Connecting the printer Checking the printer voltage Connecting the mains power Connecting the interface cable Switching on the printer Control panel LED indicators Control panel keys Print quality key Print qualities 9 wire printer Print qualities 24 wire printer Character pitch key...
Page 4
Switching from single sheets to fanfold paper Setting the first printing line (TOF) Printing out a status page Example of a status page Specifications Printer specifications Paper specifications Consumables and accessories Consumables Accessories Interface Modules Quick start guide...
This quick start guide is intended as a quick introduction into working with manual the printer and also to enable inexperienced users to operate the device prop- erly. It describes the most important functions of the printer and contains the essential information for your everyday work with the printer.
Keep this Quick start guide in a place which is easily accessible at all times. Place the printer on a solid and even base so that it cannot fall down to the ground.
Windows Explorer and double click on the START.PDF file. Then follow the instructions and menus on the screen. The Online CD-ROM contains: User guide: A detailed description of the printer and its impressive features; Drivers: for Windows 95/98, Windows ME, Windows 2000, Windows XP, Windows 2003 Server Additional documentation If your CD-ROM is be defective or missing, please consult your dealer.
Printer components Cover Control panel Paper select lever Power inlet Single sheet feeder Tractor Platen knob Power Switch USB interface Parallel interface Printhead Ribbon cassette...
Make sure that the “Up” symbols point in the correct direction. Open the packaging, lift the printer out of the cardboard box and remove the remaining packaging material. Check the printer for any visible transport damage and missing items. The...
Placing the printer STOP Place the printer on a solid, flat, surface, ensuring that the printer is positioned in such a way that it can not topple, and that there is easy access to the control panel and paper input devices.
Setting up your printer Installation procedure 1. When the printer is first taken out of Tape the packaging box, the cover of the printer is taped as shown in the dia- gram. Remove the tape. 2. Open the cover of the printer and remove the shipping lock.
1. Remove the ribbon cassette from its packaging. 2. Open the printer cover. 3. Adjust the printhead to the center of the print roller. 4. Turn the tension knob A in the direc- tion of the arrow in order to take up slack of the ribbon.
Page 13
5. Insert the recess B on the bottom of the ribbon cassette into the holding 6. Push the cassette into its mounting until it clicks into position. 7. Close the cover of the printer. Installing the ribbon cassette of the mounting.
Europe, 120 V in the USA). To do this, check the type plate at the back of the printer. Contact your dealer if the setting is incorrect. Never switch on the printer if the voltage setting is incorrect, since this may result in severe damage.
Setting up your printer Switching on the printer Press the power switch located at the right side of the printer. The printer initializes. When the initialization is completed, the Power indicator tor (SEL) loaded, the Alarm indicator For more information on indicators, please refer to Chapter 5, “Control...
The control panel and the keys are used for controlling the printer operation. The control panel consists of nine keys for controlling the printer functions and four LEDs displaying the status of the printer. The function of the keys depends on the mode of the printer.
Control panel keys Status MENU On: the printer is in Menu mode. Refer to the User Guide on the CD-ROM for further informations on the menu mode. Off: the printer is in Normal mode. ALARM On: the printer is in a fault status or paper is missing.
Control panel Function PARK Transports continuous-form paper to the park position. Use this key if you want to switch to single sheet print without removing the continuous papier. QUIET Activates the Quiet mode which reduces the printing noise by decreasing the print speed. PRINT QUALITY Selects the print quality/font.
(TOF)” on page 27. 1 The printer must be in Offline mode. The printer can print with different print qualities and fonts. The actual selected print quality is displayed by its respective LED light. If you want to change the print quality setting, press the PRINT QUALITY key repeatedly until the desired print quality is set.
Control panel Print qualities 24 wire printer DRAFT COURIER OCR-B SANS SERIF OCR-A PRESTIGE PRINT QUALITY The following print qualities/fonts are available: High Speed Draft: prints with the highest print speed (480 cps at 10 cpi) but also lowest print quality.
PITCH key repeatedly until the desired character pitch is set. RESET CHARACTER PITCH The printer can print with 10, 12, 15, 17.1 or 20 characters per inch. If PROP (proportional spacing) is selected, only the actually required space for the character width is used.
Loading paper Your printer can process both fanfold paper and single sheets. For informa- tion on the supported paper sizes, please refer to the section “Paper specifications” on page 33.
Print gap lever The printer can handle paper with different thicknesses, including multipart forms with up to five parts (original plus four copies). For details on paper thickness specifications, please refer to the section “Paper specifications” on page 33. The print gap lever, located on the right under the cover, allows you to adjust for different paper thicknesses.
Paper handling Fanfold paper 1. Move the paper select lever for- ward to Continuous Paper posi- tion. 2. If necessary, readjust the print gap lever for continuous forms (see section “Print gap lever” on page 20). 3. Slightly press the single sheet feeder to the right or to the left, until the holding pin comes free from its recess.
Page 25
8. Reinstall the manual paper feeder. 9. Press the FF/LOAD key to advance the paper to the top-of- form position from which print- ing can start. The printer is auto- matically placed in the online state.
If the paper cannot be retracted in one operation, continue to press the PARK key until the paper is parked. The printer can retract continuous forms-paper by a recommended maximum of 30.48 cm (12 inches) per operation (one form length).
Single sheets 1. Tear off printed paper at its per- foration, if necessary. 2. Press the PARK key. The fanfold paper is transported backward to the park position. 3. Move the paper select lever back- ward to Single Sheet position. 4.
Paper handling Ejecting Single Sheets If you print using software which inserts a form feed at the end of each page, each sheet is ejected automatically upon the completion of the page printing. To manually eject sheets of paper: Press the FF/LOAD key to execute a forward form feed.
1. If a single sheet is loaded, press the FF/LOAD key. The sheet is ejeceted. 2. Move the paper select lever forward to continuous paper position. 3. Press the FF/LOAD key again. The printer feeds the fanfold paper to the top of form position.
1. Either transport fanfold paper to the next top of form position or feed an inserted single sheet by pressing the FF/LOAD key. 2. Make sure that the printer is in offline mode; press the SEL key, if necessary. 3. Hold the SHIFT key depressed and use the Micro Feed Down or Micro Feed Up keys to adjust the desired first printing line.
Printing out a status page The printer has a function that allows you to printout the current parameter settings. Proceed as follows, to printout the status page. 1. Make sure that paper is loaded (fanfold paper or single sheet). 2. Switch off the printer.
Page 34
Class B (J subpart of 15) Certi- fied, CE marking, EMC Immu- nity: IEC61000-4-2 level3, Energy Star For more information on printer specifications as well as interface specifications, refer to the User Guide on the Online CD-ROM. Wide model when idling 6 VA when idling 6.5 VA...
Specifications Paper specifications Only use paper that corresponds to the paper specifications and test new sorts of paper before use. Paper type Continuous Forms Width Length No. of copies Form thickness (max.) Single Sheets Width Length Thickness For more information on paper specifications, refer to the User Guide on the Online CD-ROM.
Consumables and accessories Consumables Accessories Interface Modules Only use ribbon cassettes from the manufacturer as products from other manufacturers may damage the printhead or the ribbon drive. Consumable Ribbon Cartridge, Monochrome Accessory Metal tear-off edge, narrow model Metal tear-off edge, wide model For more options, refer to the User Guide on the Online CD-ROM.
Page 37
“All rights reserved. Translations, reprinting or copying by any means of this manual complete or in part or in any different form requires our explicit approval. We reserve the right to make changes to this manual without notice. All care has been taken to ensure accuracy of information contained in this manual. However, we cannot accept responsibility for any errors or damages resulting from errors or inaccuracies of information herein.”...
