Hama Aqua Jam - Mobile Speaker Manual

Technical Data

Frequency range:	20 Hz – 20 kHz
Output:	3 W
Battery type:	3.7 V / Li-Po / 300 mAh / 1.11 Wh
Charging voltage:	5 V 160 mA
Impedance:	4 Ω
Range:	< 10 m
Bluetooth® technology:	Bluetooth® v3.0, A2DP V1.2, AVRCP V1.0, HFP V1.5, GAVDP1.2, HSP1.2, IOP.

Controls and Displays

1. On/off button
2. LED indicator
3. Microphone
4. Micro-USB connection
5. Attachment eyelet for carabiner

Package Contents

• "Aqua Jam" Bluetooth® smartphone speakers
• 1x USB charging cable
• 1x flotation ring
• 1x carabiner
• These operating instructions

Safety Notes

• The product is intended for private, non-commercial use only.
• Do not use the product in the immediate vicinity of heaters or other heat sources or in direct sunlight.
• Do not use the product in areas where the use of electronic devices is not permitted.
• Since the battery is integrated and cannot be removed, you will need to dispose of the product as a whole. Do this in compliance with the legal requirements.
• Do not drop the product and do not expose it to any major shocks.
• Do not attempt to service or repair the product yourself. Leave any and all service work to qualified experts.
• Do not open the device or continue to operate it if it becomes damaged.
• Keep the packaging material out of the reach of children due to the risk of suffocation.
• Be considerate. Loud volumes can have a detrimental effect on your surroundings.
• Dispose of packaging material immediately according to locally applicable regulations.
• Do not modify the product in any way. Doing so voids the warranty.
• Keep this product, as all electrical products, out of the reach of children!
• Do not allow yourself to be distracted by the product, for example when driving a vehicle or operating sports equipment. Always pay attention to the surrounding traffic and your environment.
• Do not use the carabiner when climbing, to protect against falling or to secure people or objects.
• Use the flotation ring only for its intended purpose.

Getting Started and Operation

Turning on the product

• Press and hold the on/off button (1) for approx. 4 seconds to turn on the speaker.
• A signal tone confirms that the device is ready for operation. The LED indicator (2) flashes red and green alternately.

Turning off the product

• Press and hold the on/off button (1) for approx. 4 seconds to turn off the speaker.
• A signal tone confirms that the device is turning off. The LED indicator (2) flashes red before going out.

Note – Automatic power off

• Note that the speaker will automatically turn off after 10 minutes without action (no audio playback/no Bluetooth® function). The corresponding signal tone sounds.

Bluetooth^® pairing

Note

• Check whether your mobile device (MP3 player, mobile phone, etc.) is Bluetooth® capable.
• The functions described in this section are only available for Bluetooth® -capable terminal devices.
• Note that the maximum range for Bluetooth® is 10 metres without obstacles such as walls, people, etc.

Note – Bluetooth ® password
Some devices require a password to connect to another Bluetooth ® device.

• To connect to the loudspeaker, enter the password 0000 when prompted to enter from your terminal.

Note – Impaired connection
After a successful initial connection of the loudspeaker and the terminal, the connection is made automatically. If the Bluetooth ® connection does not recover automatically, check the following:

• In the Bluetooth ® settings of the terminal, check whether Hama Aqua Jam is connected. If not, repeat the steps under Bluetooth connection.
• Check that the equipment and the speakers are less than 10 meters apart. If not, reduce the distance of the devices.
• Check whether obstacles affect range. If so, position the devices closer together.

Automatic Bluetooth® connection (after successful pairing)

• Make sure that your Bluetooth ® -capable terminal device is on and Bluetooth ® is activated.
• Make sure that your Bluetooth ® -capable terminal device is visible for other Bluetooth ® devices.
• Make sure that the speaker is located within the Bluetooth ® range of max. 10 metres.
• Turn on the speaker as described in Turning on the product.
• A sound signals that the connection has been automatically established. The LED indicator (2) lights up steady green.
• Start and end audio playback on your terminal device.

Hands-free function

You can use the speaker as a hands-free set for your mobile phone. For this function, the mobile phone must be connected to the speaker via Bluetooth^®.

• Make sure that your mobile phone is connected to the Bluetooth ® speaker.
• If your mobile phone receives a call, press the on/off button (1) to accept it.
• Press the on/off button (1) again to end the call.

Note – Call quality

• To increase the call quality, make sure that you are near the speaker with your mobile phone during the call.

Battery charging function

Note

• During the charging process, do not under any circumstances expose the product to water.

Using the flotation ring

Note

• Carefully seal the Micro-USB port to make sure that the product is water-tight.
• Note that the presence of water may affect the range and tone of the speaker.

Care and Maintenance

• Make sure that water does not get into the product.
• Rinse off any saltwater residue with fresh water.
• Carefully dry the product after cleaning it or bringing it into contact with water.

Hama GmbH & Co KG
86652 Monheim / Germany
www.hama.com
