MODELS: HUDC3006, HUDC3010
Maximum Operating Pressure 10,000 PSI
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
©August 2017
HUDC5006, HUDC5010
HUDC10006, HUDC10010
HUDC15006, HUDC15010
SFA Companies
10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419
E-mail: sales@bvahydraulics.com
Aluminum Double Acting
Hollow Hole Cylinder
Instruction Manual
*
Fax: 816-448-2142
Website: www.bvahydraulics.com
HUDC3006-M0_082017
- 30 Ton Capacity
- 50 Ton Capacity
- 100 Ton Capacity
- 150 Ton Capacity
Advertisement
Table of Contents
Related Manuals for BVA Hydraulics HUDC3006
Summary of Contents for BVA Hydraulics HUDC3006
- Page 1 HUDC3006-M0_082017 Aluminum Double Acting Hollow Hole Cylinder Instruction Manual MODELS: HUDC3006, HUDC3010 - 30 Ton Capacity HUDC5006, HUDC5010 - 50 Ton Capacity HUDC10006, HUDC10010 - 100 Ton Capacity HUDC15006, HUDC15010 - 150 Ton Capacity SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153...
-
Page 2: Safety And General Information
BVA Hydraulics authorized service center. Owners 2. Verify that the product and the application are compatible. If in and operators of this equipment shall be aware that the use and doubt, call BVA Hydraulics Technical Service (888) 332-6419. -
Page 3: Installation
WARNING Failure to comply with the following warnings may Do not pull, position or move cylinder setup by the result in personal injury as well as property hose. Use carrying handle or other means of safe damage. transport. • Study, understand, and follow all instructions Do not handle pressurized hoses. -
Page 4: Specifications
1. Inspect hoses and connections daily. Replace damaged a period of 4 months, it should be connected to a pump and fully components immediately with BVA Hydraulics Replacement extended and then retracted a minimum of 5 times. This cycle will Parts only. -
Page 5: Troubleshooting Guide
MAINTENANCE (cont.) NOTICE: Do not attempt to grasp with pliers or wrench without first wrapping the jaws of such tool with rags or similar padding. How to bleed air from system: 1. Place pump at a higher elevation than the hose and cylinder as shown in Figure 2. - Page 6 (*) - indicates items included in, and available only as part of Repair Kit N/A - part is not available as replacement Note: To ensure safe and reliable performance, replace worn or damaged parts with BVA Hydraulics Authorized Replacement Parts only.
- Page 7 (*) - indicates items included in, and available only as part of Repair Kit N/A - part is not available as replacement Note: To ensure safe and reliable performance, replace worn or damaged parts with BVA Hydraulics Authorized Replacement Parts only.
- Page 8 (*) - indicates items included in, and available only as part of Repair Kit N/A - part is not available as replacement Note: To ensure safe and reliable performance, replace worn or damaged parts with BVA Hydraulics Authorized Replacement Parts only.
- Page 9 (*) - indicates items included in, and available only as part of Repair Kit N/A - part is not available as replacement Note: To ensure safe and reliable performance, replace worn or damaged parts with BVA Hydraulics Authorized Replacement Parts only.
-
Page 10: Limited Lifetime Warranty
This warranty does not cover ordinary wear and tear, overloading, alterations (including repairs or attempted repairs not performed by BVA Hydraulics or one of its authorized personnel), improper fluid use, or use of the product in any manner for which the product was not intended or the use of which is not in accordance with the instructions or warnings provided with the product. - Page 11 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 E-mail: sales@bvahydraulics.com...
- Page 12 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 E-mail: sales@bvahydraulics.com...
