JABSCO 37010 Seriers Manual

www.PumpAgents.com - Click here for Pricing/Ordering for Pumps and Parts
ELECTRIC MARINE TOI LET
Push Button Operation
FEATURES
• White Vitreous China Bowl Available in Two Sizes
• Baked enamel seat & cover -
soft close seat option available on regular bowl models
• Flexible Impeller Flush Pump
• Permanent Magnet Type Motor, Fully Enclosed, with
Stainless Steel Shaft
• High Capacity Waste Macerator and Bowl discharge Pump
• Built-in Back Flow Preventer
• Corrosion resistant material for marine use
V ARIATIONS
MODEL NUMBER
37010-3092
37010-3094
37010-4092
37010-4192
37010-4094
37010-4194
INSTALLATION
The Jabsco electric toilet may be installed above or below
the waterline. Flush pump is self-priming with a vertical lift
up to 4 feet; discharge macerator pump can operate
against a vertical head up to 4 feet (1.2m).
Inlet and outlet seacocks should be easily accessible and
be positive shut off valves. If seacocks cannot be con ve -
nient ly operated from toilet location, install suitable shut off
valves for inlet and discharge connections.
Base assembly may be moved 90° to accommodate con -
nec tions and provide accessibility for servicing.
Surface where toilet is mounted should be flat to prevent
distortion of toilet base.
PLUMBING CONNECTIONS - Connect inlet hose using
3/4" (19mm) ID hose. Make sure all inlet connec-tions
are airtight and free of sharp bends or restrictions.
Connect 1" (25mm) or 1-1/2" (38mm) hose to
discharge hose to discharge port (Adaptor 98023-0080 is
included to convert discharge port to 1-1/2"ID hose),
and make suitable
orother discharge system. Avoid sharp bends or
restrictions.For above waterline installations, a check
valve may haveto be instal-led in the flush water intake
line to ensure rapidpump priming. To retain water in
bowl, make a loop in the discharge line about 8 inches
(200mm) above base of bowl.
Jabsco Pumps 37010-4194
DESCRIPTION
Compact Bowl 12V
Compact Bowl 24V
Regular Bowl 12V
Regular Bowl 12V, Soft Close Seat/Lid
Regular Bowl 24V
Regular Bowl 24V, Soft Close Seat/Lid
connection to holding
WARNING
Flood hazard. If toilet is installed below the
!
waterline or may be below the waterline at any
angle of heel or trim, it must be installed with
properly positioned vented loops. Failure to do
so can result in flooding which can cause loss
of property and life.
Do not connect the toilet to the vessels
CAUTION
!
potable water for its source of supply. To do so can result in
contamination of potable water supply. If fresh water is pre-
ferred for flushing, provide a separate fresh water tank to
supply water to the toilet only.
DO NOT CONNECT INLET HOSE TO A PRESSURIZED
WATER SYSTEM.
If the toilet is, or can be, below waterline at any normal(in-
cluding static) attitude of vessel heel and/or trim, a 3/4"
(19mm) Vented Loop Fitting must be installed in the
length of hoseconnecting the flushing pump to the inlet
seacock. TheVented Loop Fitting must be positioned so it
remains at least 8" (200mm)* above the waterline at all
angles of heel and trim.In some installations when a
vented loop is installed in theintake hose, the flushing
pump primeability and flow char-acteristics are reduced
and may adversely affect toiletfunction. To restore
pump performance,
(Jabsco No. 37068-2000) to the vent air inlet to
inter-rupt the air supply during the flush cycle. The
brass port ofthe solenoid valve (remove plastic filter if
tank attached)shouldbe connected to the vent inlet with
3/16" hose and thesole-noid wired in parallel with the
toilet motor. See diagram below.
Model 37010-Series
connect a solenoid valve
