Assembly Instructions for Model Number 139R-BL
esort
IMPORTANT INFORMATION
Unwrap and remove all parts from the box. Keep the box and packing material until the product is assembled.
In case of return or exchange, failure to return product in similar condition as received could result in limited
reimbursement. Please save sales receipt as proof of purchase for warranty purposes. Check to ensure you
have all the parts below. If you discover any parts are missing, immediately call our toll-free service helpline at
1-800-428-8560 (Monday - Friday 9 a.m. to 4 p.m. EST) or email customer service at
info@midwesthomes4pets.com.
PARTS IDENTIFICATION
ASSEMBLY INSTRUCTIONS
Pre-assembly:
1. Posts with pre-attached screw comes with black cap attached. Remove black cap before
assembly.
2. Hoop Hammock (C) uses a pillow; this does is not come attached. Place pillow in hammock after
securing hammock in Step 3.
3. Hooded Bed (D) comes in two parts; a circular wooden board and the faux fur shell. Attach the fur shell to
woooden board, using the draw strings. Strings can be tighten to place Shell opening in desired location.
TM
A - Base
B - Oval Platform (2)
C - Hoop Hammock
D - Hooded Bed
Allen Wrench included for
assembly
TM
800-428-8560
midwesthomes4pets.com
P.O. Box 1031
Muncie, Indiana 47308
E - Long Post with Screw
F - Short Post with Screw (3)
G - Long Post (without screw)
H - Short Post (without screw)
I - Bolt (2)
1.9in (50mm)
J - Short Dual Thread Screw
2.75in (70mm)
K - Long Dual Thread Screw (2)
3.15in (80mm)
L - Bolt Cap
