- Page 1 Operations Manual Model: DP2300PIP Automatic Dough Press formerly DOUGHPRO. New Name. Same Quality. Superior Service. proluxe.com...
- Page 2 Congratulations! conditions, to be free from manufacturing defects in material and Your selection of the Doughpro DP workmanship for a period of one year on is a sound business decision. Doughpro parts and labor from the invoice date. equipment is a result of the highest quality engineering and time-tested This warranty will be effective only design.
- Page 3 • To view the set points of temperature, timer and counter, WARNING Avoid touching hot surfaces press MODE button to view the while operating the machine. desired mode of operation. CAUTION 2. Changing Temperature: During normal operation, the • Press MODE button until base of the machine must be temperature is displayed.
- Page 4 back of the press and air lower platen. Doughpro offers compressor cabinet. its own food release spray NATURALLY CLEAR Model Note: The compressor portion of the No. DPPC1. (See our catalog machine has a separate on/off switch and price list for information.) located on the rear of the lower cabinet.
- Page 5 International Symbols Contact our factory or approved service agency (800) 624-6717 (U.S. only). Note: When contacting factory for information, parts or service instructions, it is of the utmost importance that the serial number of the machine be provided. This number can be found on the serial plate located on the rear of the machine.
- Page 6 DOUGHPRO DP2300 Automatic Air Press Trouble Shooting Guide Symptom Probable Cause Action to be Taken Ref. #'s on Explosion Drawing Power Button on Digital Controller Power Cord is not plugged in. Plug power cord into wall 's face is depressed but doesn’t turn receptacle and depress power button on controller Circuit Breaker is tripped off in the...
- Page 7 DOUGHPRO DP2300 Automatic Air Press Trouble Shooting Guide Symptom Probable Cause Action to be Taken Ref. #'s on Explosion Drawing If setpoint is reached but slighty off Offset may need to be calibrated and Must call (800) 624-6717 ext. 129 in temperature.
- Page 8 DP2300PIP AUTOMATIC PIZZA PRESS 4X 77 A2.1 A2.2 A1.6 A1.9 A1.5 A1.10 A1.5 A1.2 A1.3 A1.8 A1.11 A1.7 A1.12 A1.5 A1.4 A1.3 A1.2 A1.1 01/22/16 EXPDP2300PIP RD 30040 PAGE 1 OF 2...
- Page 9 A3.1 A3.5 A3.8 A3.9 A3.3 A3.13 A3.14 A3.10 A3.2 A3.6 A3.11 A3.12 A3.4 A3.7 A4.1 A5.5 A5.1 A5.3 A4.2 4X 70 A5.3 A5.6 A5.2 4X 68 A5.4 A6.3 A6.2 EXPDP2300PIP RD 30040 A6.1 4X PAGE 2 OF 2...
- Page 10 PART LIST FOR MODEL DP2300PIP ITEM DP2300PIPE DESCRIPTION 208 ~ AC HOUSING, MACHINING 11023002202 SCREW, SOCKET HEAD 1/4-20 x 1/2 SSH142012 CLAMP-ON SHAFT COLLAR 110230031 CLAMP, CABLE 1/2 CC12 CLAMP, CABLE 5/16 CC516 CLAMP, CABLE 3/8 CC38 DECAL LABEL FUSE 2 MIL MYLAR 1 COLOR BLACK...
- Page 11 PART LIST FOR MODEL DP2300PIP ITEM DP2300PIPE DESCRIPTION 208 ~ AC PISTON, COVER 11013 FITTING, AIR 1/8" PIPE x 1/4 AQ69P4X2 FITTING, AIR 1/8-90 AQ69P4X4 TUBING, BLACK AIR LINE 1/4 TPE4014 4.25ft RELAY, SOLID STATE MPR90217 SCREW, PAN HEAD PHILLIPS 8-32 x 1/4...
- Page 12 PART LIST FOR MODEL DP2300PIP ITEM DP2300PIPE DESCRIPTION 208 ~ AC A1.6 TERMINAL, QD 3/16 x 18-22 GA (PINK) 2280 A1.7 WASHER, SAE #6 WSAE6 A1.8 SCREW, PAN HEAD PHILLIPS 6-32 x 1/4 SP63214 A1.9 WIRE, TFE 14 GA GREEN WTFE14G A1.10 RTD SENSOR ASSEMBLY 110949110 A1.11 SCREW, SET 3/8-16 x 1/2"...
