OPERATION AND INSTRUCTION MANUAL
Swivel Anchor Model: SWS100N
WARNING:
ALL PERSONS USING THIS EQUIPMENT MUST
READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD
BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST
BE PROPERLY INSTRUCTED ON HOW TO USE THE DEVICE. AVOID
CONTACT WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL,
ELECTRICAL, ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
Patent US # 8,424,638
V4.2-A
Advertisement
Table of Contents
Related Manuals for ClimbTech SWS100N
Summary of Contents for ClimbTech SWS100N
- Page 1 OPERATION AND INSTRUCTION MANUAL Swivel Anchor Model: SWS100N WARNING: ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
- Page 2 PURPOSE The SWS100N is an anchorage connector designed to function as an interface between the anchorage and a fall protection, work positioning, rope access, or rescue system for the purpose of coupling the system to the anchorage. Any references to “anchorage connector”...
- Page 3 LABEL LOCATIONS 180° 2.25”ø 8”ø (57.15mm) (203.2mm) 5.5” (139.7mm) 360° 3” 1” (76.2mm) (25.4mm) Minimum Breaking Strength (MBS): 5,000-lbf (22kN) Working Load (WLL): 1,000-lbs (454kg) Max Capacity: 310-lbs (140kg) Weight: 1.2-lbs (544.3g) Materials: Stainless Steel Regulatory Compliance: Meets or exceeds ANSI Z359.18 Type A, ANSI Z359.7-2011, OSHA 1926.502, OSHA 1910.66 LOADING CONDITIONS DIAGRAM LOAD...
- Page 4 CONCRETE MOUNTING - Use a proper drill & bit for concrete (SDS drill bit). - Drill a 7/8” (22mm) hole no less than 3” to 3.5“ (76mm-89mm) deep 9” (229mm) away from any edge. - Hole must be straight & perpendicular to surface. - Hole must be free of debris.
- Page 5 STEEL MOUNTING 5/8”-11 Torque Range: Lock Nut 75 ft-lbs * Use tapered washer with I-beams (100Nm) that have tapered flanges. 5/8” Lock Washer drill 5/8” (16mm)Ø 5/8”-11x4” Hex Bolt * .25” (6mm) * For steel applications, a grade-5, 8 (or equivalent) bolt no short- er than 4”...
- Page 6 *The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the arrest of a fall to a maximum of 8 kN (1800-lbf ). (ANCHOR POINT) WORK SURFACE *The structure the anchorage is attached to must be able to support 5,000-lbf (22kN) and installed...
- Page 7 KIT CONTENTS PART NUMBER SWS1SBA (Steel Mounting Hardware Kit) SWS100S (Swivel with Steel Mounting kit) SWS1DNC (Concrete Hardware Kit) SWS100C (Swivel with Concrete Mounting Kit) SWP100S-KIT (Weld-on Mounting Kit) DNC-TOOL (Concrete Anchor Tool) For more information:...
- Page 8 LIMITED REMEDY: Upon notice in writing, ClimbTech will repair or replace all defective items at ClimbTech’s sole discretion. ClimbTech reserves the right to require that the defective item be returned to its plant for inspection before determining the appropriate course of action. Warranty does not cover equipment damage resulting from wear, abuse, damage in transit, failure to maintain the product or other damage beyond the control of ClimbTech.
