- Page 1 BLACK SILVER KIL740-EUK KIL740-S-EUK KIL742-EUK KIL742-S-EUK KIL746-EUK KIL746-S-EUK KIL747-EUK KIL747-S-EUK KIL748-EUK KIL748-S-EUK KIL755-EUK KIL755-S-EUK 2015-07-23 #:150-9059-1...
- Page 2 WARNING ENG - Do not begin to install product until you have read and understood the instructions and warnings contained in this user guide. This product is designed to be installed on wood stud walls. Hardware is included for wood stud installation. Before installing make sure the supporting surface will support the combined load of the equipment and hardware.
- Page 3 Tools Needed for Assembly. ENG To properly tighten screws: Tighten until screw head makes contact, then tighten another 1/2 turn. Do not overtighten screws. +1/2 5/32" (4mm) 3/8" (10mm) 2015-07-23 #:150-9059-1...
- Page 4 Parts (Before beginning, make sure you have all parts shown below). A ( 1 ) B (4) C (4) back shroud M5 x 12 mm M5 x 25 mm D (4) E (4) M6 x 12 mm M6 x 25 mm F (4) G (4) M8 x 12 mm...
- Page 5 KIL740, KIL742 XX = 43.25, YY = 27.5 KIL746, KIL747, KIL748 XX = 48.25, YY = 30.25 KIL755 XX = 55.75, YY = 33.75 xx" yy" 2015-07-23 #:150-9059-1...
- Page 6 Mark mounting holes. 2.5" (64mm) 5/32" 5/32" (4 mm) (4mm) Drill four mounting holes. 2015-07-23 #:150-9059-1...
- Page 7 M (4) 2015-07-23 #:150-9059-1...
- Page 8 Center adapter brackets vertically on back of screen. Centre verticalmente los soportes en la pantalla. Centrez les supports à la verticale de l’écran. Richten Sie die Halterungen senkrecht mittig an der Bildschirm. Centreer de beugels verticaal op de van het scherm. centra le staffe verticalmente sul dello schermo.
- Page 9 2015-07-23 #:150-9059-1...
- Page 10 Note: Mounting Arm swings out to access Plug in fan power cord. For use with two adapter brackets and behind display pin sockets remove plug adapter J (2) 2015-07-23 #:150-9059-1...
-
Page 11: Limited Five-Year Warranty
LIMITED FIVE-YEAR WARRANTY Peerless Industries, Inc. (“Peerless”) warrants to original end-users of Peerless products will be free from defects in material and ® workmanship, under normal use, for a period of fi ve years from the date of purchase by the original end-user (but in no case longer than six years after the date of the product's manufacture). - Page 12 Peerless-AV Peerless-AV Europe Peerless-AV de Mexico 2300 White Oak Circle Unit 3 Watford Interchange, Ave de las Industrias 413 Aurora, IL 60502 Colonial Way, Watford, Herts, Parque Industrial Escobedo Email: tech@peerlessmounts.com WD24 4WP, United Kingdom Escobedo N.L Mexico 66050 Ph: (800) 865-2112...
