- Page 1 KVM50HD HDMI/USB KVM Extender Over Cat5e/6 VER:1.1...
- Page 2 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
-
Page 3: Table Of Contents
HDMI 1.4b and USB 2.0 standards. Two-way POC (Power over Cable) function allows either TX or RX be powered by a single 12V@1A power supply. It’s an ideal product for cyber bar and KVM extender markets. Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 4 USB 2.0 Full-speed transmission and routing 12V POC (Power over Cable) function supported 3. Package Contents 1 x Transmitter 1 x Receiver 1 x User Manual 1 x DC 12V/1A Power Adapter Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 5: Specifications
Human body model — ±8kV (air-gap discharge) & ±4kV (contact ESD Protection discharge) Connections Transmitter 1x HDMI Type A [19-pin female] Input 1x USB-B [USB B type] 1x HDMI Type A [19-pin female] Output 1x CAT [RJ45] Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 6 Output: DC 12V/1A (US/EU standards, CE/FCC/UL certified) Power Consumption TX:1.92W (Max) RX:1.68W (Max) Operation 32 - 104°F / 0 - 40°C Temperature Storage temperature -4 - 140°F / -20 - 60°C Relative Humidity 20 - 90% RH (no condensation) Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 7: Operation Controls And Functions
HDMI: Input HDMI signal indicator LED. On means there is an active signal. USB: USB status indicator LED, no USB signal being transmitted will show slow flashing, when USB signal being transmitted will show quick flashing. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 8: Receiver Panel
5.2 Receiver Panel P O W E R H D M I U S B D C 1 2V H D M I O U T C A T 5e /6 ( P O C ) Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 9 CAT5e/6 (POC): Connect to transmitter box CAT port through a CAT5e/6 cable length up to 164ft/50m. USB Keyboard: Connect to USB keyboard or a USB slave device; USB Mouse: Connect to USB mouse or a USB slave device; Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 10: Connection Diagram
6. Connection Diagram D C 1 2V H D M I O U T C A T 5e /6 ( P O C ) Website: www.seada.co.uk E-mail: sales@seada.co.uk...
