Summary of Contents for Seada SD-USB50
- Page 1 SD-USB50 USB 2.0 Extender (50M) SEADA VER 1.0...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction..................1 2. Features....................1 3. Package Contents................1 4. Specifications..................2 5. Operation Controls and Functions............. 3 5.1 Transmitter Panel................3 5.2 Receiver Panel................. 4 6. Application Example................5 Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 3: Introduction
① 1 × USB 2.0 Extender (Transmitter) ② 1 × USB 2.0 Extender (Receiver) ③ 1 × USB cable (USB-B male head to USB-A male head, 1m) ④ 1 × 5V/1A Power Adapter ⑤ 1 × User Manual Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 4: Specifications
Metal Enclosure Color Black Dimensions Transmitter/Receiver: 82mm(W)×49mm(D)×20mm(H) Weight Transmitter/Receiver: 100g Power Supply Input: AC 100~240V 50/60Hz Output: DC 5V/1A Power Consumption Transmitter: 0.7W, Receiver: 1W Operating Temperature 0°C~40°C/32°F~104°F Storage Temperature -20°C~60°C/-4°F~140°F Relative Humidity 20%~90% RH (non-condensing) Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 5: Operation Controls And Functions
Power LED indicator. The green LED will be on, when the POWER LED transmitter is provided power supply by the connected USB device. The CAT port is connected to the receiver’s CAT port by a CAT port CAT5e/6 cable. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 6: Receiver Panel
DC 5V/1A power supply. Plug DC 5V/1A power supply into the unit and connect DC 5V the adapter to an AC outlet. The CAT port is connected to the transmitter’s CAT port CAT port by a CAT5e/6 cable. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 7: Application Example
5. Application Example Transmitter Cat 5e/6 DEVICE USB 2.0 USB 2.0 DC 5V Receiver USB Flash Disk Power Supply Printer Website: www.seada.co.uk E-mail: sales@seada.co.uk...
