9. Auxiliary Positioning

9.1 Notes:
9.1.1 Auxiliary positioning can only be calibrated through the offline display screen or APP. It can only be used on the PC and
cannot be calibrated. For precise positioning, calibration must be performed through the display screen/APP first.
9.1.2 If the machine is not moved or the laser module is not disassembled, there is no need to repeat the positioning. If the laser
module is disassembled or the machine is moved, repositioning is required for accuracy.
9.1.3 When exporting a .gc file with Lightburn, the current position needs to be selected as the bottom left corner to ensure accu-
rate positioning.
9.1.3 Enabling this function provides 2 features:
a) Auxiliary material placement;
b) Positioning - when starting engraving, the laser will move to the crosshair position.
9.1.4 This function is disabled by default for the auxiliary positioning. A6 PRO does not have the auxiliary positioning function,
while other models have it.
9.2 How to Calibrate Auxiliary Positioning on the Display Screen:
9.2.1 Choose "Red Light Positioning" and the laser crosshair light will turn on.
