VENTILATION
SYSTEM
INSTALLATION
RESIDENTIAL SERIES
• Do not try to install it yourself without proper qualifications.
• For safe and correct installation of the device, first read carefully all the information
concerning safety measures and rules.
• Improper installation voids warranty service.
• PRANA is not responsible for the installation performed by an unqualified specialist (group)
and all subsequent consequences.
MODEL RANGE: PRANA 2022 ®
Use the QR code or visit the website: prana.help/b22 to view
information about the device, user manual and other useful
information.
GB
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for prana RESIDENTIAL Series
Summary of Contents for prana RESIDENTIAL Series
- Page 1 • For safe and correct installation of the device, first read carefully all the information concerning safety measures and rules. • Improper installation voids warranty service. • PRANA is not responsible for the installation performed by an unqualified specialist (group) and all subsequent consequences. MODEL RANGE: PRANA 2022 ®...
-
Page 3: Table Of Contents
CONTENT WARNINGS AND SAFETY MEASURES ............4 MAIN INSTALLATION STEPS ............... 6 MAIN PRINCIPLES ..................7 ELECTRICITY CONNECTION ................. 14 FIRST START ....................15 POSSIBLE INSTALLATION ERRORS ..............16... -
Page 4: Warnings And Safety Measures
WARNINGS AND SAFETY MEASURES • This device may be used by children from the age of 8 years, as well as by physically or sensory disabled or mentally challenged persons or people with lack of experience and knowledge, provided that they are supervised or instructed about the safe operation of the device and understand the dangers involved. - Page 5 • It is necessary to make sure that the conditions, mechanical and electric installation norms applied in the country where the installation is performed are observed. • PRANA is not responsible for the installation performed by an unqualified specialist (group) and all subsequent consequences. Improper installation voids warranty service.
-
Page 6: Main Installation Steps
MAIN INSTALLATION STEPS The list of actions that must be performed for the correct installation of the PRANA ventilation system. All the necessary items are described in this manual. • Defining the mounting area • Fixing the drill at an angle (ensure the inclination of the hole outdoors) •... -
Page 7: Main Principles
The minimum distance to the flat surface (walls, ceilings, etc.) is 100 mm for the PRANA 160 series, and 150 mm for the PRANA 210 series. In order for the location of the recuperator to create a convection zone, it is necessary to provide free space in front of the system (do not cover with curtains, interior items, etc.). - Page 8 Air conditioner and recuperator work in the same room and complement each other: the first creates coolness, the second keeps it and supplies fresh air and vice versa if we talk about the cold season. If the recuperator is installed in the same room with the air conditioner, the recommended distance between these two devices should be provided so that both work effectively.
- Page 9 In order for the location of the recuperator to provide the correct convection zone, it is necessary: • Do not block the air exchange with curtains; • Interior items; • In other ways. Obstacles in the way of air inflow actually stop it, the pressure and flow rate approach zero level.
- Page 10 While installing in the recreation premises and sleeping areas, the systems should be installed on the opposite side from the zone of the permanent human presence. In the cold season, the temperature of the supply air flow will be lower than the indoor temperature.
- Page 11 Recuperator hole diameter, depending on model: • PRANA 160 series - hole not less than 162 mm; • PRANA 210 series - hole not less than 220 mm. To ensure the normal operation of the system, it is necessary that its housing, which faces the street, protrudes beyond the wall by 1-2 cm before the start of the air intake.
- Page 12 The through-hole should be made with a slope of 2-3° towards the street. The outer cover cannot be turned over. Do not cover the air intake grilles and the condensate drain hole. When planning the facade insulation of external walls, make sure to consider their thickness when determining the total length of the working module.
- Page 13 The condensate drain hole must be placed vertically downwards. The condensate heater is located at the bottom; its end is located in the hole of the condensate drain and should be at the lowest radial point.
-
Page 14: Electricity Connection
ELECTRICITY CONNECTION The ventilation system is connected to the power supply network with a voltage of ~ 230V and a frequency of 50 Hz. The connection of the ventilation system to the power supply network is provided by an electric cable (by default 30 cm), which is removed from the operating module. -
Page 15: First Start
FIRST START Before starting, check: • whether the connection to the power supply network is correct; • whether the air intake is open. Before switching on the system, open the air intake, accordingly, close it after use (if you do not want to use other modes of operation that involve closing the front cover of the recuperator). -
Page 16: Possible Installation Errors
POSSIBLE INSTALLATION ERRORS Consequences that may indicate incorrect installation of the PRANA ventilation system. • Non-compliance with the inclination of the installation: Condensate flows down the wall in the room; short circuit; failure of climate sensors and control systems. • Wrong condensate drain direction: Condensate flows down the wall in the room;... - Page 17 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _______________________________________________________...
- Page 18 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _______________________________________________________...
- Page 19 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _______________________________________________________...
- Page 20 МОДЕЛЬНИЙ РЯД: PRANA 2022 ®...
