PROFESSIONAL SOUND SYSTEM
Mini Subwoofer System

General Description

The FB-10 is designed as a subwoofer system for the *F-
series speaker system.
*F-series Speaker System
F-10W, F-10B
F-150W, F-150G, F-150R
F-300W, F-300G, F-300R
Features
1. The FB-10 is a high input capacitance, mini subwoofer
system using a 16 cm woofer.
2. By adopting a port radiation type enclosure, the FB-10
can reproduce super low frequency sound with less
distortion despite its compact size.
3. The FB-10 can be installed on the wall or the ceiling
with the optionally available BY-10 fitting.

Specifications

Enclosure: Port radiation type
Speaker: 16 cm cone speaker
Impedance:
Power Handling Capacity
Continuous Pink Noise: 60W (40-20,000Hz) 20W (40-100Hz)
Continuous Program: 180W (40-20,000Hz) 60W (40-100Hz)
Sensitivity: 83dB (1W/1m)
Frequency Response: 40Hz - 100Hz
Finish (Enclosure): Urethane coated (Black)
Dimensions: 700(W) x 212(H) x 212(D) mm
27.6(W) x 8.3(H) x 8.3(D) inches
Weight: Approx. 9 kgs (20 Ibs.)
Specifications are subject to change without notice for
improvements.
TOA Corporation
KOBE, JAPAN
Instruction Manual
