- Page 1 SD-USB100 USB 2.0 Extender (100M) SEADA VER 1.0...
- Page 2 Table of Contents 1. Introduction................... 2. Features....................3. Package Contents................4. Specifications..................5. Operation Controls and Functions............5.1 Transmitter Panel................5.2 Receiver Panel................6. Application Example................Website: www.seada.co.uk E-mail: sales@seada.co.uk...
- Page 3 ① 1× USB 2.0 Extender (Transmitter) ② 1× USB 2.0 Extender (Receiver) ③ 1× USB cable (USB-B male head to USB-A male head, 1m) ④ 1× 12V/1A Locking Power Adapter ⑤ 1× User Manual Website: www.seada.co.uk 1 / 5 E-mail: sales@seada.co.uk...
- Page 4 Weight Transmitter/Receiver: 100g Input: AC 100~240V 50/60Hz Power Supply Output: DC 12V/1A (US/EU standards, CE/FCC/UL certified) Power Consumption Transmitter: 1.3W, Receiver: 2.3W Operating Temperature 0°C~40°C/32°F~104°F Storage Temperature -20°C~60°C/-4°F~140°F Relative Humidity 20%~90% RH (non-condensing) Website: www.seada.co.uk 2 / 5 E-mail: sales@seada.co.uk...
- Page 5 Plug DC 12V/1A power supply into the unit and connect DC 12V the adapter to an AC outlet. The CAT port is connected to the receiver’s CAT port CAT port by a CAT5e/6 cable. Website: www.seada.co.uk 3 / 5 E-mail: sales@seada.co.uk...
- Page 6 Plug 12V/1A DC power supply into the unit and connect DC 12V the adapter to an AC outlet. The CAT port is connected to transmitter’s CAT port by CAT port CAT5e/6 cable. Website: www.seada.co.uk 4 / 5 E-mail: sales@seada.co.uk...
- Page 7 6. Application Example DC 12V Transmitter Cat5e/6 (100M) DEVICE USB 2.0 USB 2.0 DC 12V Receiver U Flash Disk Power Supply Printer Website: www.seada.co.uk 5 / 5 E-mail: sales@seada.co.uk...
