Designer styleD Marine
toilet
FeatUres
• Very quiet flush cycle - like a household toilet
• Single button flush actuator - with dual function water
level control switch
• Supplied with Par-Max 4 self-priming pump to
provide sea water or lake water to rinse the toilet
bowl
• Vitreous china bowl available in compact 14" height
or standard 17" height
• Available in White or Bone
• Baked enamel seat & cover
• High capacity waste macerator and bowl discharge
pump
• All toilet plumbing and wiring connections are
internal-out of sight
sPeCiFiCations
Ports:
Motor & switch: Pump and Toilet Meet U.S.C.G.
normal Water
Consumption:
oPeration
The Designer Styled Toilets with the popular Quiet-
Flush system provide both quiet operation and user
control of water levels in the toilet bowl. A single large
push-button switch provides a simple flush mode by
activating both the rinse water supply and the macerator
discharge pump simultaneously. An additional rocker
switch offers independent control of the rinse water
supply and discharge pump separately so the bowl
water level can be easily raised or lowered by the user.
This provides a method of minimizing water use, when
desired, as well as a means of raising the water level in
the bowl when appropriate for user comfort. It also
allows for complete evacuation of the bowl water while
underway in rough sea conditions.
1
PAR-MAX Pump and Toilet
Inlet - 3/4" Hose Barb
Outlet-1" Hose Barb
Regulation 183.410 and ISO
8846 Marine for Ignition
Protection.
Toilets are marked
andcomply with
EN50081-1 for suppression of
electro-magnetic interference.
1-2 Quarts (Litres)/Flush
Model 37275-series
Model number
37275-0092
Compact White Toilet 14", 12 Volt EMC
37275-0094
Compact White Toilet 14", 24 Volt EMC
37275-1092
Standard White Toilet 17", 12 Volt EMC
37275-3092
Standard Bone Toilet 17", 12 Volt EMC
37275-1094
Standard White Toilet 17", 24 Volt EMC
37275-3094
Standard Bone Toilet 17", 24 Volt EMC
installation
The 37275-Series Designer Styled Toilet includes the
Quiet-Flush Toilet pumping system and is supplied with a
dedicated PAR-MAX 4 pump to provide either sea or lake
water to rinse the toilet bowl when flushing the
toilet. This pump is intended to be located remotely from
the toilet but will function best if the distance from the
toilet is kept to a minimum. Because it is self-priming, it
may be located above the vessel's waterline. It must be
installed with the Pumpgard strainer (provided with the
toilet) located somewhere in the inlet plumbing to the
pump. The toilet also includes a multi-function flush
control which should be installed in a bulkhead location
that is convenient to the toilet and allows access for
wiring to run from the power source and to both the toilet
discharge pump and PAR-MAX rinse water pump.
Because all plumbing and wiring connections at the
toilet are made internally within the china bowl, all
plumbing and wiring must be completed and extended to
the toilet location prior to final installation of the toilet.
1
Description
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for JABSCO 37275 Series
Summary of Contents for JABSCO 37275 Series
- Page 1 Designer styleD Marine Model 37275-series toilet FeatUres • Very quiet flush cycle - like a household toilet • Single button flush actuator - with dual function water level control switch • Supplied with Par-Max 4 self-priming pump to provide sea water or lake water to rinse the toilet bowl •...
- Page 2 Install the toilet seat and lid assembly on the china bowl Vented Loop with the fasteners provided and position the toilet in its desired location. When locating the toilet, ensure there is adequate clearance above the bowl so the seat and Waterline lid assembly can rotate to its fully open position and remain open on its own.
-
Page 3: Electrical Specifications
If the toilet is plumbed to an overboard discharge, and is Position the toilet in its intended mounting position and below the vessel’s waterline, the discharge plumbing must very gently, with a 10 mm wrench, screw the provided include a properly positioned vented loop. The vented loop toilet hold-down fastener into the pilot hole drilled fitting must be secured in a location that remainsatleast earlier. - Page 4 The Jabsco Quiet-Flush Toilet does not require routine housing to the motor. Slide the centrifugal impeller on maintenance other than occasional cleaning to maintain the motor shaft positioning it about 1/32"...
-
Page 5: Exploded View
eXPloDeD VieW F L U F IL L D R A Parts list Qty. Part Qty. Part Description Req. Number Description Req. Number Seal † Seat & Cover 37078-1000 1040-0000 † Bowl, Compact Size, White 37076-0010 Screw 91010-0144 † Bowl, Standard Size, White 37076-1010 Washer, Plastic* 35445-0000... -
Page 6: One-Year Limited Warranty
JABSCO and sold hereunder shall be in conformity with pump components. applicable written specifications and descriptions Loosen the four 5/16"... - Page 7 JABSCO's factory, or by persons not The foregoing warranty is limited solely as set forth expressly approved by JABSCO, nor to any unit the herein and applies only for the period designated serial number, model number, or identification of above.
- Page 8 ITALY JAPAN GERMANY ITT Industries ITT Corporation Jabsco Marine Italia Jabsco GmbH NHK Jabsco Company Ltd. Bingley Road, Hoddesdon Cape Ann Industrial Park Via Tommaseo, 6 Oststrasse 28 3-21-10, Shin-Yokohama 20059 Vimercate, Milano Kohoku-Ku, Yokohama, 222-0033 Hertfordshire EN11 0BU...
