 2 Duo Processor U7700
1.33GHz, 2MB L2, 533MHz FSB with 64-bit
• Chipset
o Mobile Intel® 945GMS Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
5
Memory
• Configured with 2048MB PC2-5300 DDR2 SDRAM (single memory slot
occupied)
• 2048MB (Min)/2048MB (Max), 1024MB on motherboard with single
available memory slot occupied with 1024MB PC2-5300 memory
module
6
Hard Disk Drive
• 160GB (5400 RPM); Serial ATA hard disk drive; 9.5mm height
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R) drive supporting 9 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (10x), DVD-ROM (8x), DVD-R (8x), DVD-RW (4x),
DVD+R (8x), DVD+RW (4x), DVD-RAM (3x)
8
Display
• 12.1" diagonal widescreen high brightness display at 1280 x 800
resolution(WXGA) - Transreflective type
o LED backlight
9
Graphics
• Intel® Graphics Media Accelerator 950
Sound
• Built-in monaural speaker
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• 85 key US keyboard
• TouchPad™ pointing device
• Control Buttons:
o Toshiba Assist button
o Toshiba Outdoor Display Switch
Communications
• Intel® PRO/1000 - 10/100/1000 Ethernet
• Integrated Wi-Fi® compliant wireless:
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
• Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
Expandability
• One PCMCIA – Type II/Type I Card Slot
• Secure Digital slot (supports SDIO)
Ports
• Video
o RGB (monitor) output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
3
4
7
10
11
© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
1
o USB v2.0 – 3 ports
o 64-pin docking connector
• Security
o Fingerprint reader
Physical Description
• Dimensions (WxDxH Front/H Rear): 11.1" x 8.5" x .77"(f)/1.0"(r) with
feet
• Weight: Starting at 2.4 lbs depending upon configuration
C1
• LCD Cover Color: Aluminum Silver
Power
• 45W (15V x 3A) 100-240V AC Adapter.
• Dimensions (WxDxH): 3.66" x 1.09" x 1.57"
• Weight: starting at 0.4 lbs
13
Battery
• (5800mAh) Lithium Ion battery pack
• Dimensions (WxDxH): 8.1" x .79" x 1.72"
• Weight: starting at 0.69 lbs
Toshiba EasyGuard®
• Protect & Fix
o Shock Absorbing Design
o Hard Disk Drive Protection
o Spill-Resistant Keyboard
o Magnesium Alloy Casework
• Secure
o Multiple-Level Password Utilities
o Fingerprint Reader (includes software for password and identity
management)
o AuthenTec EntréPad® TruePrint® technology
o Infineon TPM Software Professional Package
o Trusted Platform Module (TPM v1.2)
o TOSHIBA Secure Digital Token Utility
o Execute Disable Bit
o Optional Services and Accessories (additional purchase required)
• Connect
o Diversity Antenna
o TOSHIBA ConfigFree®
o Voice-over-IP Ready Design
o TOSHIBA Bluetooth® Stack
• Optimize
o TOSHIBA Zooming Utility
o One-touch Resolution Change
o TOSHIBA Power Saver Utility
o TOSHIBA Optical Disc Drive Power On/Off Utility
o Wireless On/Off Switch
o TOSHIBA Fn-esse® Shortcut Utility
o TOSHIBA Mouse Utility
o FN Shortcut Keys
BIOS
• ACPI v2.0, PNP, VESA, DPMS, DDC, SM BIOS v2.4, PCI BIOS v2.1
support
C1
Software
• Toshiba Software and Utilities
o Electronic User's Guide
o Bluetooth Stack for Windows by Toshiba
Portégé R500-S5006X
Part Number UPC
PPR50U-07X020 883974078455
14
15
HDD Shock Absorber
LCD Panel Shock Absorber
Chassis Shock Protector
3D Accelerometer
HDD Dome Shock Protector
HDD Shock Absorber
16
CompuTrace®
17
12
Page 1 of 5
