BANTAM BEAMER
ADJUSTABLE FROM 3.5"-14"
Model # BWA014K
WARNING:
ALL PERSONS USING THIS EQUIPMENT MUST
READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD
BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST
BE PROPERLY INSTRUCTED ON HOW TO USE THE DEVICE. AVOID
CONTACT WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL,
ELECTRICAL, ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
V1.1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ClimbTech BWA014K
Summary of Contents for ClimbTech BWA014K
- Page 1 BANTAM BEAMER ADJUSTABLE FROM 3.5”-14” Model # BWA014K WARNING: ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
- Page 2 PURPOSE The BWA014K is an anchorage connector designed to function as an interface between the anchorage and a fall protection, work positioning, rope access, or rescue system for the purpose of coupling the system to the anchorage. Any references to “anchorage connector”...
- Page 3 PERFORMANCE: REGULATORY COMPLIANCE: Static Tensile Strength: 5000-lbf (22kN) ANSI Z359.1-2007, ANSI Z359.7-2011, Maximum Capacity: One worker with OSHA 1926.502, OSHA 1910.66 max weight of 310-lbs (140 kg) when used EN 795:2012 Type B (CE 0321) as a single point anchorage connector for EU PPE Directive 89/686/EEC personal fall arrest or restraint system COMPONENT MATERIALS:...
- Page 4 LOADING CONDITIONS DIAGRAM Placement at or below a user’s working height requires integration of a compatible ANSI Z359.1 shock-absorbing lanyard that does not allow the user to extend more than 6 feet (in any direction) from the anchorage connector before the shock absorber is activated. The beam anchor must be attached to the I-beam flange facing the user (top flange if above, bottom flange if below, etc.).
- Page 5 *The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the arrest of a fall to a maximum of 8 kN (1800-lbf ). ( ANCHOR POINT ) WORK SURFACE Inspect retaining bushing for wear or damage.
- Page 6 WARNING LABEL LOCATIONS BREAKING STRENGTH: 5000 lbf (22.2 kN) MFG: MM/YYYY WARNING: All persons using this equipment must read, understand and follow all instructions. Failure to do so could result in serious injury or death. IB14K-XXX SN: XXXX:XXXX IB14K-XXX SN: XXXX:XXXX WARNING: It is essential to the safety of the end user that the seller of this device include all instructions pertaining to the proper use, maintenance and inspection of the device in the language of the country in which the product is to be sold.
- Page 7 MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. The frequency of cleaning should be determined by inspection and by severity of the environment. Clean with compressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product.
- Page 8 INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES INCLUDING, BUT NOT LIMITED TO LOSS OF PROFITS, IN ANY WAY RELATED TO THE PRODUCTS REGARDLESS OF THE LEGAL THEORY ASSERTED. Produced by: ClimbTech LLC. 7303 Burleson Rd STE 901 Austin, TX 78744 Notified Body responsible for the EC type examination...
