Seada HDV-E5100 User Manual

Hdmi over ip extender with loop out (100m)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GLite
HDMI over IP Extender with
Loop out (100M)
VER 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDV-E5100 and is the answer not in the manual?

Questions and answers

Related Manuals for Seada HDV-E5100

Summary of Contents for Seada HDV-E5100

  • Page 1 GLite HDMI over IP Extender with Loop out (100M) VER 1.0...

  • Page 2: Table Of Contents

    Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.

  • Page 3: Introduction

    3. Package Contents ① 1× HDMI over IP Encoder ② 1× HDMI over IP Decoder ③ 1× Wideband IR Blaster cable ④ 1× Wideband IR Receiver cable ⑤ 2× 5V/1A Power Adapters ⑥ 1× User Manual 1/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...

  • Page 4: Specifications

    88mm (W) × 61.2mm (D) × 16.5mm (H) Weight Encoder: 155g, Decoder: 150g Input: AC100 - 240V 50/60Hz, Output: DC 5V/1A Power Supply (US/EU standards, CE/FCC/UL certified) Power Consumption Encoder: 1.5W, Decoder: 1.25W Operation -10°C ~ 50°C / 14°F ~ 122°F Temperature 2/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...

  • Page 5: Operation Controls And Functions

    / hub. The LED will illuminate blue when the Encoder is POWER LED powered on. Plug the DC 5V/1A power supply into the unit and DC 5V connect the adapter to an AC outlet. 3/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...

  • Page 6: Decoder Panel

    / hub. The LED will illuminate blue when the Decoder is POWER LED powered on. Plug the DC 5V/1A power supply into the unit and DC 5V connect the adapter to an AC outlet. 4/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...

  • Page 7: The Computer Plays Video Stream

    DVD or Blu-ray Player Figure 1: Video Stream connection diagram Step 2: On the PC, go to Control Panel > Network and Internet > Network Connections > Local Area Connections, right click on it, choose Propertiers. 5/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
  • Page 8 Double click Internet Protocol Version 4 (TCP/IPv4). 6/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
  • Page 9 As the Encoder’s IP address is 192.168.10.10, the computer's IP should be 192.168.10.X (X contains 1~255 except 10). Step 3: Input the Encoder’s IP address into your brower on the PC to enter Web GUI page, These pages are shown as below. 7/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
  • Page 10 20480Kb/s and the SubStream range is from 256Kb/s to 2048Kb/s. Note: You can only use either MainStream or SubStream in VLC media player. The MainStream has larger resolution and bitrate than the SubStream. So, the MainStream picture is clearer than the SubStream. 8/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
  • Page 11 Status button: Clicking this button will refresh currently network configuration information to display in Status Log. Status Log: Display the Net configuration information. port: Set netport port value. The default value is 80. 9/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
  • Page 12 Note: When the update file is too large, the upgrade progress could stay a long time in 99%.This is a normal phenomenon. Please do not turn off the power or press the “RESET” button until the upgrade progress up to 100%. 10/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...

  • Page 13: Vlc Media Player Introduction

    When you have connected the Web GUI, then you need to open the VLC media player software on the computer. Double click the “VLC media player” shortcut icon. Please see the icon at picture 4. Picture 4 Step 1: Click “Media > Open Network Stream” 11/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
  • Page 14 (the IP address of the computer and product should be in the same network segment.) and network connection status. ③ If everything is OK, the product boot static IP need to a little time to communication for router. Please try it more times. 12/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
  • Page 15 Web GUI to setting the Dectype, Resolution and Bitrate value of the VLC media player. At the same time, you can check the setting on VLC media player. Choose “Tools>Codec information” to check current codec and resolution. Please see the following picture. 13/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
  • Page 16 Choose “Tools>Codec information>Statistics” to check current bitrate. Please see the following picture. Note: The bitrate is floating up and down when you check it. This is a normal phenomenon. 14/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...

  • Page 17: Application Example

    HDMI IN RESET HDMI OUT RESET Decoder Encoder CAT IN IR IN DC 5V CAT OUT IR OUT DC 5V Power Supply Power Supply Ethernet Cat5e/6 IR Extender IR Blaster Figure 2: Encoder connects directly Decoder 15/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
  • Page 18 CAT IN IR IN DC 5V HDMI OUT RESET HDMI Cable Decoder HDMI Cable CAT IN IR IN DC 5V HDMI OUT RESET Decoder Figure 3: Encoder connects Decoder via switcher (one Encoder to multiple Decoders) 16/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...

  • Page 19: Faq

    15m/49.2ft. According to CAT line length test, using CAT 5e/6 cable extends distance up to 100m/328ft between Encode and Decode. The use of “Premium High Speed HDMI” cable is highly recommended. 17/17 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
