- Page 1 N53AJ52 5MP Fixed Network Eyeball Camera Quick Installation Guide V1.0.1 Dahua Technology USA Inc.
-
Page 2: Foreword
General This manual offers reference material and general information about the basic operation, maintenance, and troubleshooting for a Dahua Camera. Read, follow, and retain the following safety instructions. Heed all warning on the unit and in the operating instructions before operating the unit. - Page 3 Please contact the customer service for the latest program and supplementary documentation. Video loss is inherent to all digital surveillance and recording devices; therefore Dahua cannot be held liable for any damage that results from missing video information. To minimize the occurrence of lost digital information, Dahua recommends multiple, redundant recording systems, and adoption of backup procedure for all data.
- Page 4 Legal Notices Copyright This user guide is ©2020, Dahua Technology USA Inc. This user guide is the intellectual property of Dahua Technology USA Inc. and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered...
-
Page 5: Important Safeguards And Warnings
Important Safeguards and Warnings This chapter describes the contents covering proper handling of the device, hazard prevention, and prevention of property damage. Read these contents carefully before using the device, comply with them when using, and keep it well for future reference. Installation and Maintenance Professionals Requirements All installation and maintenance professionals must have adequate qualifications or ... - Page 6 have the same characteristics as the original parts. Unauthorized parts may cause fire, electrical shock, or other hazards. Dahua is not liable for any damage or harm caused by unauthorized modifications or repairs. Perform safety checks after completion of service or repairs to the unit.
- Page 7 Contact the manufacturer or a qualified service representative to service the camera or to replace a component, including the desiccant. Dahua recommends the use of a thunder-proof device in concert with the unit. Do not touch the CCD or the CMOS optic sensor. Use a blower to clean dust or dirt on the ...
-
Page 8: Cybersecurity Recommendations
Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity Change Passwords and Use Strong Passwords The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible. - Page 9 Change ONVIF Password Older IP camera firmware does not automatically change the ONVIF password when the system credentials are changed. Update the camera’s firmware to the latest revision or manually change the ONVIF password. Forward Only Ports You Need ...
- Page 10 Connect IP Cameras to the PoE Ports on the Back of an NVR Cameras connected to the PoE ports on the back of an NVR are isolated from the outside world and cannot be accessed directly. Isolate NVR and IP Camera Network ...
-
Page 11: Table Of Contents
Table of Contents Foreword ............................... I Important Safeguards and Warnings....................IV Cybersecurity Recommendations ....................VII Table of Contents ..........................X 1 Overview ............................1 Parts List ..........................2 Dimensions..........................3 Cables and Connectors ......................4 2 Installing the Camera ........................5 Preparing for Installation ......................6 Unpacking .......................... -
Page 12: Overview
Starlight, True Wide Dynamic Range, and IR illumination allow the camera to operate in any lighting condition. The camera is a component of the Dahua ArcticPro series and is rated to IP67 allowing the camera to deliver high-quality and reliable video in the harshest... -
Page 13: Parts List
Parts List... -
Page 14: Dimensions
Dimensions... -
Page 15: Cables And Connectors
Cables and Connectors Cable type might vary with device. Waterproof all cable joints with insulating and waterproof tape to avoid short circuit and water damage. Ref. Port Name Connector Description Connect to standard Ethernet cable. Note: Certain devices support Power over Ethernet. Network Port RJ-45 Check the specific device to determine if the device... -
Page 16: Installing The Camera
Installing the Camera This section details installing the camera to a wall or to a ceiling. Note that the wall or ceiling must be capable of supporting a minimum of three times the weight of the camera and a bracket (if used). -
Page 17: Preparing For Installation
Note: Dahua recommends attaching a “drip loop” (flex or hard conduit) during installation to ensure condensation does not form in the mount or the conduit. -
Page 18: Unpacking
Unpacking This equipment should be unpacked and handled with care. If an item appears to have sustained damage during shipping, notify the shipper immediately. Verify that all the parts listed below are included. If an item is missing, contact customer support or your local representative. -
Page 19: Installing An Sd Card
Installing an SD Card Disconnect power to the camera. Remove the panel at the rear of the camera. Gently insert the SD card into the slot until it clicks in place. Replace the panel. Press the Reset button for 10 seconds to reset the device. -
Page 20: Using The Waterproof Ethernet Connector
Using the Waterproof Ethernet Connector Attach the waterproof network connector if the camera is used outdoors. Place the wide side of the rubber ring onto the end of the network cable extending out from the camera. Pull the waterproof cable end without the Ethernet connector through the body of the Waterproof Connector. -
Page 21: Mounting The Camera
Mounting the Camera Remove the camera, the mounting template, and the hardware package from the box. Apply the mounting template to the installation medium. Pre-drill the three (3) perimeter holes for the expansion bolts, using a drill bit that is no wider than the expansion bolt. Detach the camera body from the installation base. -
Page 22: Mounting To A Wall: Cables Through Camera Base Conduit
2.5.2 Mounting to a Wall: Cables through Camera Base Conduit... -
Page 23: Network Configuration
Network Configuration Initialize the device configure the IP setting with the Dahua ConfigTool or via the device’s web interface. Device initialization is available on select models, and it is required at first use and after device is being reset. -
Page 24: Initializing The Device
Initializing the Device Double-click the ConfigTool Icon on a PC to open the tool. Click the IP Icon. Click Search Setting. Enter the start IP and end IP of the network segment in which you want to search devices, and then click OK. All the devices found in the network segment are listed. Select one or several devices with status Uninitialized, and then click Initialize. -
Page 25: Modifying The Ip Address
Modifying the IP Address Modify the IP address of one or multiple devices at one time. This section provides instructions for modifying IP addresses in batch. Modifying IP addresses in batch is available only when the corresponding devices have ... -
Page 26: Connecting To The Dmss App
Connecting to the DMSS App Install the free mobile app on your smart phone: Apple App Store: iDMSS Google Play Store: gDMSS Tap the iDMSS or the gDMSS icon to open the app. Tap the Device icon at the bottom of the screen. Tap the “+”... - Page 27 Scan the QR code on the the back or bottom of the device. If the QR code does not work, tap Manually enter SN. Input the device for easy identification. It's required to input the password for the added device then select the save icon located on the top right corner.
- Page 28 Dahua Technology USA 23 Hubble Irvine, CA 92618 Tel: (949) 679-7777 Fax: (949) 679-5760 Support: 877-606-1590 Sales: sales.usa@dahuatech.com Support: support.usa@dahuatech.com © 2020 Dahua Technology USA. All rights reserved. Design and specifications are subject to change without notice.
