Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. NOTICE: The removal or modiﬁcation of evaporative emission-related parts on this OHRV is illegal. Violators may be subject to civil and/or criminal penalties as provided under California and federal law. OWNER’S MANUAL YXE10WPLM LIT-11626-34-34 B4M-F8199-11...
Page 2 EBU31032 Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your...
Page 3 Yamaha experience in the production of fine sporting, touring, and pace-setting racing vehicles. With the purchase of this Yamaha, you can now appreciate the high degree of crafts- manship and reliability that have made Yamaha a leader in these fields.
Page 4 EBU31080 IMPORTANT MANUAL INFORMATION EBU31070 FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERI- OUS INJURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to poten- tial personal injury hazards.
Page 5  This vehicle complies with all state off-highway noise level and spark arrester laws and regulations. EBU31111 YXE10WPLM OWNER’S MANUAL ©2021 by Yamaha Motor Corporation, U.S.A. 1st edition, July 2020 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A.
Page 6: Table Of Contents
On–Command drive knob EBU31120 CONTENTS “2WD/4WD/DIFF. LOCK” ....5-17 D-mode knob VEHICLE IDENTIFICATION ..... 1-1 “SPORT/TRAIL/CRAWL”....5-18 Identification numbers......1-1 Suspension mode switch ....5-19 Accelerator pedal ....... 5-19 LOCATION OF THE WARNING AND Brake pedal ........5-20 SPECIFICATION LABELS ....... 2-1 Parking brake lever ......
Page 7 OPERATION ..........7-1 Auxiliary DC connectors..... 5-37 ® Engine break-in........7-1 audio system....5-37 SSV Works Starting the engine .......7-2 Yamaha Adventure Pro powered by ® Drive select lever operation and Magellan ......... 5-37 reverse driving ........7-3 FOR YOUR SAFETY – On-Command drive knob .....7-6 PRE-OPERATION CHECKS....
Page 8 Hood........... 9-10 Checking the accelerator pedal..9-43 Engine oil and oil filter ......9-11 Parking brake lever free play Why Yamalube ........9-20 adjustment ........9-44 Transmission oil ......... 9-21 Brake light switch adjustment ....9-44 Continuously Variable Transmission Cable inspection and lubrication ..9-45 (CVT) ..........
Page 9 Vehicle Emission Control Information label ..........12-1 Emission Regulation (California)..12-1 Vehicle data recording ....... 12-1 NOISE REGULATION ......12-3 MAINTENANCE RECORD ....12-4 YAMAHA MOTOR CORPORATION, U.S.A. 2020 AND LATER MODEL SIDE-BY-SIDE LIMITED WARRANTY........12-5 YAMAHA EXTENDED SERVICE (Y.E.S.) ..........12-7...
Page 10: Vehicle Identification
EBU38890 VEHICLE IDENTIFICATION EBU32781 EBU32800 Vehicle identification number Identification numbers The vehicle identification number is stamped Record the vehicle identification number, into the frame. model label information and key identification number in the spaces provided below. VEHICLE IDENTIFICATION NUMBER: MODEL LABEL INFORMATION: 1.
Page 11 * * * * - * * * 1 1 1 1. Model type code 2. Production code 1. Model label 3. Color code Your specific model can be identified by EBU32790 Key identification number checking the model type code found on the The key identification number is stamped on model label.
Page 12 1. Key identification number...
Page 13: Location Of The Warning And Specification Labels
EBU31130 LOCATION OF THE WARNING AND SPECIFICATION LABELS...
Page 15 Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
Page 16 WARNING Improper use of cargo bed or cage/frame can result in severe injury or Never carry death from loss of passengers control, overturn or in cargo bed. other accidents. Maximum Load in Cargo Bed: 600 lbs (272 kg) Maximum Vehicle Load: 1256 lbs (570 kg) •...
Page 17 This unit contains high pressure nitrogen gas. requirements for rollover protection structures Mishandling can cause explosion. m=900Kg for ISO3471 Read owner’s manual for instructions. Do not incinerate, puncture or open. YAMAHA MOTOR CORPORATION U.S.A. B4M-F2259-00 6555 Katella Avenue, Cypress, California 90630-5101, U.S.A. B4M-F4164-00 B4J-F847C-00...
Page 18 WARNING YAMAHA MOTOR CORPORATION U.S.A. certifies this ROV complies with the American National Standard for Recreational • Improper tire pressure or overloading this vehicle may Off-Highway Vehicles, ANSI/ROHVA-1-2016 Standard. cause severe injury or death from loss of control or Date of manufacture **/** rollover.
Page 19 PREMIUM UNLEADED GASOLINE ONLY WARNING 91 Min. Pump Octane (R+M) / 2 1TD-F415E-00 Improperly loading a trailer or pulling an object can affect handling, stability, and risk of overturn or other accidents. • Secure load to prevent it from shifting. •...
Page 20 WARNING Improper Use of Off-Highway Vehicle Can Cause Severe Injury or Death Be Prepared • Fasten seat belts. • • Wear an approved helmet, eye protection • and protective gear. • • Driver must be able to comfortably reach all •...
Page 21 Vehicle Can Cause Severe Injury when lowering bed. Do not hold or Death the cage/frame while closing bed. Be Prepared • Fasten seat belts. YAMAHA BHF-K7764-00 Wear an approved • helmet, eye protection and protective gear. • Passengers must be able...
Page 22: Safety Information
Wolverine RMAX2. While understanding all parts of this manual are important for vehicle owner- ship, be sure to read this chapter and the instructions in Chapter 8 before operating your Yamaha Wolverine RMAX2. Also use these two chapters and the labels on the vehicle to instruct new op- erators and passengers.
Page 23 Before you operate your Yamaha Wolverine RMAX2  Prepare yourself and your passenger: • This vehicle is intended for use only by an operator 16 or older with a valid motor vehicle li- cense. DRIVER UNDER • This vehicle is designed to carry the driver and one passenger. Never carry passengers in the cargo bed.
Page 24  Secure cargo so that it will not shift – a loose load could change handling unexpectedly or be thrown forward and strike occupants. While using your Yamaha Wolverine RMAX2  Keep your body completely inside the vehicle at all times. Keep both hands on the steering wheel.
Page 25  Abrupt maneuvers or aggressive driving, even on flat, open areas, can cause loss of control, including rollovers. The Wolverine RMAX2 has higher ground clearance and other features to handle rugged terrain, and, as a result, can overturn in situations where some other vehicles may not.
Page 26 • Avoid paved surfaces. Turn gradually and go slowly if you must drive on pavement. This vehicle is designed for off-road use only.  If you think or feel that the vehicle may tip or roll, keep your body completely inside the protec- tive structure of the vehicle: •...
Page 27 Genuine Yamaha Accessories Choosing accessories for your Wolverine RMAX2 is an important decision. Genuine Yamaha Ac- cessories, which are available only from a Yamaha dealer, have been designed, tested, and ap- proved by Yamaha for use on your Wolverine RMAX2.
Page 28 Many companies with no connection to Yamaha manufacture parts and accessories or offer oth- er modifications for Yamaha vehicles. Yamaha is not in a position to test the products that these aftermarket companies produce. Therefore, Yamaha can neither endorse nor recommend the use of accessories not sold by Yamaha or modifications not specifically recommended by Yamaha, even if sold and installed by a Yamaha dealer.
Page 29: Description
EBU31170 DESCRIPTION EBU31180 Left view 2,3 4 1. Winch 7. Door 2. Fuses 8. Engine oil tank 3. Battery 9. Coolant reservoir 4. Air filters 10.Brake fluid reservoir 5. Seat belt 11.Front shock absorber assembly 6. Shoulder bolster...
Page 30: Right View
EBU31190 Right view 6 6 6 1. Brake/tail light 2. Cargo bed 3. Seat belt 4. Fuel tank cap 5. Transmission oil dipstick 6. Oil filter cartridge 7. Rear shock absorber assembly 8. Spark arrester...
Page 31: Controls And Instruments
EBU31200 Controls and instruments 7 8 9 1. Speed Management System switch 11.Glove compartment 2. Steering wheel 12.USB jack 3. Multi-function meter unit 13.Drive select lever 4. Main switch 14.Parking brake lever 5. D-mode knob 15.Accelerator pedal 6. Suspension mode switch 16.Brake pedal 7.
Page 32: Instrument And Control Functions
EBU3121D INSTRUMENT AND CONTROL The operation of the indicator and warning FUNCTIONS lights, and the multi-function meter can be EBU31221 confirmed at this time. Main switch EBU31241 Off position “ ” All electrical circuits are switched off. The key can be removed. EBU31251 Start position “...
Page 33: Indicator Lights And Warning Lights
EBU31269 EBU39290 Low-range indicator light “ ” Indicator lights and warning lights This indicator light comes on when the drive select lever is in the “L” position. EBU39300 High-range indicator light “ ” This indicator light comes on when the drive select lever is in the “H”...
Page 34 EBU39340 High beam indicator light “ ”  See pages 5-17 and 7-6 for more informa- This indicator light comes on when the high tion on selecting the drive mode. beam of the headlight is switched on.  Due to the synchronizing mechanism in the EBU39351 differential gear case, the drivetrain icon Differential gear lock indicator light “...
Page 35 If the warning light does not go off, light remains on, have a Yamaha dealer stop the engine and allow it to cool. (See page check the vehicle.
Page 36 Yamaha dealer check the EPS system. display will indicate an error code (see page The electrical circuit of the warning light can 5-13). Have a Yamaha dealer check the self- be checked by turning the key to “ ” (on). If diagnosis system.
Page 37 Seat belt reminder light “ ” play will indicate an error code (see page The reminder light comes on when the key is 5-13). Have a Yamaha dealer check the sus- turned to “ ” (on) to remind the occupants pension system.
Page 38: Multi-Function Meter Unit
 speedometer EBU39871 Multi-function meter unit  odometer  tripmeters  clock  hour meter  voltage display  coolant temperature display  speed management icon  fuel gauge  D-mode indicator  suspension mode indicator  brightness control mode 1.
Page 39 Odometer and tripmeters Push the “SELECT” button to switch between the odometer “ODO”, the tripmeters “TRIP A” and “TRIP B”, and the service tripmeter “ ” in the following order: ODO → TRIP A → TRIP B → → ODO To reset a tripmeter, set the display to the tripmeter you want to reset, then push the “RESET”...
Page 40 Clock, hour meter, voltage display and Push the “MODE” button to switch between coolant temperature display the clock “CLOCK”, the hour meter “HOUR”, the voltage display “VOLT”, and the coolant temperature display “ ” in the following or- der: CLOCK → HOUR → VOLT → →...
Page 41 If the voltage display indicates “Lo” or tinues to rise, the message “Hi” will flash. “Hi”, there may be trouble with the battery charging circuit or the battery may be faulty. If this occurs, have a Yamaha dealer check or repair the vehicle. 5-10...
Page 42 Fuel gauge  The coolant temperature display can be set to “°C” or “°F”. To switch the temperature units, turn the key to “ ” (off), then while holding the “RESET” button pushed, turn the key to “ ” (on). ...
Page 43 When the Speed Management System switch working correctly, all display segments will (page 5-14) is set to the “ ” (on) position, flash repeatedly. Have a Yamaha dealer the D-mode function is deactivated and the check the vehicle. D-mode indicator disappears.
Page 44 1. Push the “SELECT” button until the If the display indicates an error code, note the brightness level is displayed. code number and have a Yamaha dealer 2. Use the “RESET” button to set the bright- check the vehicle. ness level.
Page 45: Speed Management System
ECB00812 NOTICE If the multi-function display indicates an error code, the vehicle should be checked as soon as possible in order to avoid en- gine damage. EBU37660 Speed Management System This model is equipped with a Speed Man- agement System. When the Speed Manage- 1.
Page 46 6. Turn the main switch to “ ” (on) and confirm that the speed management icon comes on. (See page 5-11.) The main switch must be turned to “ ” (off) and then back to “ ” (on) before Speed Management System changes are recog- nized by the vehicle.
Page 47: Light Switch
that the electric starter will not have EBU39410 Light switch “ ” enough power to crank the engine. If this should happen, remove the battery and re- charge it. EBU39431 Winch switch “ ” 1. Light switch “ ” Set the switch to “ ”...
Page 48: On-Command Drive Knob "2Wd/4Wd/Diff. Lock
 “DIFF. LOCK” (four–wheel drive with the EBU39121 On–Command drive knob differential gear locked): Power is supplied “2WD/4WD/DIFF. LOCK” to the front and rear wheels with the differ- ential gear locked. Unlike standard four– wheel drive, all wheels turn at the same speed regardless of traction.
Page 49: D-Mode Knob "Sport/Trail/Crawl
 Before changing the D-mode, be sure to EBU39740 D-mode knob stop the vehicle and take your foot off “SPORT/TRAIL/CRAWL” the accelerator pedal. Mode “TRAIL” Mode “TRAIL” offers smooth acceleration, linear engine response and strong engine braking. This mode is suitable for driving on tight trails or general driving.
Page 50: Suspension Mode Switch
EBU39891 EBU31413 Suspension mode switch Accelerator pedal 1 1 1 1. Suspension mode switch 1. Accelerator pedal This model is equipped with an electronically Press the accelerator pedal to increase en- adjustable suspension system. The damping gine speed and thus vehicle speed. Release force of both the front and rear shock absorb- the accelator pedal and spring tension will re- ers can be adjusted.
Page 51: Brake Pedal
EBU37650 Brake pedal When the brake pedal is pressed and then the accelerator pedal is pressed, the brake over- ride system will not engage. EBU35642 Parking brake lever 1. Brake pedal Press the brake pedal to slow and stop the vehicle.
Page 52: Drive Select Lever
To release the parking brake, pull slightly on The drive select lever is used to shift the the lever, press the release button, and then transmission into the low, high, neutral, and push the lever to its original position. reverse positions. (See page 7-3.) EBU39450 ...
Page 53: Fuel Tank Cap
Remove the fuel tank cap when refueling. To open, turn counterclockwise. When finished When driving under heat-stress conditions, it refueling, install the fuel tank cap by screwing is recommended to reduce throttle at regular it down clockwise. intervals to allow the V-belt to cool. EBU37390 ECB03900 Doors...
Page 54: Passenger Seat Cushion
1 1 1 1. Handle 1. Passenger seat cushion 2. Door To install the seat cushion, insert the projec- tions on the rear of the seat cushion under the EBU37600 Passenger seat cushion seat frame, and then insert the projection on To remove the passenger seat cushion, lift the front of the cushion into the grommet the front of the cushion, and then pull the...
Page 55: Adjusting The Driver Seat Position
2 2 2 1. Driver seat position adjusting lever EBU34993 2. Driver seat Adjusting the driver seat position The driver seat position can be adjusted to suit the driver’s preference. WARNING! Nev- Adjust the driver seat position and make sure er adjust the seat position while operating it is locked in place before starting off.
Page 56: Adjusting The Steering Wheel Position
EBU35002 Adjusting the steering wheel position Adjust the steering wheel position before The steering wheel position can be adjusted starting off. to suit the driver’s preference. WARNING! Never adjust the steering wheel position EBU36953 while operating the vehicle, otherwise the Rearview mirror steering wheel may suddenly change posi- tion, which may lead to an accident.
Page 57: Seat Belts
EBU36184 EBU31503 Seat belts Glove compartment 1 1 1 1. Push and open. Always wear the seat belts properly while rid- Store lightweight or frequently used items, ing in the vehicle. (See page 8-5.) such as your driving gloves or vehicle docu- ments, in this compartment.
Page 58: Storage Compartments
ECB02071 ECB02241 NOTICE NOTICE To protect from damage, do not put metal To protect from damage, do not put metal items, like tools, or sharply edged items di- items, like tools, or sharply edged items di- rectly in the glove compartment. If they rectly in the storage compartment.
Page 59: Cup Holders
EWB03240 WARNING  Never ride with any open or glass con- tainers in the cup holders; otherwise, the contents may spill and the glass contain- ers may be thrown about and break, and 1 1 1 possibly injure people in the vehicle dur- ing sudden braking or an accident.
Page 60: Cargo Bed
1 1 1 1. Cup holder 1. Cargo hook EBU37880 Cargo bed EWB03250 WARNING  Never carry passengers in the cargo bed.  Do not exceed the specified maximum load limits. Heavier cargo could cause loss of control because of improper weight balance.
Page 61 For additional loading information, see page To close 7-8. Lift the tailgate to the original position, and then push the tailgate to securely lock it in Opening and closing the tailgate place. Lifting and lowering the cargo bed 2 2 2 1.
Page 62: Front And Rear Shock Absorber Assemblies
To lower EWB00401 WARNING With hands and fingers clear of pinch points, Always adjust the shock absorber assem- lower the cargo bed slowly to its original po- blies on the left and right side to the same sition and be sure it is locked into place. setting.
Page 63 Maximum (hard): Distance A = 496.3 mm (19.54 in)  A special wrench can be obtained at a Yamaha dealer to make this adjustment.  The spring preload setting is determined by measuring distance A, shown in the illustra- tion. The shorter distance A is, the higher the spring preload;...
Page 64 [ECB00082] poor damping performance.  Do not dispose of a damaged or worn Tightening torque: out shock absorber assembly yourself. Locknut: Take the shock absorber assembly to a 41 N·m (4.1 kgf·m, 30 lb·ft) Yamaha dealer for any service. 5-33...
Page 65: Winch
away. Use hook strap to keep hands away EBU38930 Winch from fairlead when winding the winch rope. ECBM0051 NOTICE Prolonged winching can overheat the 1 1 1 winch motor and can drain the vehicle’s battery, even when the engine is idling. Al- low the winch motor to cool and the bat- tery to recharge between uses.
Page 66: Trailer Hitch Bracket And Receiver
This vehicle is equipped with a trailer hitch bracket and a 2" (5 cm) receiver for a stan- dard trailer hitch. Trailer towing equipment can be obtained at a Yamaha dealer. See page 7-8 for loading information. 1. USB jack...
Page 67 This vehicle is equipped with a 12-V DC jack in the dashboard.  Turn off the accessory before plugging in- This vehicle also has a 5-V USB jack in the to/unplugging from the jack. center console.  When the auxiliary DC jack is not being used, cover it with the cap.
Page 68: Auxiliary Dc Connectors
Yamaha Adventure Pro powered by ® Magellan This vehicle is equipped with auxiliary DC connectors. Consult your Yamaha dealer be- This vehicle is equipped with Yamaha Adven- ® fore installing any accessories. ture Pro powered by Magellan . Read the Yamaha Adventure Pro Owner’s Manual for...
Page 69: For Your Safety - Pre-Operation Checks
Failure to inspect or maintain the vehicle properly increases the possibility of an accident or equipment damage. Do not operate the vehicle if you find any problem. If a problem can- not be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Pre-operation checklist ITEM...
Page 70 ITEM ROUTINE PAGE 6-6, 6-6, 6-6, 9-21, • Check front differential, transmission case, and rear final Drivetrain gear for leakage. 9-25, 9-27 • Check coolant level in reservoir. Coolant 6-6, 9-29 • Fill with coolant if necessary. Accelerator pedal • Check free play and for proper operation. Seat belts •...
Page 71: Front And Rear Brakes
Apply the brakes firmly for one minute. If there  Check that there is no free play in the brake is any leakage, have the vehicle inspected by pedal. If there is free play, have a Yamaha a Yamaha dealer. dealer check the brake system. (See page 9-43.)
Page 72 EWB02522 EWB02532 WARNING WARNING Gasoline and gasoline vapors are ex- Gasoline is poisonous and can cause inju- tremely flammable. To avoid fires and ex- ry or death. Handle gasoline with care. plosions and to reduce the risk of injury Never siphon gasoline by mouth. If you when refueling, follow these instructions.
Page 73: Engine Oil
If you carry a portable fuel container in the  Do not use oils with a diesel specifica- bed of your Yamaha Wolverine RMAX2, be tion of “CD” or oils of a higher quality sure to secure it with the cap tightened before than specified.
Page 74: Transmission
Wash off any dirt or mud that EBU36030 Differential gear could affect operation. Have a Yamaha dealer Make sure there is no oil leaking from the dif- repair as necessary for proper operation. ferential gear case.
Page 75: Passenger Handhold
Take the ve- resulting in serious injury or death in a crash. hicle to a Yamaha dealer or refer to the Servi- To help make sure your restraint systems are ce Manual for correct tightening torque.
Page 76 Tire pressure improper tire pressure may cause severe injury or death from loss of control or roll- over. Tire pressure below the minimum specified could also cause the tire to dis- lodge from the rim under severe driving conditions. [EWB04120] 1.
Page 77 Tire inspection OPERATING TIRE PRESSURE (cold): VEHICLE LOAD of 0.0–200.0 kg (0–441 lb) FRONT: (Recommended) 100.0 kPa (1.000 kgf/cm², 14.0 psi) REAR: (Recommended) 100.0 kPa (1.000 kgf/cm², 14.0 psi) Front: (Minimum) 90.0 kPa (0.900 kgf/cm², 13.0 psi) Rear: (Minimum) 90.0 kPa (0.900 kgf/cm², 13.0 psi) VEHICLE LOAD of 200.0–570.0 kg (441–...
Page 78: Operation
If any abnormality is noticed EBU31890 during this period, consult a Yamaha dealer. Engine break-in There is never a more important period in the 0–10 hours:...
Page 79: Starting The Engine
If a warning or indicator light does not Do not turn the key to the “ ” (start) position work as described above, have a Yamaha with the engine running; otherwise, damage dealer check the vehicle. to the electric starter may result.
Page 80: Drive Select Lever Operation And Reverse Driving
2. Apply the brake pedal, then shift by mov- ing the drive select lever along the shift  Engine power is restricted when the engine guide. Make sure that the drive select le- is too cold. (See page 5-4.) ver is completely shifted into position. ...
Page 81 This includes when crossing difficult white. If the lights do not come on, ask terrain such as rocky surfaces, deep mud, a Yamaha dealer to inspect the electri- water, or when towing. cal circuits.  Due to the synchronizing mechanism in...
Page 82 1. Drive select lever 2. L (Low-range) 3. H (High-range) 4. N (Neutral) 5. R (Reverse) 4. Release the parking brake, if applied. 5. Check behind the vehicle for people or obstacles, and then release the brake pedal. 6. Press the accelerator pedal gradually and continue to watch to the rear while back- ing.
Page 83: On-Command Drive Knob
EBU39151 On-Command drive knob The vehicle handles differently in each of the drive modes (“2WD”, “4WD” and “DIFF. LOCK”). For example, the vehicle requires more effort to turn in “DIFF. LOCK” than in “2WD”. Always stop the vehicle before changing the position of the On-Command drive knob. The meter display changes according to the selected drive mode.
Page 84  When using the differential gear lock (“DIFF. LOCK”), the differential gear lock indicator light and the drive train icon will flash until the differential gear lock properly engages/disengages.  When the differential gear lock indicator light and the drive train icon are flashing, turning the steering wheel back and forth will help the differential gear lock to engage or disengage.
Page 85: Parking
EBU31930 EWB04260 Parking WARNING When parking, stop the engine and shift the Improper loading or towing can increase drive select lever into the neutral position. Ap- the risk of loss of control, an overturn, or ply the parking brake to help prevent the ve- other accident: hicle from rolling.
Page 86 Operating when loaded with cargo or tow- MAXIMUM LOAD LIMITS ing a trailer Cargo bed: Drive more slowly than you would without a 272.0 kg (600 lb) Pulling load (gross trailer weight): load. The more weight you carry, the slower 8888 N (907 kgf, 2000 lbf) you should go.
Page 87 Pulling something other than a trailer Yamaha recommends that loads be trans- ported in the bed or in a trailer. If you need to move an object a short distance use a winch and follow the winch manufacturer’s instruc- tions.
Page 88: Basic Guide For Safe Use
EBU31950 EBU39760 KNOW YOUR VEHICLE BASIC GUIDE FOR SAFE USE This off-road vehicle will handle and maneu- ver differently from cars, ATVs, go-carts, EBU31962 golf-cars and grounds-keeping vehicles. The As a Wolverine RMAX2 owner you are re- Wolverine RMAX2 has higher ground clear- sponsible for the safe and proper operation of ance and other features to handle rugged this vehicle.
Page 89  The driver must be able to place both feet As the owner/operator, it is your responsibility to protect yourself and your passenger from flat on the floorboard while seated upright accidents, including rollovers. The Wolverine with his/her back against the backrest. ...
Page 90 Passenger requirements Occupant protection system This vehicle is designed for the operator and EWB03350 WARNING one passenger. Allowing passengers to ride Do not make changes to the occupant pro- improperly can lead to serious injury or death. tection system. If you install aftermarket As the operator, you are responsible for your products or have your vehicle modified, passenger.
Page 91 Protective structure The vehicle cage/frame provides a protective structure that helps limit intrusions by branch- es or other objects and may reduce your risk of injury in accidents. The protective structure will not protect occupants in all rollovers or accidents. Body parts outside of vehicle can be struck by passing objects or crushed during vehicle rollover.
Page 92 Seat belts A crash can damage the restraint systems in Seat belts should be worn by the driver and your vehicle. A damaged restraint system passenger. The driver must be sure that the may not properly protect the person using it, passenger is belted before driving.
Page 93 1. Hold the latch plate as you pull the belt across your lap and chest. Make sure the belt is not twisted and is not caught on any portion of the vehicle, your clothing, or any equipment you are carrying. 2.
Page 94 6. Check if the seat belt shoulder position reason in a rollover. The doors may also re- suits the size of the driver and passenger. duce intrusion of objects into the occupant To adjust the seat belt shoulder position, area. Make sure the door is securely latched move the seat belt height adjuster left before operation.
Page 95 helps to reduce the likelihood that the pas- senger puts a hand outside the vehicle if the vehicle begins to tip. The driver should make sure the passenger is holding onto the handhold with both hands before operating the vehicle. 1.
Page 96 could briefly jerk in one direction or back and forth as the tires and vehicle respond to the obstacle. This quick motion could injure your thumbs or wrist if your thumbs or hand(s) are inside the steering wheel. Grip the steering wheel so that your thumbs will not be hit by the spokes.
Page 97: Learning To Operate Your Vehicle
EBU33544 LEARNING TO OPERATE YOUR VEHI- CORRECT GRIP EXAMPLE Personal protective equipment INCORRECT GRIP EXAMPLE 1. Approved motorcycle helmet 2. Eye protection 3. Long-sleeved shirt or jacket 4. Gloves 5. Long pants 6. Over-the-ankle boots The driver and passenger should wear the fol- lowing to reduce risk of injury in an accident: ...
Page 98  Eye protection (goggles, helmet face shield, Practice for new Yamaha Wolverine or protective eyewear) RMAX2 users  Over-the-ankle boots, gloves, long-sleeved You should become familiar with the perfor- shirt or jacket, and long pants mance characteristics of the vehicle in a lar-...
Page 99 Getting ready to ride Perform the Pre-Operation Checks on page 6-1. Follow the instructions starting on page 7-2 to start the engine. Turning Use care in turns – turning the steering wheel too far or too fast can result in loss of control or a rollover.
Page 100 For example, if you feel the back of the vehi- accelerator pedal slowly and smoothly. The cle start to slide to your right, steer to the centrifugal clutch will engage and the vehicle right. will begin to accelerate. If you think or feel that the vehicle may tip or Avoid higher speeds and sudden or hard ac- roll, keep your body completely inside the celeration until you are thoroughly familiar...
Page 101 Engine braking Parking on a flat area Engine compression braking is designed to When parking on a flat area, stop the engine assist you when operating your Wolverine and shift the drive select lever into the neutral RMAX2 off-road. With this feature, the engine position.
Page 102 5. Block the front and rear wheels with Your Yamaha Wolverine RMAX2 has higher rocks or other objects. ground clearance and other features to han- dle rugged terrain, and as a result, can over- Loading turn in situations where some vehicles may The total weight of operator, passenger, ac- not.
Page 103 to see far enough ahead of you. Use common side of a hill, which increases your risk of roll- sense and remember that some hills are too over. Practice first on gentle slopes before at- steep for you to climb or descend. Use proper tempting steeper hills.
Page 104 slow your descent. Release the brake and be- If you are sliding or skidding, try to steer in the gin to coast down the hill. Use engine braking direction the vehicle is sliding, to regain con- as much as possible, gently applying the trol.
Page 105 Pavement Wet brakes may have reduced effectiveness. This vehicle is designed for off-road use only. After leaving the water, test the brakes. If nec- Avoid paved surfaces. Turn gradually and go essary, apply the brakes several times to let slowly if you must drive on pavement. friction dry them out.
Page 106 drive before driving on a slippery surface and the risk of fire during operation or after leaving plan your path to avoid making abrupt ma- the vehicle, do not let brush, grass and other neuvers. materials collect under the vehicle, near the If you feel the vehicle begin to slide sideways muffler or exhaust pipe, or next to other hot or fishtail (rear-wheel sliding), steer into the di-...
Page 107 If there is any question about your ability to maneuver safely over the obstacle, you should turn around if the ground is flat and you have the room or back up until you find a less difficult path. 8-20...
Page 108: Periodic Maintenance And Adjustment
If you are not familiar with vehicle before touching them. service, have a Yamaha dealer perform the service. EBU39930 Owner’s Manuals and Tool kit Store this manual and the:...
Page 109  Winch Owner’s Manual  Yamaha Adventure Pro Owner’s Manual  SSV Works MRB3 User Guide in a vinyl bag and always carry them in the glove compartment as shown. Put the tool kit and tire pressure gauge in the storage com- partment.
Page 110 Yamaha dealer to check the torque settings and adjust them as necessary.
Page 111: Maintenance Charts
Even if the vehicle isn’t driven for the stated mileage or engine hours, the month maintenance intervals should still be followed. Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. EBU35772...
Page 112 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours • Check for leakage. • Check for looseness and tighten all screw √ √ √ Exhaust system clamps and joints if necessary. •...
Page 113 EBU35803 General maintenance and lubrication chart INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours • Check coolant leakage. √ √ √ √ √ • Repair if necessary. Cooling system •...
Page 114 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours √ √ √ √ √ • Check oil level. Differential gear √ √ • Change. • Check operation/brake pad wear/fluid leak- age.
Page 115 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours • Check balance, runout and for damage. √ √ √ √ 15 * Wheels • Replace if necessary. • Check bearing assemblies for loose- √...
Page 116 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours Fittings and fas- • Check all chassis fittings and fasteners. √ √ √ √ √ 23 * • Correct if necessary. teners EBU39510 ...
Page 117: Hood
EBU32340 Hood To remove 1. Pull the tab on each hood lock up, and then turn the hood locks 1/4 turn clock- wise. 1. Tab 1 1 1 2. Hood lock 2. Remove the hood. 1. Tab 1. Hood 9-10...
Page 118: Engine Oil And Oil Filter
To install EBU39771 Engine oil and oil filter 1. Insert the projections on the hood into the Check the engine oil level regularly. In addi- slots in the front grill, and then place the tion, the oil must be changed and the filter re- hood in the original position.
Page 119 To check the engine oil level 1. Park the vehicle on a level surface. 2. Start the engine and warm it up to a nor- mal operating temperature (the engine oil temperature should reach 60 °C [140 °F]), then let the engine idle for a minimum of 10 seconds before turning the engine off.
Page 120 To change the engine oil 6. Remove the engine oil tank drain bolt and 1. Park the vehicle on a level surface. its gasket to drain the engine oil from the 2. Start the engine, warm it up for several oil tank.
Page 121 1. Trough 1. Engine oil drain bolt 2. Gasket 7. Place an oil pan under the engine to col- 9. Place an oil pan under the oil cooler drain lect the used engine oil. to collect the used engine oil. 8.
Page 122 12. Add 1.50 L (1.59 US qt, 1.32 Imp.qt) of the recommended engine oil to the en- gine oil filler hole on the cylinder head. 13. Add 2.05 L (2.17 US qt, 1.8 Imp.qt) of the recommended engine oil to the oil tank. 14.
Page 123 17. Turn the engine off and wait for 10 minu- 2. Lift the cargo bed up. tes. 3. Remove the right rear panel by removing 18. Remove the engine oil tank filler cap, and the bolts and quick fastener screws as then add sufficient oil of the recommend- shown.
Page 124 If the O-ring remains attached to 1. Bolt A the crankcase, oil leakage may occur. 2. Bolt C An oil filter wrench is available from a Yamaha dealer. 1 1 1 1. Bolt A 9-17...
Page 125 1. Oil filter wrench 1. O-ring 2. Oil filter cartridge 7. Install the new oil filter cartridge with an 6. Apply a light coat of clean engine oil to oil filter wrench, and then tighten it to the the O-ring of the new oil filter cartridge. specified torque with a torque wrench.
Page 126 1. Torque wrench 1. Right rear panel 2. Bolt A 8. Install the drain bolts, and then add the 3. Bolt B specified amount of the recommended 4. Quick fastener screw engine oil. Check the engine oil level and the vehicle for oil leakage. Refer to steps 11–21 of the “To change the engine oil”...
Page 127: Why Yamalube
EBU38630 1. Bolt A Why Yamalube 2. Bolt C YAMALUBE oil is a Genuine YAMAHA Part born of the engineers’ passion and belief that engine oil is an important liquid engine com- ponent. We form teams of specialists in the...
Page 128: Transmission Oil
ECB02910 NOTICE and value. Yamaha’s experience gained over When checking or changing the transmis- many years of research and development into sion oil, make sure that no foreign material oil since the 1960’s helps make Yamalube the enters the transmission.
Page 129 1 1 1 1. Rubber cover 1. Transmission oil dipstick 2. Maximum level mark 4. Remove the transmission oil dipstick and 3. Minimum level mark wipe it clean. 5. With the arrow mark pointing outward, fully insert the dipstick into the oil filler hole and then remove it again.
Page 130 9. Install the passenger seat cushion. To change the transmission oil 1. Place an oil pan under the transmission case to collect the used oil. 2. Remove the transmission oil dipstick. 3. Remove the transmission oil drain bolt and gasket. 1.
Page 131: Continuously Variable Transmission (Cvt)
Oil will flow out immediately when the drain bolt is loosened. Take care not to lose the bolt. 4. After draining the oil, install the transmis- sion oil drain bolt with a new gasket. 5. Tighten the drain bolt to the specified torque.
Page 132: Final Gear Oil
Yamaha dealer perform this main- ECB03590 NOTICE tenance. More frequent inspections are rec- When checking or changing the final gear ommended if you often drive hard or operate oil, make sure that no foreign material en- in severe conditions.
Page 133 Tightening torque: Final gear oil filler bolt: 23 N·m (2.3 kgf·m, 17 lb·ft) Changing the final gear oil 1. Park the vehicle on a level surface. 2. Place an oil pan under the final gear case to collect the used oil. 3.
Page 134: Differential Gear Oil
4. Install the drain bolt and its new gasket, EBU36065 Differential gear oil and then tighten the bolt to the specified Check the oil level and change the differential torque. gear oil at the intervals specified in the period- ic maintenance chart. Tightening torque: ECB03600 Final gear oil drain bolt:...
Page 135 2. Remove the differential gear oil filler bolt 5. Install the differential gear oil filler bolt and its gasket, and then check the oil lev- and its gasket, and then tighten the bolt el. It should be up to the brim of the filler to the specified torque.
Page 136: Coolant
7. Install the differential gear oil filler bolt and its gasket, and then tighten the bolt to the specified torque. Tightening torque: Differential gear oil filler bolt: 23 N·m (2.3 kgf·m, 17 lb·ft) 8. Check for oil leakage. If oil leakage is found, check for the cause.
Page 137 If genuine Yamaha coolant is not available, use an ethylene glycol antifreeze containing corrosion inhibitors for aluminum engines and mix with distilled water at a 1:1 ratio. ECB02190 NOTICE Mix antifreeze with distilled water only. However, if distilled water is not available, 1.
Page 138: Axle Boots
7. Install the hood. To change the coolant The coolant must be changed at the intervals specified in the periodic maintenance chart. Have a Yamaha dealer change the coolant. WARNING! Never attempt to remove the radiator cap when the engine is hot. [EWB04250]...
Page 139: Checking The Spark Plugs
If any spark plug shows a dis- tinctly different color, the engine could be op- erating improperly. Do not attempt to diagnose such problems yourself. Instead, 1. Spark plug gap have a Yamaha dealer check the vehicle. 9-32...
Page 140: Air Filter Maintenance
cause the rubber seal on the end of the cap Spark plug gap: fits tightly. To remove the spark plug cap, 0.7–0.8 mm (0.028–0.031 in) simply twist it back and forth while pulling Clean the surface of the spark plug gasket it out;...
Page 141 The primary air filter should be cleaned and gine wear and possible engine damage. oiled every 300–600 km (200–400 mi). Additionally, the fuel injection system The secondary air filter should be replaced would be affected, resulting in poor engine every 2000–5000 km (1200–3000 mi). performance and possible overheating.
Page 142 1 1 1 1. Foam air filter 1. Air filter element lock plate 2. Foam air filter element 4. Pull off the air filter element lock plate, 3. Air filter frame and then remove the foam air filter ele- 5. Wash the foam material gently but thor- ment from the air filter frame.
Page 143 11. Pull the foam air filter element over its frame, and then install the lock plate. 12. Insert the primary air filter into the air filter case, and then install the air filter case cover by hooking the holders onto the air filter case.
Page 144: Air Filter Check Hoses
the air filter elements may be soiled. Clean the check hose and air filter case and check the 1 1 1 air filter elements. 1. Secondary air filter 1 1 1 2. Screw 4. Insert a new air filter element and tighten the screws.
Page 145: V-Belt Case Drain Plug
Do If water drains from the V-belt case after re- not start the engine while cleaning the ex- moving the drain plug, have a Yamaha dealer haust system. inspect the vehicle, as the water may affect other engine parts.
Page 146 1. Tailpipe bolt 1. Tailpipe 2. Spark arrester 2. Remove the tailpipe by pulling it out of 3. Gasket the muffler, and then remove the gasket. 4. Install the gasket, and then insert the tail- 3. Tap the tailpipe lightly, and then use a pipe into the muffler and align the bolt wire brush to remove any carbon depos- holes.
Page 147: Valve Clearance
Valve clearance damaged or if the lining thickness is less than The correct valve clearance changes with 1.0 mm (0.04 in), have a Yamaha dealer re- use, resulting in improper fuel/air supply or place the brake pads as a set.
Page 148: Checking The Parking Brake Pads
1. Lining thickness EBU37500 Checking the parking brake pads 1. Minimum level mark Have a Yamaha dealer check the brake pads for wear and damage, and if necessary, re- Specified brake fluid: DOT 4 place them as a set. EWB02721...
Page 149: Brake Fluid Replacement
Adding a brake fluid other than DOT 4 the brake system for leakage. If the brake fluid may result in a harmful chemical reac- level goes down suddenly, have a Yamaha tion. dealer check and repair the vehicle before  Be careful that water does not enter the any further operation.
Page 150: Checking The Brake Pedal
 Replace the brake hoses every four years. EBU32531 Checking the brake pedal Have a Yamaha dealer check the brakes at the intervals specified in the periodic mainte- nance chart. There should be no free play in the brake pedal. The brakes should operate 1 1 1 smoothly and there should be no brake drag.
Page 151: Parking Brake Lever Free Play Adjustment
Yamaha dealer ad- just it. 1 1 1 1 1 1 1. Accelerator pedal 2. Accelerator pedal free play EBU39540 Parking brake lever free play adjust- 1. Parking brake lever free play...
Page 152: Cable Inspection And Lubrication
Cables can also become frayed or kinked. Lubricate the cable ends. If the cables do not operate smoothly, ask a Yamaha dealer to re- place them. 1. Brake light switch 2. Adjusting nut Recommended lubricant: If necessary, adjust the brake light switch.
Page 153: Pedal Lubrication
Have a Yamaha dealer replace the stabilizer bushes if necessary. Recommended lubricant: Lithium-soap-based grease EBU32590...
Page 154: Steering Shaft Lubrication
EBU32610 Recommended lubricant: Wheel removal Lithium-soap-based grease 1. Loosen the wheel nuts. 2. Elevate the vehicle and place a suitable EBU32600 Steering shaft lubrication stand under the frame. Lubricate the pivot points. 3. Remove the nuts from the wheel. 4. Remove the wheel. Recommended lubricant: Lithium-soap-based grease 9-47...
Page 155: Tire Replacement
Always use the same size and type of tires Size: recommended in this owner’s manual. The 30x10.00R14 NHS tires that came with your Yamaha Wolverine Manufacturer/model: RMAX2 were designed to match the perfor- MAXXIS/ML1/CANIVORE mance capabilities and to provide the best...
Page 156: Wheel Installation
EWB03400 WARNING If the battery seems to have discharged, re- Do not reverse the rims on your Yamaha charge it as soon as possible. Wolverine RMAX2 to widen the track EWB03410 width. Installing wheels improperly in-...
Page 157 INTERNAL: Drink large quantities of water or milk. Follow with milk of magnesia, beaten egg, or vegetable oil. Get prompt medical attention. EYES: Flush with water for 15 minutes and get prompt medical attention. EWB03420 WARNING Batteries may produce explosive gases. Ventilate when charging or using in a 1.
Page 158  Always keep the battery charged. Stor- manufacturer’s instructions, or have a ing the battery in a discharged state for Yamaha dealer charge it for you. an extended period of time will cause  Keep in mind that the battery tends to dis- permanent battery damage.
Page 159: Jump-Starting
the battery, the main switch must be EBU32651 Jump-starting off, and the positive lead must be con- Jump-starting the vehicle should be avoided. nected before the negative lead. [ECB01111] The battery should be removed and charged instead. However, if the vehicle must be jump-started, proceed as follows.
Page 160 vehicle and the other end of the positive lead to the positive terminal of the charged battery. 1 1 1 1 1 1 1. Jumper cable negative lead 5. Start the engine. (See page 7-2.) 6. After the engine starts, disconnect the 1.
Page 161: Fuse Replacement
EBU32665 Fuse replacement The fuses are located under the hood. If an electrical problem is suspected, check the fuses and replace if necessary. 2 3 4 3 3 3 5 6 7 8 9 10 1. Spare fuse 2. Accessory fuse “ACC” 3.
Page 162 1. Turn off all electrical systems. (See page Specified fuses: 5-1.) Main fuse: 2. Remove the hood. (See page 9-10.) 50.0 A Fuel injection system fuse: 3. Remove the blown fuse, and then install a 10.0 A new fuse of the specified amperage. Headlight fuse: WARNING! Always use a fuse of the 7.5 A...
Page 163: Headlights
There are no user replaceable bulbs. If one or more headlights do not come on, check for a loose connection, check the headlight fuse, and then have a Yamaha dealer check the ve- 1 1 1 hicle.  When the headlights are set to low beam, the outer two headlights come on.
Page 164: Auxiliary Lights
Auxiliary lights This model is equipped with LED auxiliary lights, there are no replaceable bulbs. If an auxiliary light does not come on, check for a loose connection, check the fuses, and then have a Yamaha dealer check the vehicle. 9-57...
Page 165: Brake/Tail Light
If your vehicle When the transmission is shifted into reverse, requires any repair, take it to a Yamaha deal- a white reverse light should come on. The skilled technicians at a Yamaha dealer-...
Page 166 EWB03450 WARNING When checking the fuel system, do not smoke and make sure there are no open flames or sparks in the area, including pilot lights from water heaters or furnaces. Gasoline or gasoline vapors can ignite or explode, causing severe injury or property damage.
Page 167: Troubleshooting Charts
Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
Page 168 Restart the engine. If the engine overheats again, ask a Level is OK. Yamaha dealer to inspect and/or repair the cooling system.  Tap water can be used in an emergency. Change to the recommended coolant as soon as possible.
Page 169: Cleaning And Storage
may have reduced stopping ability, in- EBU32720 CLEANING AND STORAGE creasing the chance of an accident. NOTICE: Excessive water pres- EBU35920 [EWB03471] Cleaning sure may cause water seepage and Frequent, thorough cleaning of your vehicle deterioration wheel bearings, will not only enhance its appearance but will brakes, transmission seals and electri- improve its general performance and extend cal devices.
Page 170: Storage
1. Fill the fuel tank with fresh fuel and add with a light film of oil. Do not apply oil to the specified amount of Fuel Med Rx, any rubber parts or the seat covers. available from your Yamaha dealer, or equivalent product. Follow the instruc- 10-2...
Page 171 30 °C [90 °F] or less than 0 °C [32 °F]). Use of Fuel Med Rx or another high-quality fuel stabilizer eliminates the need to drain the fuel system. Consult a Yamaha dealer if the fuel system needs to be drained. 10-3...
Page 172: Specifications
EBU32751 SPECIFICATIONS Dimensions: Cylinder arrangement: Inline Overall length: Number of cylinders: 3030 mm (119.3 in) 2-cylinder Overall width: Displacement: 1680 mm (66.1 in) 999 cm³ Overall height: Bore × stroke: 1975 mm (77.8 in) 93.0 × 73.5 mm (3.66 × 2.89 in) Seat height: Compression ratio: 882 mm (34.7 in)
Page 173 Recommended engine oil grade: Differential gear oil: API service SG type or higher, JASO standard MA Type: SAE 80W-90 API GL-5 Hypoid gear oil 130 °F Quantity: 0.31 L (0.33 US qt, 0.27 Imp.qt) Coolant quantity: SAE 0W-30 Coolant reservoir (up to the maximum level mark): 0.45 L (0.48 US qt, 0.40 Imp.qt) Radiator (including all routes): SAE 10W-30...
Page 174 Spark plug (s): Rear tire: Manufacturer/model: Size: NGK/LMAR8GI-8 30x10.00R14 NHS Spark plug gap: Manufacturer/model: 0.7–0.8 mm (0.028–0.031 in) MAXXIS/ML1/CANIVORE Clutch: Loading: Clutch type: Maximum load: Wet, centrifugal, shoe 570.0 kg (1256 lb) Drivetrain: (Total weight of all occupants, cargo, accessories, and tongue) Primary reduction ratio: Tire air pressure (measured on cold tires):...
Page 175 Minimum: Rear suspension: Front: Type: 90.0 kPa (0.900 kgf/cm², 13.0 psi) Double wishbone Rear: Spring: 210.0 kPa (2.100 kgf/cm², 30.0 psi) Coil spring Front wheel: Shock absorber: Rim size: Gas-hydraulic damper 14x6.5AT Wheel travel: Rear wheel: 429 mm (16.9 in) Electrical system: Rim size: 14x6.5AT...
Page 176 Meter lighting: Fuses: Main fuse: Neutral indicator light: 50.0 A Fuel injection system fuse: High beam indicator light: 10.0 A EPS fuse: Reverse indicator light: 40.0 A SCU fuse: Coolant temperature warning light: 15.0 A Headlight fuse: Engine trouble warning light: 7.5 A Signaling system fuse: Parking brake indicator light:...
Page 177: Consumer Information
EBU32775 CONSUMER INFORMATION EBU32820 EBU38940 Vehicle Emission Control Information Emission Regulation (California) label An add-on or modified part must be compli- The Vehicle Emission Control Information la- ant with applicable ARB evaporative emission bel is affixed at the location in the illustration. control standards.
Page 178 Privacy Policy. Privacy Policy https://yamaha-motor.com/privacy-policy Yamaha will not disclose this data to a third party except in the following cases. In addi- tion, Yamaha may provide vehicle data to a contractor in order to outsource services re- lated to the handling of vehicle data.
Page 179: Noise Regulation
EBU32830 NOISE REGULATION TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering in- operative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.
Page 180: Maintenance Record
EBU35842 MAINTENANCE RECORD Copies of work orders and/or receipts for parts you purchase and install will be required to do- cument maintenance done in accordance with the warranty. The chart below is printed only as a reminder to you that the maintenance work is required. It is not acceptable proof of mainte- nance work.
Page 181: Yamaha Motor Corporation, U.s.a. 2020 And Later Model Side-By-Side Limited Warranty
EBU32855 YAMAHA MOTOR CORPORATION, U.S.A. 2020 AND LATER MODEL SIDE-BY- SIDE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants THE CUSTOMER’S RESPONSIBILITY under this YAMAHA MOTOR CORPORATION, U.S.A. MAKES that new Yamaha Side-by-Side models purchased warranty shall be to: OTHER WARRANTY...
Page 182 Attention: Warranty Department 3. Each Yamaha Side x Side dealer is held responsible for his setup, service and war-ranty repair work. This will ensure that Yamaha Motor Corporation, U.S.A. has an up-to-date registration record in accordance with federal law.
Page 183: Yamaha Extended Service (Y.e.s.)
This excellent Y.E.S. plan coverage is only available to dealer to see how comfor ting uninterr upted factor y- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts.
Page 184 Yamaha. See your dealer today! A special note: YAMAHA EXTENDED SERVICE If visiting your dealer isn’t convenient, contact Yamaha with your Vehicle Identification Number. We’ll be happy to help you get the Y.E.S. coverage you need. Yamaha Service Marketing P.O. Box 6555...
Page 185: Index
INDEX Coolant, Pre-operation check ........6-6 Coolant temperature warning light ........ 5-4 Cup holders ..............5-28 Accelerator pedal ............5-19 Data recording, vehicle ..........12-1 Accelerator pedal, checking ........9-43 Differential gear lock indicator light ....... 5-3 Accelerator pedal, Pre-operation check ......6-6 Differential gear oil, Periodic maintenance ....
Page 186 Multi-function meter unit ..........5-7 Glove compartment .............5-26 Neutral indicator light ............. 5-2 Noise regulation ............12-3 Headlight beam, adjusting ...........9-56 Headlights ..............9-56 Helmet reminder light .............5-6 On-Command drive knob, operation ......7-6 High beam indicator light ..........5-3 Owner’s Manuals and Tool kit ........9-1 High-range indicator light ..........5-2 Hood ................9-10 Parking ................
Page 187 Vehicle identification number ........1-1 Warranty, extended ............. 12-7 Warranty, limited ............12-5 Wheel installation ............9-49 Wheel removal ............. 9-47 Winch ................5-34 Winch switch ............... 5-16 Yamaha Adventure Pro powered by Magellan® ..5-37 Yamalube ..............9-20 13-3...
Page 189 EBU32880 For your best ownership experience, think Genuine Yamaha! Genuine Yamaha Parts – Genuine Yamaha replacement parts are the exact same parts as the ones originally equipped on your vehicle, providing you with the performance and durability you have come to expect.
Page 190 PRINTED IN USA 2020.09-0.3×1 CR (E)

This manual is also suitable for:

Yxe10wplm

Yamaha WOLVERINE R MAX 2021 Manual

Quick Links

Troubleshooting

Related Manuals for Yamaha WOLVERINE R MAX 2021

Summary of Contents for Yamaha WOLVERINE R MAX 2021

This manual is also suitable for:

Table of Contents
