Adjusting the Projector's Focus / Zoom

To focus the image, rotate the focus ring or turn the focus lever
(for short-throw lens models) until the image is clear. You may
turn the zoom lever to zoom in or out.
For more information about the focus distance, please refer to
the table below:
Model Type/Name
XGA (IN134 model)
WXGA (IN136 model)
1080p (IN138HD/SP2080HD model)
XGA (IN134ST model)
WXGA (IN136ST model)
1080p (IN138HDST model)
XGA (IN2134 model)
WXGA (IN2136 model)
1080p (IN2138HD model)
Short-throw lens models
Installation
Focus Distance
1.2 to 12.02 meters
1 to 10 meters
1 to 7.5 meters
0.4 to 3.81 meters
0.4 to 3.4 meters
0.4 to 3.4 meters
1.2 to 9.02 meters
1 to 7.7 meters
1 to 7.5 meters
Zoom Lever
Focus Ring
Focus Lever
