SUBSTATION
OPTION HANDSET
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
Note: For operation of the units, refer to the VS-900 operating instructions.

1. GENERAL DESCRIPTION

The RS-190 Full-Duplex Substation is designed exclusively for use with TOA's VS-900 Voice Security System.
The RS-191 Option Handset is designed exclusively for indoor-use in combination with the RS-190.
It also features handset conversation with the RS-190.

2. SPECIFICATIONS

[RS-190]
Rated Input
Rated Impedance
Internal Speaker
Control Output
Operating Temperature
Finish
Dimensions
Weight
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Oval head combination screw M4 x 25 ................ 4
[RS-191]
Handset Receiver
Handset Transmitter
Operating Temperature
Finish
Dimensions
Weight
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Oval head combination screw M4 x 25 ................ 4
1 W
500 Ω
4 cm cone-type
Open collector output: 24 V DC, 30 mA
(The open collector output is kept turned on till the conversation is finished
after the call button was pressed.)
–10 to +50°C
(Temperature range not to freeze the speaker and switch)
Panel: Stainless steel (SUS304), hairline
Call switch button: Resin
120 (w) x 120 (h) x 58.5 (d) mm
465 g
Dynamic type
Electret condenser type
0 to +40°C
(Temperature range not to freeze the speaker and switch)
ABS resin, pale white
116 (w) x 220 (h) x 70 (d) mm
330 g
INSTALLATION MANUAL
Oval head slotted screw UNC No.6 x 18 .............. 4
Oval head slotted screw UNC No.6 x 18 .............. 4
RS-190
RS-191

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-190 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toa RS-190

  • Page 1 Note: For operation of the units, refer to the VS-900 operating instructions. 1. GENERAL DESCRIPTION The RS-190 Full-Duplex Substation is designed exclusively for use with TOA's VS-900 Voice Security System. The RS-191 Option Handset is designed exclusively for indoor-use in combination with the RS-190.
  • Page 2 3. WALL MOUNTING Mount the RS-190 and the RS-191 to electrical boxes mounted in the wall. Note: The wall should be over 12 mm thick, and the opening in the wall for an electrical box should be under 120 mm by 120 mm.
