- Page 2 Make sure there is a proper electrical wall outlet located within reach of the Proluxe equipment is a result of the cord and plug attached to the press. highest quality engineering and time- Then place the press in an area that tested design.
- Page 3 (A) Pull Pressing Handle for raising and lowering the upper platen. Proluxe shall not be liable for the This action forces the mating of injury, loss or damage, direct or the platens.
- Page 4 2. Counter – Cycle counter counts WARNING the number of applications from In case of power cord damage, 1 to 9999 (see additional Notes – do not attempt to repair or Counter). replace the power cord. Contact the manufacturer or the local 3.
- Page 5 Dough Pressing Operations SETTING CRUST THICKNESS CONTROL: *The thickness is determined by dough Press Only Press & Par Bake weight and temperature setting on each Dough Press Press Temp Temp Product Time Time platen. 150°F 325°F 7-15 Pizza both both seconds seconds platens...
- Page 6 ADDITIONAL NOTES: Temperature No. DPPC1. (See our catalog and price list for information.) Note Note: This spray will not affect Fahrenheit/Centigrade (Celsius) the taste of your crust in any Conversion way. The temperature controller can be programmed to display either 6.
- Page 7 International Symbols Preventative Maintenance Suggestions The Proluxe DP2010 machines are relatively maintenance free. For a long and trouble-free life, the following preventative maintenance should be followed: Daily Care: 1. Platens: These platens should only be cleaned with mild soap and warm water then wiped off with a clean, soft cloth or soft sponge.
- Page 8 DOUGHPRO DP2000 Trouble Shooting Guide Symptom Probable Cause Action to be Taken Power Button on Digital Controller Power Cord is not plugged in. Plug power cord into wall 's receptacle face is depressed but doesn’t turn and depress power button on controller Circuit Breaker is tripped off in the Reset circuit breaker that the Grill is...
- Page 9 DOUGHPRO DP2000 Trouble Shooting Guide Symptom Probable Cause Action to be Taken Heater Platen overheating If the Relay (depending the year of Replace Relay If the Controller's heat- the model) on the coil side are on LED is not lit indicating the receiving 12vdc indicates the controller is working properly.
- Page 10 72 2X EXPLOSION VIEW DP2010MBZ (MLBZ/MRBZ) 137 2X 07/22/19 122 4X 40 3X 115 2X 76 4X EXPDP2010MBZ RC 072219 CUSTOMER MANUAL PAGE 1 OF 2...
- Page 11 52 4X 52 4X INCLUDE PLATEN INSIDE CRATE 67 2X EXPDP2010MBZ RC 072219 CUSTOMER MANUAL PAGE 2 OF 2...
- Page 12 PROLUXE PARTS LIST FOR DP2010MBZ (MLBZ/MRBZ) DP2010MLBZE DP2010MRBZE ITEM # DESCRIPTION QTY. 208 ~ AC 208 ~ AC HOUSING, MACHINED 1101781542201 1101781542201 LOCK PLUG, 5/8" ID DP17502 DP17502 CABLE STRAIN RELIEF 3231 3231 SCREW, SOCKET FLAT HEAD,1/4-20 X 3/4 SF142034 SF142034 HANDLE SOCKET 11016650...
- Page 13 PROLUXE PARTS LIST FOR DP2010MBZ (MLBZ/MRBZ) DP2010MLBZE DP2010MRBZE ITEM # DESCRIPTION QTY. 208 ~ AC 208 ~ AC SOLID STATE RELAY MPR90217 MPR90217 MICRO SWITCH ROLLER WHEEL 1101017044 1101017044 SCREW, ROUND HEAD 4-40 X 5/8 SR44058 SR44058 WIRE HARNESS 11017815450 11017815450 SCREW, SOCKET HEAD 3/8-16 X 3/4...
- Page 14 PROLUXE PARTS LIST FOR DP2010MBZ (MLBZ/MRBZ) DP2010MLBZE DP2010MRBZE ITEM # DESCRIPTION QTY. 208 ~ AC 208 ~ AC ELECTROMAGNET, 12V 36W 600lbs. 11017815413 11017815413 SCREW, SET 1/4-20 X 1/4 SST142014 SST142014 BOLT HEX SLOTTED 8-32 X 1/4 BH83214 BH83214 WASHER, SAE 1/2 WSAE12 WSAE12...
- Page 15 PROLUXE PARTS LIST FOR DP2010MBZ (MLBZ/MRBZ) DP2010MLBZE DP2010MRBZE ITEM # DESCRIPTION QTY. 208 ~ AC 208 ~ AC SCREW, SET 1/4-20 X 1/2 SST142012 SST142012 EYELET END MACHINED 1101098154C5 1101098154C5 GAS SPRING, 30LB FORCE DP12810 DP12810 CLEVIS, STEEL DP12809 DP12809 CLEVIS PIN 1/4" DIA X 3/4" LONG...
- Page 17 Exclusions: 1. WOOD / GAS FIRED OVENS: PROLUXE warranty applies to the main body of the oven being steel / refractory and insulation shall be free from defects in materials and workmanship for a period of four years from the date of purchase. The gas equipment shall be free from defects in materials and workmanship for a period of one (1) year from the date of purchase.
