180˚
8.0"ø
(203.2mm)
5.5"
(139.7mm)
360˚
PERFORMANCE:
REGULATORY COMPLIANCE:
Tensile Strength (UTS):
ANSI Z359.1-2007,
5,000-lbf (22kN)
ANSI Z359.7-2011,
Working Load: 1,000-lbs
OSHA 1926.502
(454kg)
DIMENSIONS:
COMPONENT MATERIALS:
Weight: 1.2-lbs
Zinc Plated Steel
STEEL MOUNTING: SWY050S
Torque :
45 ft-lbs
.5"-13 Lock Nut
(61 Nm)
.5" Lock
Washer
Use
tapered
.5"-13 x 4"
washer
Hex Bolt *
drill .5" (13mm)Ø
.25"
(6mm)
min
INSPECTION AND MAINTENANCE LOG
MODEL NUMBER:
2.25"ø
DATE OF MANUFACTURE:
(57.15mm)
Date
Part Number
3.0"
Inspection:
(76.2mm)
Official periodic inspection must be made at least semiannually. The inspection must
be performed by a qualified person other than the intended user. If severe weather or
conditions exist then inspections must be carried out more frequently. All inspection
results must be logged in the space provided above.
1. Inspect Swivel to make sure it is flush with mounting surface.
2. Make sure all labeling is affixed to the unit.
3. Inspect anchoring system for signs of damage or wear.
4. Make sure the unit can rotate 360° and D-ring can flip 180° side to side.
5. Record inspection results in the space provided above.
*If any damage that could affect the strength or operation of the device, or
unsafe conditions are found, proper disposal is required. Anchorage connector
must be rendered unusable and then properly discarded.
LABEL LOCATIONS
7303 Burleson Rd. Suite 901 Austin, TX 78744
1(512) 308-6440 / www.climbtech.com
Comments
Inspector Name
ClimbTech, LLC.
OPERATION AND INSTRUCTION
MANUAL
Swivel Anchor Model: SWY050N
WARNING:
ALL PERSONS USING THIS EQUIPMENT MUST
READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD
BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST
BE PROPERLY INSTRUCTED ON HOW TO USE THE DEVICE. AVOID
CONTACT WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL,
ELECTRICAL, ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
Patent # US 8,424,638
V2.5-A
Advertisement
Related Manuals for ClimbTech SWY050N
Summary of Contents for ClimbTech SWY050N
- Page 1 .5”-13 x 4” washer Hex Bolt * OPERATION AND INSTRUCTION MANUAL drill .5” (13mm)Ø Swivel Anchor Model: SWY050N WARNING: ALL PERSONS USING THIS EQUIPMENT MUST .25” READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO (6mm) SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
- Page 2 The anchorage connector must be inspected prior to each use for PURPOSE wear, damage, and other deterioration. If defective components are The SWY050N is an anchorage connector designed to function as an found the anchorage connector must be immediately interface between the anchorage and a fall protection, work positioning,...
