Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
These instructions contain important care, cleaning, and
warranty information -
please leave instructions for the
consumer
.
ORDERING INFORMATION
MODERN LIFE Class Five Two-Piece Toilet
305mm.................................................................K-77744T-SL
Includes Bowl .....................................................K-77728T
Includes Tank...........................................K-77742T-SLT3
Includes MODERN LIFE Slim Quiet-close
Toilet Seat............................................K-77380T
MODERN LIFE Class Five Two-Piece Toilet
400mm.................................................................K-77745T-SL
Includes Bowl .....................................................K-77729T
Includes Tank...........................................K-77742T-SLT4
Includes MODERN LIFE Slim Quiet-close
Toilet Seat............................................K-77380T
NOTES
·
Observe all local plumbing and building codes.
·
Shut off the water supply.
·
Seat post holes are on 140mm centers.
·
Ensure that the new drain has the correct roughing-in
dimension. This toilet has a 305/400mm roughing-in
dimension.
See Roughing-in
·
Closet flange must be 305/400mm on-center from wall.
·
Carefully inspect the new fixture for any sign of damage.
·
For new construction, refer to the dimensions in
installation step
for locating the shut-off valve.
·
Fixture dimensions are nominal and conform to tolerances
established by ASME Standards (A112.19.2-2013).
·
This product complies with GB25502-2017. Water
Efficiency Grade 1.
No.2 KOHLER ROAD, SANSHUI CENTRAL INDUSTRIAL PARK, LEPING TOWN, SANSHUI DIST., FOSHAN, GUANGDONG, PRC POST CODE 528137
8# MENGSHAN RD, ECONOMIC DEVELOPMENT ZONE OF HUANTAI, ZIBO, SHANDONG, CHINA POST CODE: 256410
1322809-T01-B
.
MODERN LIFE
SKIRTED CLASS FIVE TWO-PIECE TOILET
·
·
·
·
305mm.................................................................K-77744T-SL
.................................................................K-77728T
......................................................K-77742T-SLT3
......................................................K-77380T
400mm.................................................................K-77745T-SL
.................................................................K-77729T
......................................................K-77742T-SLT4
......................................................K-77380T
·
·
·
140mm
·
305/400mm(
·
·
·
·
2013)
·
GB25502-2017
2
528137
8
256410
©
Copyright Kohler China Investment Co., Ltd. 2018
-1-
©
INSTALLATION INSTRUCTIONS
S-TRAP 305mm K-77744T-SL
S-TRAP 400mm K-77745T-SL
)
305/400mm
ASME
(A112.19.2-
1
-
2018
Advertisement
Table of Contents
Related Manuals for Kohler MODERN LIFE K-77744T-SL
Summary of Contents for Kohler MODERN LIFE K-77744T-SL
- Page 1 This product complies with GB25502-2017. Water Efficiency Grade 1. No.2 KOHLER ROAD, SANSHUI CENTRAL INDUSTRIAL PARK, LEPING TOWN, SANSHUI DIST., FOSHAN, GUANGDONG, PRC POST CODE 528137 528137 8# MENGSHAN RD, ECONOMIC DEVELOPMENT ZONE OF HUANTAI, ZIBO, SHANDONG, CHINA POST CODE: 256410 256410 ©...
- Page 2 WARNING: Risk of personal injury or product damage : Handle vitreous china products very carefully. Vitreous china can break and chip if you overtighten bolts and nuts. WARNING: Risk of external leakage . The fill valve nut has been factory-tightened to design specifications. If re-tightening is required, wrench tighten one turn past finger tight .
- Page 3 Supply 390 424 OF OUTLET Fig.#1 Kohler reserves the right to change marked dimensions without prior notice. INSTALLATION TO REMOVE EXISTING TOILET Turn off the water supply. Flush the toilet, and use a sponge to remove the remaining water from the tank and bowl.
- Page 4 TO INSTALL BOWL Drain Hole Position the template and align with drain hole. Mark down the position of foot and 5 holes. Fig.#4 Drill holes on ground with the drill of 10mm 10mm (3/8"), then insert anchor to holes. CAUTION: Please make sure there is no water pipe or spool under the 5 10mm holes to be drilled.
- Page 5 Thread the supply hose onto the tank. Fig.#9 Slide the metal washer and the rubber washer onto the bolt. Metal Washer Fig.#10 Carefully align and lower the bowl. Apply weight to the bowl rim to let the outlet insert into plastic trap. Outlet Plastic Trap Fig.#11...
- Page 6 TO CONNECT WATER SUPPLY Supply Shank* * Flexible hose (not provided) are recommended to connect the supply Supply Shut-Off Valve line to the fill valve. If you use a rigid connection(not provided), take care not to apply side forces to the bottom of the fill valve.
- Page 7 A. Partially close the water supply shut-off valve if the water pressure to the toilet is too tank is filling. high. Check the toilet performance following any such adjustment. B. Remove dirt or obstructions from the valve head. Flush the lines. IMPORTANT: Use only genuine Kohler parts as shown to avoid property damage. 1322809-T01-B...
- Page 8 CAUTION: Don t use any cement while installing the toilet. Heat expansion of the toilet may damage the feet of the toilet. Kohler will not be responsible for any damage because of using cement. WARNING: Risk of product damage. Do not throw into the toilet what is easy to block it, such as newspaper, paper pilch, sanitary towel.
