- Page 1 SPARTAN Getting Started Edition 11 - 2022-07-08 imc SPARTAN-4-N © 2022 imc Test & Measurement GmbH imc Test & Measurement GmbH • Voltastr. 5 • 13355 Berlin • Germany...
- Page 2 "Products\imc DEVICES\OSS" or "Products\imc DEVICEcore\OSS". If you wish to receive a copy of the GPL sources used, please contact our Hotline. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 2...
-
Page 3: Table Of Contents
6.4.1 Display ................................36 6.4.2 GPS ................................... 36 6.5 Pin configuration of the fieldbusses .................... 37 6.5.1 CAN-Bus, CAN FD (DSUB-9) ..........................37 © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 3... - Page 4 6.5.5 ARINC-Bus (DSUB-15) ............................40 6.5.6 PROFIBUS (DSUB-9) ............................41 6.5.7 MVB-Bus (DSUB-9) ............................41 6.6 REMOTE plug ..........................44 Index .......................... 45 © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 4...
-
Page 5: General Introduction
Please note that all properties described refer to a closed measurement system and not to its individual slices. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 5... - Page 6 Products not satisfying these requirements may only be used with special approval of the regulating body in the country where operated. All lines connected to imc SPARTAN devices should not be longer than 30 m and they should be shielded and the shielding must be grounded.
- Page 7 The FCC requires the user to be notified that any changes or modifications made to this product that are not expressly approved by imc may void the user's authority to operate this equipment. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 7...
-
Page 8: Notes Regarding This Document
What additions and enhancements you suggest? · Where have material mistakes slipped in? · Which spelling, translation or typing errors have you found? © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 8... -
Page 9: Explanation Of Symbols
(This is guaranteed by the absence of named substances). Observe the documentation Read the documentation before starting work and/or operating. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 9... -
Page 10: Last Changes In Content
Amendments and bug-fix in Edition 8 Chapter Amendment Temperature ACC/DSUBM-T4 schematic added measurement IEPE/ICP plug improved description for the software and plug recognition © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 10... -
Page 11: Safety
The user must also ensure that any personnel assisting in the use of the imc SPARTAN device have also read and understood the content of this document. - Page 12 "Electric Installations and Industrial Equipment" (DGUV Regulation 3)*. This confirmation applies exclusively to devices of the imc SPARTAN series, but not to all other components included in the scope of delivery.
- Page 13 Before touching the device sockets and the lines connected to them, make sure static electricity is diverted to ground. Damage arising from electrostatic discharge is not covered by the warranty. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 13...
-
Page 14: Assembly And Connection
Basically, reliability decreases when operating under extreme conditions (forced ageing). The operating temperature data represent the extreme limits at which the function of all components can still be guaranteed. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 14... -
Page 15: Notes On Connecting
Particular care should be taken to comply with the storage device's max. ambient temperature limitation. 5. Avoid prolonged exposure of the device to sunlight. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 15... -
Page 16: Power Supply
In order to comply with Part 15 of the FCC-regulations applicable to devices of Class B, the system must be grounded. Grounding is also the condition for the validity of the technical specifications stated. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 16... - Page 17 3.3.3.2 Grounding with power supplied by a car battery imc SPARTAN system with isolated from the housing (CHASSIS)) input with isolated DC-supply (e.g. battery) If the power supply (e.g. car battery) and the measurement device are at different voltage levels, then if they were connected by the supply line, it would cause a ground loop.
-
Page 18: Potential Difference With Synchronized Devices
This process takes up to 10 s. Holding the power-on button down is not necessary. If no measurement is currently running, it takes only approx. one second for the device to be deactivated. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 18... -
Page 19: Remote Control
Chapter 3 3.3.8 Remote control imc SPARTAN measurement devices can be switched on and off remotely, by control signals that are accessible at the device's "REMOTE" terminal. These can be operated by externally installed manual switches, relay contacts or electronic switching elements. -
Page 20: Rechargeable Accumulators And Batteries
3.3.10 Rechargeable accumulators and batteries imc SPARTAN devices contain maintenance-free lead-gel batteries. Charging these batteries is accomplished automatically when the activated device receives a supply voltage. Due to the inevitable leakage of charge we recommend that the device be activated for 6 to 9 hours at least every 3 months to prevent the batteries from dying. -
Page 21: Signal Connection
5. The lid screws can be tightened Reference Pin configuration Please find the pin configuration of each available plug in the chapter: Pin configuration © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 21... -
Page 22: Maintenance And Servicing
Be certain that the ventilation slits remain unobstructed. 4.3 Storage As a rule, the measurement device must be stored in a temperature range of -40°C to +85°C. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 22... -
Page 23: Transport
Note however that the form and the format are accurately given by IATA and the expression has to take place in color. Format: 120 x 110 mm. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 23... -
Page 24: Start Of Operation Software / Firmware
Under some circumstances, this may require using switches to subdivide the network into separate segments in order to govern the data traffic in a targeted way and thus optimize the data rate. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 24... -
Page 25: Connecting Via Lan In Three Steps
Subsequently, a prompt appears asking whether to search for devices with an inappropriately configured network interface. Close this message box by clicking "Yes". © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 25... - Page 26 DHCP, the alternative values are used. These could lead to errors in the connection (different networks, same IP-addresses, etc.). © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 26...
- Page 27 Now check whether the correct time zone is set for the device. For more info, see the description of the software manual under the keyword "Device properties". © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 27...
-
Page 28: Firmware Update
Device operating system Online Online-functions and hard drive controller Display Operating system of the connected displays Fieldbus Fieldbus interfaces (e.g. CAN etc.) Signal conditioners Amplifiers © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 28... - Page 29 You are notified when the firmware setup concludes successfully, as shown below: Conclusion of the firmware update (example of a single device) Choose "Close". The device can now be used with the product software. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 29...
- Page 30 You can call the Firmware-Update dialog manually. Ribbon View Setup-Configuration > Updating Firmware Complete The function is only to be used in compliance with instructions from the imc-Hotline. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 30...
-
Page 31: Pin Configuration
Chapter 6 6 Pin configuration © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 31... -
Page 32: Connecting Dsub-15 Adaptor Plug
Cable shielding must be connected at CHASSIS (DSUB frame) as a rule. At some plugs, (5 V) is available, with a maximum load current of typically 135 mA per plug. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 32... -
Page 33: Dsub-15 Pin Configuration
LEVEL OPDRN CHASSIS CHASSIS CHASSIS CHASSIS CHASSIS CHASSIS CHASSIS CHASSIS * if special version with ±15 V option, then this pin is reference © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 33... -
Page 34: Special Plug
(2) if special version with ±15 V option, then this pin 6 is the reference [ ] : 1/4 Bridge with B16 and +SENSE with BCF16 © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 34... -
Page 35: Dsub-26 Pin Configuration (High Density)
-VB2 +SUPPLY1 +VB1 -SUPPLY1 -VB1 +IN1 +IN1 For contact with the chassis use -IN1 -IN1 the screw of the strain relief. [+SENSE1_1/4B1] -SENSE1 © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 35... -
Page 36: Dsub-9 Pin Configuration
2x Black 2x Black PPS (1 Hz clock) Yellow Yellow Pin configuration at measurement device. At the GPS-mouse Rx and Tx are interchanged. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 36... -
Page 37: Pin Configuration Of The Fieldbusses
CANSAS modules. On the other hand, it is not always possible to protect against very fast increasing currents, such as a hard short-circuit on the cable, safely and quickly enough! © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 37... - Page 38 (housing, power supply, system electronics). CAN_GND should always be used independently of the power supply so that the CAN_H and CAN_L levels are reliably detected. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 38...
-
Page 39: Lin-Bus (Dsub-9)
BP channel A (positive bus line channel A) BP channel B (positive bus line channel B) 6.5.4 XCPoE (RJ45) Standard Ethernet 1x RJ45. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 39... -
Page 40: Arinc-Bus (Dsub-15)
7B Tx4B sending channel 4B Rx8A receiving channel 8A Rx8A receiving channel 8A Rx8B receiving channel 8B Rx8B receiving channel 8B © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 40... -
Page 41: Profibus (Dsub-9)
Terminator A internal jumper to 1 Terminator A interna jumper to 2 Terminator B interna jumper to 4 Terminator B interna jumper to 5 © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 41... - Page 42 Ground A B.Bus_GND Ground B A.Bus_5V 5V Supply A B.Bus_5V 5V Supply B Rm = 143 Ω; Ru = Rd = 383 Ω © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 42...
- Page 43 Pin configuration of the fieldbusses Chapter 6 DSUB connection for ESD © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 43...
-
Page 44: Remote Plug
RESET_ reference for MUTE and RESET CHASSIS Reference Please find here the description of the REMOTE control. © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 44... -
Page 45: Index
Firmware update Display Logbook DSUB-26-HD FLEXRAY pin configuration Remote fuses: overview pin configuration ARINC-Bus pin configuration CAN-Bus pin configuration FLEXRAY General terms and conditions © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 45... - Page 46 16, 18 Software installation Special hazards System requirements Telephone numbers: Hotline uninterruptible power supply Warranty WEEE Restriction of Hazardous Substances XCPoE pin configuration © 2022 imc Test & Measurement GmbH imc SPARTAN - Getting Started, Edition 11 - 2022-07-08 Page 46...
