Assembly Instructions for Model Numbers 1154U
ImPortant InformatIon
Remove collar, tags, and leads from pet before placing it in the home to prevent possible entanglement.
Unwrap and remove all parts from the box. Keep the box and packing material until the product is assembled. In case of
return or exchange, failure to return product in similar condition as received could result in limited reimbursement. Please
save sales receipt as proof of purchase for warranty purposes. Check to ensure you have all the parts below. If you
discover any parts are missing, immediately call our toll-free service helpline at 1-800-428-8560
(Monday - Friday 9 a.m. to 4 p.m. EST) or email customer service at info@midwesthomes4pets.com.
Parts IdentIfIcatIon
A. Bottom Panel (2)- The bottom panel has the widest
spaces between the wires and upright bent hooks.
The "front" bottom panel has a bent wire attached
to one end ("pan stop").
B Top Panel (2 hinged panels)- The top panels have
open hooks on the length of two sides.
C Long Side Panel (4)- Each Side Panel has two
closely spaced wire rungs at the bottom. Use these
rungs to help identify the bottom.
D Door Panel (Front)- This is the shorter panel with
the hinged door and U-shaped slide bolt locks. The
top of the Door Panel has two bent wire hangers.
E Back Panel- Same size as door panel but is solid
mesh. Top of Back Panel has two bent wire
hangers.
F Corner Rods (6)- These are straight wire rods with
hooks on the end. They will be inserted downward
twoard the corner loops to secure the top, sides,
and bottom of your pet home.
G Bottom Pan-This is a slide-in pan which can be
easily removed for cleaning.(Pan comes in
separate carton.)
800 428 8560
midwesthomes4pets.com
P .O. Box 1031
Muncie, Indiana 47308
A
Front
Back
C
D
F
by
Pan stop
B
E
G
1
