- Page 1 FO-F02P 18Gbps HDMI over Optical Fiber Extender with Audio Extracting SEADA VER 1.0...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction.................... 2. Features....................3. Package Contents................4. Specifications..................5. Operation Controls and Functions............5.1 Transmitter Panel................5.2 Receiver Panel................5.3 IR Pin Definition................6. Application Example................Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 3: Introduction
☆ Transmitter supports loop output (sharing local HD video and audio) and audio embedding function ☆ Receiver supports audio extracting output function ☆ Compact design for easy and flexible installation Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 4: Package Contents
1 x RS-232 [3.81mm Phoenix connector] Transmitter 1 x SERVICE [Micro USB, Update port] Output: 1 x HDMI OUT [Type A 19-pin female] 1 x Optical Fiber Out [LC female] 1 x IR OUT [3.5mm Stereo Mini-jack] Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 5: Operation Controls And Functions
20 - 90% RH (no condensation) 5. Operation Controls and Functions 5.1 Transmitter Panel HDMI SERVICE LINE POWER FIBER LOOP AUDIO EDID HDMI IR IN IR OUT DC 5V HDMI OUT HDMI IN LINE IN RS-232 FIBER Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 6 DVD or PC with an HDMI cable. Audio signal input port, connect to audio source device LINE IN such as MP3. RS-232 signal pass-through port for transmitting RS-232 RS-232 command signals between the Transmitter and Receiver. Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 7: Receiver Panel
Audio signal extracting output port (extract the HDMI OUT audio signal), connect to audio output device such as AUDIO OUT amplifier or speaker. RS-232 signal pass-through port for transmitting RS-232 RS-232 command signals between the Transmitter and Receiver. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 8: Ir Pin Definition
IR Blaster IR Blaster Signal Power IR Receiver IR Signal Power Grounding 5.3 Optical Fiber Module ① SFP-BL32TG-10DC is the optical fiber module of the Transmitter. ② SFP-BL23TG-10DC is the optical fiber module of the Receiver. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 9: Application Example
IR IN IR OUT IR Receiver IR Blaster The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Website: www.seada.co.uk E-mail: sales@seada.co.uk...
