CAUTION
!
!
These INSTRUCTIONS are for experienced operators. If you are not fully familiar with the principles
of operation and safe practices for arc welding equipment, we urge you to read our booklet, "Pre-
cautions and Safe Practices for Arc Welding, Cutting, and Gouging" Form 52-529. Do NOT permit
untrained persons to install, operate, or maintain this equipment. Do NOT attempt to install or
operate this equipment until you have read and fully understand these instructions. If you do not
fully understand these instructions, contact your supplier for further information. Be sure to read
the Safety Precautions on page 2 before installing or operating this equipment.
I.
INTRODUCTION
The ST-21 (Part No. 995950EU) is a rugged all purpose,
water-cooled, manual MIG welding torch designed to
operate at welding currents up to 600 amperes contin-
uous duty using all types of shielding gases. The torch
utilizes a pistol grip design for convenient start-stop
welding control and easy handling, and its in-line type
construction allows all service lines to enter through
the torch barrel.
The ST-21 is intended for use with ESAB wire feeders
which have provision for water cooling and will han-
dle all types of welding wires from .035-in. diameter
through 3/32-in. diameter including flux cored wires.
Manual Number: 0-5629
Revision Date: 02-23-2022
Revision Number: AA
Language: ENGLISH
ST-21
MIG WELDING TORCH
II.
DESCRIPTION
To provide maximum resistance to the abuses of day
to day service, the torch is of heavy duty construction
with all metal parts well insulated from current carrying
members. The in-line body and adjustable pistol grip
handle allows the ST-21 to be used in a variety of ap-
plications with easy maneuverability and comfortable
operation. The torch handle is easy to reposition along
the barrel to satisfy operator preference, and a trigger
lock incorporated in the grip enables the operator to
lock the trigger in a depressed position during long
welds.
To facilitate maneuverability, all service lines are inter-
nally connected to the torch body and exit from the
rear of the torch barrel.
The torch can use either threaded contact tips (long or
short) or slip-in contact tubes which are secured with
a collet nut supplied with the torch (see Table 2). The
contact tube can be quickly and easily replaced by un-
screwing the metal nozzle and collet nut, and removing
the tube. Five metal nozzles are available for use with
the ST-21; four for continuous fusion welding, and one
for spot welding applications. Nozzle sizes 8 and 10,
require a spatter liner. The water-cooling requirements
for the ST-21 are described in Section VI.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST-21 and is the answer not in the manual?

Questions and answers

Summary of Contents for ESAB ST-21

  • Page 1 The in-line body and adjustable pistol grip utilizes a pistol grip design for convenient start-stop handle allows the ST-21 to be used in a variety of ap- welding control and easy handling, and its in-line type plications with easy maneuverability and comfortable construction allows all service lines to enter through operation.
  • Page 2: Accessory Equipment

    Table 1- Nozzles Description Part No. A. REQUIRED No. 8 Nozzle* P/N 598739 The ST-21 requires a nozzle (see Table 1), nozzle spatter No. 10 Nozzle* P/N 598721 liner, and several wire feed accessories of the proper No. 10L Nozzle P/N 598891 size for the wire being used.
  • Page 3 Do not use equipment beyond its ratings. For example, Welders having pacemakers should consult their phy- overloaded welding cable can overheat and create a sician before welding. EMF may interfere with some fire hazard. pacemakers. After completing operations, inspect the work area Exposure to EMF may have other health effects which to make certain there are no hot sparks or hot metal are unknown.
  • Page 4 CYLINDER HANDLING -- Cylinders, if mishan- ADDITIONAL SAFETY INFORMATION -- For dled, can rupture and violently release gas. more information on safe practices for electric Sudden rupture of cylinder, valve, or relief arc welding and cutting equipment, ask your device can injure or kill. Therefore: supplier for a copy of “Precautions and Safe Practices for Arc Welding, Cutting and Gouging”, Form 52-529.
  • Page 5 2. Collet Nut Wrench, Part No. 996109 - Permits loos- Les étincelles et les projections de métal incandescent ening of the collet nut without removing nozzle. risquent de se loger dans les manches retroussées, les Particularly recommended when using the above rebords de pantalons ou les poches.
  • Page 6 un incendie ultérieurement. Employer des guetteurs tiques autour des câbles de soudage et l’équipement. d’incendie au besoin. Par conséquent : Pour plus d’informations, reportez-vous à la norme Un soudeur ayant un stimulateur cardiaque doit NFPA 51B, « Fire Prevention in Use of Cutting and Wel- consulter son médecin avant d’entreprendre une opé- ding Processes », disponible auprès de la National Fire ration de soudage.
  • Page 7 les mesures nécessaires pour améliorer la ventilation ENTRETIEN DE L’ÉQUIPEMENT -- Un équipe- l’aire de travail. Ne pas poursuivre l’opération si le ment entretenu de façon défectueuse ou malaise persiste. inadéquate peut Causer des blessures graves ou mortelles. Par conséquent : Consulter la norme Z49.1 ANSI/ASC (à...
  • Page 8 RENSEIGNEMENTS DE SÉCURITÉ SUPPLÉMEN- AWS C5.3 - « Pratiques recommandées pour le TAIRES -- Pour plus d’informations sur les gougeage et le coupage à l’arc au carbone ». pratiques sécuritaires pour les équipements AWS C5.5 - « Pratiques recommandées pour le de soudage et de coupage à...
  • Page 9: Installation

    INSTALLATION Conduits & Liners for ST-16 & ST-21 Water-Cooled GMAW Guns Wire Size Hard and Flux-Cored Wire Aluminum (Tweco 44 Series Liner) (PA liner with bronze conduit front) in. (mm) 15 ft. (5 m) 12 ft. (4m) .030 (0.8) 328P20404AST 1440-1103 .035 (0.9)
  • Page 10: Adjustment And Operation

    B. Liner installation process for PA liners (for Aluminum Wires) Figure 3a Figure 3b Figure 3c Insert the PA conduit liner through the Euro adapter nipple at the torch end and feed all the way through the front of the Torch tube. See Figure 3a. 1.
  • Page 11: Maintenance & Replacement Parts

    MAINTENANCE & REPLACEMENT PARTS If this equipment does not operate properly, stop work immediately and investigate the cause of the malfunction. Maintenance work must be performed by an experienced person, and electrical work by a trained electrician. Do not permit untrained persons to inspect, clean, or repair this equipment. Use only recommended replacement parts.
  • Page 12 C. NOZZLES Nozzle spatter will be minimal and will wipe off easily due to efficient nozzle cooling. If necessary, occasional tightly adhering spatter can be removed from the inside of nozzles with a hand reamer or file. Exercise care not to break the insulator (spatter) liner or that spatter does not drop back into the nozzle or contact tube.
  • Page 15 This Page Intentionally Blank...
  • Page 16 2800 Airport Road Denton, Texas, U.S.A. 76207 Phone: 1-800-426-1888 http://www.esabna.com ESAB AB operates a policy of continuous improvement. We therefore reserve the right to make changes and improvements to any of our products without notice. Customer // Technical Support (843) 664-4405...
