- Page 1 3K-ST INSTALLATION GUIDE VERSION NO: 1.0 DATE: OCTOBER 2023 MANUFACTURED BY:...
-
Page 2: Table Of Contents
SETTING UP ....................4 4.2.1 PREREQUISITES ................... 4 4.2.2 SITE SELECTION ................... 4 SAFETY PRECAUTIONS ......................5 CALORIMETER (3K-ST) ................. 5 FILLING STATION (3K-3) ................5 5.2.1 HIGH PRESSURE OXYGEN ..............6 VESSEL (3K-5S) ..................6 DAILY SAFETY STEPS ......................8 HARDWARE TEST ........................ -
Page 3: Introduction
Digital Data Systems (Pty) Ltd. CAL3K Advanced Bomb Calorimeters www.ddscalorimeters.com INTRODUCTION Digital Data Systems (Pty) Ltd (dds) specializes in the design and manufacture of scientific bomb calorimeter systems for various types of industries and applications from the coal mining industry to educational institutes. -
Page 4: System Components
Digital Data Systems (Pty) Ltd. CAL3K Advanced Bomb Calorimeters www.ddscalorimeters.com SYSTEM COMPONENTS THE CAL3K-ST SYSTEM CHECK LIST The system consists of the following: 3K-ST CAL3K-ST Calorimeter Received 3K-S-KT CAL3K-ST Calorimeter Installation Kit Included in Kit: Power Supply (12V) 3K-1-055 PC Keyboard (PS2) -
Page 5: Installation
Locate and tick-off the various system components as indicated on the CAL3K-ST Check List as per above. Unpack and inspect all the system components such as the 3K-ST Calorimeter, 3K-3 Filling Station and the 3K-5S Standard Vessels according to the instructions in the relevant sections in this document. -
Page 6: Setting Up
A mains outlet for the 3K-ST Calorimeter and a mains outlet power supplies. A supply of oxygen at a pressure of 3.0Mpa (30bars) (3000Kpa) within 4 meters of the 3K-ST Calorimeter. If bottled oxygen is used, a suitable high-pressure oxygen regulator must be supplied. -
Page 7: Safety Precautions
CAL3K Advanced Bomb Calorimeters www.ddscalorimeters.com SAFETY PRECAUTIONS CALORIMETER (3K-ST) • Connect the safety earth to the EARTH STUD on the back of the instrument. This is required when the external power supply fails • Do not open the CAL3K for any reason whatsoever! There are no serviceable parts inside the unit. -
Page 8: 5.2.1 High Pressure Oxygen
Digital Data Systems (Pty) Ltd. CAL3K Advanced Bomb Calorimeters www.ddscalorimeters.com NOTE: With some applications you may need to fill the Vessel to less than 3000KPA e.g. • 1500KPA (15 bar), however this is only applicable when you have a sample which is highly combustible, for example with wood related samples. - Page 9 Digital Data Systems (Pty) Ltd. CAL3K Advanced Bomb Calorimeters www.ddscalorimeters.com THE VESSEL MUST BE INSPECTED AT REGULAR INTERVALS DEPENDING ON THE USE. A SUITABLE INSPECTION PERIOD CAN BE SET (By your agent!) AND THE UNIT WILL ISSUE AN INSPECTION WARNING AND SOON AFTER THIS IT WILL SHUT-DOWN THE OPERATION. NOTE: THE MANUFACTURER (DDS) AND ITS AGENTS CANNOT BE HELD RESPONSIBLE FOR ANY LOSS OR DAMAGE RESULTING FROM NEGLIGENCE OR INCORRECT USE OF THEIR EQUIPMENT.
-
Page 10: Daily Safety Steps
Digital Data Systems (Pty) Ltd. CAL3K Advanced Bomb Calorimeters www.ddscalorimeters.com DAILY SAFETY STEPS The 4K-4 vessel is a high-pressure apparatus and should be treated with care. • Handle the vessel over a table or solid surface. • Do not drop a vessel. •... -
Page 11: Warranty - For New Products
Digital Data Systems (Pty) Ltd. CAL3K Advanced Bomb Calorimeters www.ddscalorimeters.com WARRANTY – FOR NEW PRODUCTS PURPOSE OF PRODUCT WARRANTY Any part of a product is subject to ageing and eventual failure. These failures occur during normal use. The purpose of a warranty is to protect the Owner against a part failure caused by manufacturing defects in workmanship, material, or design for a specific time. -
Page 12: Warranty - Repaired Products
Digital Data Systems (Pty) Ltd. CAL3K Advanced Bomb Calorimeters www.ddscalorimeters.com WARRANTY – REPAIRED PRODUCTS Any “dds” scientific product that has been repaired has a warranty period of 30 Days from date of shipment for the Repair request only. If something else goes wrong that is not part of the original Repair, the warranty does not apply. -
Page 13: Warranty Registration Form
Digital Data Systems (Pty) Ltd. CAL3K Advanced Bomb Calorimeters www.ddscalorimeters.com WARRANTY REGISTRATION FORM SERIAL NUMBERS (S/N): Calorimeter: _____________________________ Filling Station: _____________________________ Vessel(s): _____________________________ Other: _____________________________ DEALER NAME: _____________________________________________________________ OWNER’S/CUSTOMER’S COMPANY NAME: _______________________________________ AUTHORISED BY: _____________________________________________________________ INSTALLED AT: _____________________________________________________________ TEL NO: ____________________________ FAX NO: ______________________________...
