Toa HB-1 Specifications

I
N T E R I O R
D S
E S I G N E R I E S
H B - 1
F -M
LUSH OUNT
S
U B W O O F E R
THE TOA HB-1 FLUSH-MOUNT
is the ideal solution for
SUBWOOFER
adding low frequency enhancement to
commercial, residential and retail sound
systems. The HB-1's unique minimum-depth
design allows discreet flush-mount
installation in ceiling structures or in walls
between studs spaced on 16" centers.
The HB-1 features a tuned, ported enclosure
and a heavy-duty 8" woofer for high power
handling and extended low frequency
response. An acoustic bandpass filter design
eliminates the need for an external crossover.
The solidly constructed steel enclosure also
acts as a heat-sink to dissipate excessive heat
from the speaker component. Other
features include a paintable grille and
removable terminal block. Options include a
matching transformer for connecting the HB-1
to distributed speaker systems and a 900
Series Low Pass Filter Module for convenient
system equalization.The HB-1 also carries a
five year warranty.
H
I G H L I G H T S
Low Frequency Enhancement
for a wide variety of speaker
system applications including
hotels, houses of worship,
museums, offices, residential
spaces, restaurants, and retail
stores.
Minimum-Depth Design
allows recessed, flush-mount
installation in spaces with only
4.1" of available depth.
Wall-Mount
between 16" spaced wall studs.
Ceiling-Mount
using supplied rigging points.
Tuned, Ported Enclosure
for deep bass and low distortion.
Acoustic Bandpass Filter Design
eliminates need for external
crossover.
High Power Handling:
240 W (Continuous Program)
O A
P T I O N A L C C E S S O R I E S
E-07S
900 Series Low Pass Filter Module for convenient
system equalization
MT-S0601
Matching Transformer (60 W max.) for 70.7 V/ 100 V distributed
speaker systems, mountable inside enclosure
Frequency Response:
45 - 200 Hz (-10 dB, 1/2 space)
High Sensitivity:
91 dB SPL (1 W / 1 m, 1/2 space)
Heavy-Duty Loudspeaker Component:
8" woofer with ferrite magnet
Solid, Vibration-Free Steel Enclosure:
also acts as heat-sink to dissipate
excessive heat away from the
speaker component.
Removable Terminal Block
with loop-through terminations
for convenient connection of
parallel speakers.
Paintable Grille
to custom-match to the
environment.
Mounting Bracket Included
Five Year Warranty
