Goal Zero Lighthouse Core - Lantern & USB Power Hub Manual

GET TO KNOW YOUR GEAR

DEMO MODE
Take the Lighthouse CORE out of demo mode by plugging the built-in USB cable into a live USB port.

HOW IT WORKS

1. Take the Lighthouse CORE out of demo mode by plugging it into a live USB port with the built-in recharging cable.
2. Turn the dial on top of the Lighthouse CORE left or right for Dualite™ Directional Lighting and brightness options.
3. Recharge the Lighthouse CORE by plugging it into a live USB port with the built-in recharging cable.
4. Charge phones and boost tablets by plugging into the 1A USB output port.

TECHNICAL SPECIFICATIONS

Charge times:
Nomad 7	5-10 hrs
USB Source	5 hrs
Run time:
One Side Lit (low power)	350+ hrs
One Side Lit (high power)	8 hrs
Both Sides Lit (low power)	200+ hrs
Both Sides Lit (high power)	4 hrs
Battery:
Cell Chemistry	Li-ion NMC
Cell Capacity	16.3Wh (3.7V, 4400mAh)
Lifecycles	Hundreds of cycles
Shelf-life	Charge every 3-6 months
Fuses	None
Management System	Charging and low-battery protection built-in
Light:
LED (output)	Warm white LED 430 Lumens
Color Temperature	3,500 Kelvin
Ports:
USB Port (output)	5V, up to 1A (5W max), regulated
USB Port (input)	5V, up to 1A (5W max)
General:
Chainable	No
Weight	0.8 lbs (351 g)
Dimensions	5 x 4.5 in (12.7 x 11.4 cm)
Operating Usage Temp.	32-104 F (0-40 C)
Certs
Warranty	12 months

Be sure to register your product at goalzero.com/support
