9. Auxiliary Positioning
10.2.2 Click the triangle symbol next to "Red Cross
Positioning Calibration" to enter the calibration page,
as shown in the following figure. Then, click the "Mark
Current Position" button again, and the laser will start
engraving the crosshair.

10. About

(1) Machine's effective size
(2) Screen version number, mainboard version number
10.2.3 Observe the error between the marked position
and the crosshair laser. If there is an error, proceed to
the next calibration step.
10.2.4 Click the up, down, left, and right buttons to the
position of the marked position (error value <1mm).
After calibration, click "Confirm".
X:365.0 , Y:305.0
control board:V1.055
Screen firmware:V1.055
12
