OPERATION AND INSTRUCTION MANUAL
Energy Absorbing Y-Lanyard Model: EAL12NC-72Y-C13
WARNING:
READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD
BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST
BE PROPERLY INSTRUCTED ON HOW TO USE THE DEVICE. AVOID
CONTACT WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL,
ELECTRICAL, ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
Patent # US 10,384,086 B2
ALL PERSONS USING THIS EQUIPMENT MUST
V1.0-A
Advertisement
Related Manuals for ClimbTech EAL12NC-72Y-C13
Summary of Contents for ClimbTech EAL12NC-72Y-C13
- Page 1 OPERATION AND INSTRUCTION MANUAL Energy Absorbing Y-Lanyard Model: EAL12NC-72Y-C13 WARNING: ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
- Page 2 Any references to “connecting subsystem” in this manual include, and apply to, the EAL12NC-72Y-C13 and all integral components. Any references to “anchorage connector” in this manual include, and apply to, the CBH013X.
-
Page 3: Key Components
COMPATIBILITY LIMITATIONS Connecting subsystem must only be coupled to compatible full body harnesses and anchorages. Compatibility must be determined by an engineer or other qualified person. OSHA 29 CFR 1926.502 prohibits snaphooks from being engaged to certain objects unless two requirements are met: it must be a locking type snaphook, and it must be “designed for” making such a connection. “Designed for”... - Page 4 Maximum Free Fall Average Arresting Force Maximum Deployment Distance 60” Forces may increase when cold and/or wet Read Instructions before Use Model: EAL12NC-72Y-C13 Length: 6ft Manufacture Date: MM/YYYY Capacity: 1 user (130-310 lbs.) Compliance: ANSI Z359.13, OSHA 1926.503 & 1910.140...
- Page 5 SERIOUS INJURY OR DEATH. PRODUCT IS DESIGNED TO DEFORM. ADD 6 IN (153 MM) TO FALL CLEARANCE CALCULATIONS. DO NOT USE IN TEMPERATURES BELOW -10 ºF (-23 ºC). Note: For markings of components not manufactured by ClimbTech, refer to manufacturer for proper marking information.
- Page 6 ANCHORAGE CONNECTOR CONNECTION INSTRUCTIONS 4” MAX 2.5” Ø MAX Safety Gate Hinge *Note: When closed and locked, safety must contact the gate hinge as shown. SCENARIO C SCENARIO D SCENARIO A SCENARIO B Inspect every connection. Ensure gate has closed and locked. Ensure dangerous loading conditions are not present and will not develop in the event of a fall.
- Page 7 TRANSVERSE LOADING Transverse/Side loading tested using ANSI Z359.12 fixturing in static and dynamic load conditions. Dynamic Testing performed according to ANSI Z359.18 Type A requirements. Minimum Static Breaking Strength: 3600-lbf. DANGEROUS LOADING CONDITIONS 12” Ø or Smaller Warning: This anchorage connector is designed to deform under fall arresting forces. Do not make connections that may allow the anchorage connector to disengage the anchorage when deformed.
-
Page 8: Maintenance, Cleaning And Storage
ENERGY ABSORBING LANYARD CONNECTION INSTRUCTIONS Connect the Dorsal D-Ring Connector directly to the Dorsal D-Ring of a compatible full body harness. This is the only permitted connection for the Dorsal D-Ring Connector. D-Ring extensions or other products that may increase the length of this connecting subsystem are strictly prohibited. -
Page 9: Inspection And Maintenance Log
INSPECTION GUIDELINES Official periodic inspection must be made at least semiannually. The inspection must be performed by a qualified person other than the intended user. If severe weather or conditions exist then inspections must be 1. Inspect webbing and stitching for damage due to cuts, abrasion, tears, excessive heat, chemical contact, excessive stretching, ultraviolet deterioration, rotting, mildew, and any other factors that may interfere with proper function of the connecting subsystem. - Page 10 CALCULATING FREE-FALL DISTANCE When calculating free-fall distance, the anchor height should be greater than the sum of energy abosrbing lanyard length, deceleration distance, worker height, and minimum fall clearance. Additionally, care must be taken to avoid collisions while falling obstacles, swing falls and additional hazards.
- Page 11 NOTES...
- Page 12 LIMITED REMEDY: Upon notice in writing, ClimbTech will repair or replace all defective items at ClimbTech’s sole discretion. ClimbTech reserves the right to require that the defective item be returned to its plant for inspection before determining the appropriate course action. Warranty does not cover equipment damage resulting from wear, abuse, damage in transit, failure to maintain the product or other damage beyond the control of ClimbTech.
