CEILING SUBWOOFER
TABLE OF CONTENTS
..........................
2
Thank you for purchasing TOA's Ceiling Subwoofer.
Please carefully follow the instructions in this manual to ensure long, trouble free use of your equipment.
FB-2862C-AS
FB-2862C-EA
FB-2862C-EB
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Toa FB-2862C-AS
Summary of Contents for Toa FB-2862C-AS
- Page 1 ......Traceability Information for Europe Manufacturer: Authorized representative: Thank you for purchasing TOA’s Ceiling Subwoofer. TOA Corporation TOA Electronics Europe GmbH Please carefully follow the instructions in this manual to ensure long, trouble free use of your equipment. 7-2-1, Minatojima-Nakamachi, Chuo-ku, Kobe, Hyogo,...
-
Page 2: Safety Symbol And Message Conventions
Maximum ceiling thickness: 37 mm (1.5”) combination. Doing otherwise may cause the unit or component to fall off, resulting in personal injury. Leave the installations to your TOA dealer because Should the following irregularity be found during use, the installation requires expert knowledge.Improper... -
Page 3: General Description
2. GENERAL DESCRIPTION The FB-2862C is a vented speaker, flush-mounted ceiling subwoofer that offers a low frequency range and high-quality sound output. Use of its supplied and optional mounting hardware permits versatile mounting to match a wide range of applications and installation locations. 3. - Page 4 Unit: mm (inches) 6.1. Detaching the Front Grille Turn the front grille counterclockwise to full stop, then pull it Unlock lightly downward. [Front] [Side] The front grille employs a double-locking system. If the grille cannot be detached when lightly pulled downward, it Front grille likely has not yet been fully rotated back to the detachment position.
- Page 5 The FB-2862C ceiling subwoofer can be mounted in 3 different configurations: Mounting tab Direct mounting to a ceiling panel Use the supplied ceiling reinforcement ring. Mounting to a ceiling frame Use the supplied ceiling reinforcement ring in conjunction with the optional HY-TB1 Tile Bar Bridge. Mounting to an anchor bolt Use the supplied ceiling reinforcement ring in conjunction with the optional HY-AH1 Anchor Hanging Bracket.
- Page 6 3-1. Direct mounting to a ceiling panel Mounting hole Fold the supplied ceiling reinforcement ring in half* and insert it trough the mounting hole in the ceiling panel, then open it with its tabs facing up. Ceiling reinforcement ring Place the ring on the ceiling panel aligning it with (accessory) Loosen the cord clamp fixing screws and open the cord clamp.
