- Page 1 MTP-NT Manual Edition 2 - 2023-11-09 © 2023 imc Test & Measurement GmbH imc Test & Measurement GmbH • Voltastr. 5 • 13355 Berlin • Germany...
- Page 2 Monitor installation medium in the folder "Products\imc DEVICES\OSS" or "Products\imc DEVICEcore\OSS" or "Products\imc STUDIO\OSS". If you wish to receive a copy of the GPL sources used, please contact our Hotline. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 2...
- Page 3 Notes denote useful additional information on a A reference in this document is a reference in particular topic. the text to another text passage. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 3...
-
Page 4: Table Of Contents
8.2 HF-Tx - Radio transmitter incl. antenna (rotor side) ..............56 8.3 Installation of the radio transmitter on a shaft ................57 8.4 Position of receiving standard magnetic foot antennas .............. 58 © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 4... - Page 5 9 Inductive transmission .................... 59 9.1 Inductive Pick-up head ......................... 60 9.2 IND-PICKUP-HEAD 45 MHz ......................61 9.3 Inductive powering ........................65 Index .......................... 91 © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 5...
-
Page 6: General Notes
· inappropriate use of the equipment. Please note that all properties described refer to a closed measurement system and not to its individual slices. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 6... - Page 7 Unauthorized intervention in the device renders the guarantee null and void. Notes on radio interference suppression The imc MTP-NT telemetry system satisfy the EMC requirements for an use in industrial settings. Any additional products connected to the product must satisfy the EMC requirements as specified by the responsible authority (within Europe ) in Germany the BNetzA - "Bundesnetzagentur"...
- Page 8 The FCC requires the user to be notified that any changes or modifications made to this product that are not expressly approved by imc may void the user's authority to operate this equipment. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 8...
-
Page 9: Explanation Of Symbols
The device itself does not generate dangerous voltages. DC, Direct Current Supply of the device via a DC voltage source (in the specified voltage range) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 9... -
Page 10: Document History
Please check the device for mechanical damage and/ or loose parts after unpacking it. The supplier must be notified immediately of any transportation damage. Do not operate a damaged device. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 10... -
Page 11: Safety
Work which may only be performed by trained imc personnel may not be performed by the user. Any exceptions are subject to prior consultation with the manufacturer and are conditional on having obtained corresponding training. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 11... - Page 12 (§ 5 Sec. 1, 4 of DGUV Regulation 3). This does not affect guarantee and liability regulations of the civil code. previously BGV A3. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 12...
- Page 13 Before touching the device sockets and the lines connected to them, make sure static electricity is diverted to ground. Damage arising from electrostatic discharge is not covered by the warranty. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 13...
-
Page 14: Start Of Operation
In case of connection problems, you should check the Device Manager to see if the COM port used is available. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 14... -
Page 15: Nt Configuration Software
Please download the configuration software file ntconfiginstaller.exe from the imc web page: https://www.imc-tm.com/download-center/product-downloads/mtp-nt/software/ Reference Please find a detailed description of the configuration software in the chapter: "TBD". © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 15... -
Page 16: Mtp-Nt Description
Ø Ø Signal bandwidth, see chap. signal bandwidth Signal bandwidth, see chap. signal bandwidth Ø Ø ADC Resolution 18 bit ADC Resolution 18 bit © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 16... - Page 17 Power supply: 6 to 9 V DC Ø Current consumption: 100 mA * Required is the KMT COMMUNICATOR handheld remote control Blue- tooth device with USB connector) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 17...
-
Page 18: Table 1: Common Specifications Of Mtp-Nt Modules
10000 g peak (11 ms) Storage temperature -40 to +125°C Static Acceleration 3000 g (depends of Humidity 100 % mounting!) Table 1: Common specifications of MTP-NT modules © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 18... - Page 19 MTP-NT modules Chapter 4 4.1.1 Pin configuration © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 19...
- Page 20 MTP-NT modules Chapter 4 © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 20...
- Page 21 MTP-NT modules Chapter 4 4.1.2 Housing dimensions and weight of the modules © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 21...
- Page 22 MTP-NT modules Chapter 4 4.1.3 Mounting plates for MTP-NT modules © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 22...
- Page 23 MTP-NT modules Chapter 4 Mounting plates example for shaft diameters 100-200 or 150-250 mm © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 23...
-
Page 24: Signal Bandwidth And Sampling Rates
The resolution of the A/D converter and the data handling within the NT module system is 18 bits. · The PCM data stream is currently 16 bit wide. 4.3 Connection cables 4.3.1 MTP-NT-BUS-C (-L/-M/-S) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 24... - Page 25 Signal cable 220 mm with open ends (2x 2-pin, VOLT or IEPE) MTP-NT-C-In-2x2 Cut the cables to your required length. 4.3.3 Data cable Data coil cable 500 mm with open ends, shielded MTP-NT-C-D-COIL-500 © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 25...
- Page 26 4.3.5 RS 232 RS 232 Connection cable (1 m) to RS232/USB RS232/USB adaptor adaptor MTP-NT-Config-C Hinweis The USB adaptor ist not compatible with Windows 11. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 26...
-
Page 27: Mtp-Nt Bus Connection
MTP-NT Bus connection Chapter 4 4.4 MTP-NT Bus connection © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 27... - Page 28 IN means: bus cable is coming from the direction of the controller. OUT means: bus cable goes in the direction of the other modules. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 28...
- Page 29 MTP-NT Bus connection Chapter 4 connection scheme 4 channel version © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 29...
-
Page 30: Block Diagram
MTP-NT Bus connection Chapter 4 4.5 Block diagram © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 30... - Page 31 Block diagram Chapter 4 Installation on a shaft © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 31...
-
Page 32: Settings Of Parameters Of Mtp-Nt-Controller
Settings of parameters of MTP-NT-Controller Chapter 4 4.6 Settings of parameters of MTP-NT-Controller © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 32... -
Page 33: Wireless Solutions
Ø Range 5 to 20 m Ø Power supply: 6 to 9 V DC Ø Current consumption: 37 mA (average) standby mode: 15 mA (average) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 33... - Page 34 4.7.1 KMT Communicator Device for a wireless configuration of a remote MTP-NT system via USB to the Bluetooth module MTP-NT-BLUE (incl. wireless firmware update) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 34...
-
Page 35: Daisy-Chain Connection (Bus Cable)
Easy to connect - with the same MTP-NT-BUS-C cable The bus is expandable to several meters. AMP "Locking-Clip" crimp connectors withstand ultra-harsh vibration and shock environment. Caution: Locking-Clip must be completely connected! © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 35... -
Page 36: Decoder
5.1 Analog Decoder: MTP-NT-DEC8CH/16CH, 24CH, 32CH Receiver unit for max. 32 channels; output via DSUB-37 Inductive transmission 45 MHz version up to 5000 Mbit (10000 Mbit on special request) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 36... -
Page 37: Table 3: Technical Specs: Mtp-Nt-Dec8Ch/16Ch, 24Ch, 32Ch
+80% not condensing at +20°C Vibration Static acceleration 10 g in all directions Shock 100 g in all directions Table 3: Technical Specs: MTP-NT-DEC8CH/16CH, 24CH, 32CH © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 37... -
Page 38: Digital Decoder: Mtp-Nt-Dig-Dec-V2
+80% not condensing at +20°C Vibration Static acceleration 10 g in all directions Shock 100 g in all directions Table 4: Technical Specs: MTP-NT-DIG-DEC-V2 © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 38... - Page 39 * This means the mathematically generated output resolution after linearization; the true ADC resolution depends on sensor type and temperature range and may be significantly lower. © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 39...
- Page 40 163.52 (example: 1 V analog output voltage multiplied by 163.52 gives the reading 163.52 degrees Celsius). © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 40...
-
Page 41: Measurement Types
ADC Resolution 18 bit · Measurement uncertainty <0.1% · Gain uncertainty <0.1% · Power supply: 6 to 9 V DC · Current consumption (with full bridge 350 Ω) 90 mA © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 41... - Page 42 MTP-NT-STG2 - measuring bridges Chapter 6 Full bridge (120 Ω or 350 Ω) Half bridge 350 Ω 120 Ω © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 42...
- Page 43 MTP-NT-STG2 - measuring bridges Chapter 6 Quarter bridge 350 Ω 120 Ω © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 43...
-
Page 44: Mtp-Nt-Analog2
· sensor supply (12 V / 30 mA typ.) · Power supply: 6 to 9 V DC · Current consumption: 120 to 160 mA © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 44... -
Page 45: Mtp-Nt-Iepe2 Connection Options For Sensors
ADC Resolution 18 bit · Measurement uncertainty <0.1% · Gain uncertainty <0.1% · Power supply: 6 to 9 V DC · Current consumption 140 mA IEPE/ICP input © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 45... -
Page 46: Mtp-Nt-Volt2 - Mesauring Voltages
+4 V sensor excitation max. 20 mA · ADC Resolution 18 bit · Measurement uncertainty <0.1% · Power supply: 6 to 9 V DC · Current consumption 80 mA Voltage input © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 46... -
Page 47: Mtp-Nt-Pot2
ADC Resolution: 18 bit · Measurement uncertainty < 0.1% · Power supply: 6 to 9 V DC · Current consumption: 90 mA (with two 1 kΩ potentiometers) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 47... -
Page 48: Mtp-Nt-Xvdt2
Signal bandwidth 0 Hz to 200 Hz · Programmable lowpass filter · Power supply: 6 to 9 V DC · Current consumption: 130 mA (with 2x MHR500) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 48... -
Page 49: Mtp-Nt-Thermo2
Output resolution 0.05K/step (20 steps/Kelvin) Measurement uncertainty ≤ 1 K Sensor break detection message = "-999.0°C" Unreasonable value message = "-998.0°C" Table 5: MTP-NT-THERMO2 Specifications © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 49... - Page 50 MTP-NT-THERMO2 Chapter 6 © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 50...
-
Page 51: Mtp-Nt-Con-Ind-Tx (Controller Connection)
· Output: PCM IND-Transmitter included · Programmable via RS232/USB adapter and remote software · Power supply: 6 to 9 V DC · Current consumption 150 mA © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 51... -
Page 52: Mtp-Nt Ind Pwr 6V (Power Module Connection)
· Vibration: 5 g · Shock: 3000 g Warning Don't power ON without connected Analog modules like MTP-NT-STG, ICP. Otherwise you can damage it!! © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 52... -
Page 53: Mtp-Nt Mounting
Mounting of second pick up at flat coil on shaft Chapter 7 7 MTP-NT mounting 7.1 Mounting of second pick up at flat coil on shaft © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 53... -
Page 54: Mounting Of Second Pick Up At Coil Ring
Mounting of second pick up at coil ring Chapter 7 7.2 Mounting of second pick up at coil ring © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 54... -
Page 55: Radio Transmission
Operating -20°C to 70°C Humidity 20 to 80% not condensing Vibration Static acceleration 10 g in all directions Shock 100 g in all directions © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 55... -
Page 56: Hf-Tx - Radio Transmitter Incl. Antenna (Rotor Side)
Consumption of current: 70 mA · Powering: 5 V DC (powering comes via MTP-Controller) · Vibration: 5 g · Static acceleration: 3000 g · Shock: 10000 g · Water non-protected © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 56... -
Page 57: Installation Of The Radio Transmitter On A Shaft
Installation of the radio transmitter on a shaft Chapter 8 8.3 Installation of the radio transmitter on a shaft © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 57... -
Page 58: Position Of Receiving Standard Magnetic Foot Antennas
Position of receiving standard magnetic foot antennas Chapter 8 8.4 Position of receiving standard magnetic foot antennas © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 58... -
Page 59: Inductive Transmission
Twist also the flexible wire and solder it on the MTP-NT the inflexible 1 mm wire, at 0.63 not necessary) IND-Tx (isolate all solder points with shrink tubing) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 59... -
Page 60: Inductive Pick-Up Head
If you want to install also an inductive power coil close to the data coil, the minimal distance must be >2 mm! (distance between IND-DATA coil to IND-POWER coil) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 60... -
Page 61: Ind-Pickup-Head 45 Mhz
IND-PICKUP-HEAD 45 MHz Chapter 9 9.2 IND-PICKUP-HEAD 45 MHz IND-PICKUP-HEAD 45 MHz - cable rear side (radial to shaft) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 61... - Page 62 IND-PICKUP-HEAD 45 MHz Chapter 9 IND-PICKUP-HEAD 45 MHz - cable right side (axial to shaft) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 62...
- Page 63 IND-PICKUP-HEAD 45 MHz Chapter 9 9.2.1 Dimensions IND-PICKUP-HEAD 45MHz - cable rear side (radial to shaft) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 63...
- Page 64 IND-PICKUP-HEAD 45 MHz Chapter 9 IND-PICKUP-HEAD 45MHz – cable right side (axial to shaft) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 64...
-
Page 65: Inductive Powering
Inductive powering Chapter 9 9.3 Inductive powering Inductive power supply set Picture shows standard inductive power supply for diameter up to 300 mm © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 65... - Page 66 Make power coil with 3-18 windings for 1000-20 mm diameter (see diagram) and twisted the end of wire. Use 0.63…1.00 mm (1.00 mm for diameter of 100-1000 mm) CUL wire (Enameled copper wire) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 66...
- Page 67 The distance is optimal in the range between 5 and 10mm. (depends of shaft and current consumption) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 67...
-
Page 68: Table 6: Optimum Windings For Steel Shafts
(mm) 250 nF 1000 150 nF 150 nF 150 nF 150 nF 150 nF 150 nF 150 nF 150 nF 150 nF 150 nF © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 68... - Page 69 9.3.3 Power head selection – depends on diameter (table) Recommended power heads: Diameter 150 mm 300 mm 500 mm 1000 mm 4-Channel 8-Channel 16-Channel 32-Channel IND-PWR-HEAD-XL and XXL IND-PWR-HEAD-XXXL(old version) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 69...
- Page 70 Cable must be unrolled for use, otherwise it will warm up! 9.3.4 Dimensions of inductive Power head 9.3.4.1 Power head XL and XXL Dimensions of IND-PWR-HEAD-XL and XXL © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 70...
- Page 71 Inductive powering Chapter 9 9.3.4.2 Power head XXXL (old version) IND-PWR-HEAD-XXXL © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 71...
- Page 72 Inductive powering Chapter 9 9.3.4.3 Power head 3XL (new version) IND-PWR-HEAD-3XL © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 72...
- Page 73 Inductive powering Chapter 9 9.3.4.4 Power head 4XL (new version) IND-PWR-HEAD-4XL © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 73...
- Page 74 Inductive powering Chapter 9 9.3.4.5 Mounting Power head © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 74...
- Page 75 Inductive powering Chapter 9 9.3.5 Power head with slot 9.3.5.1 Dimensions of power head XXL with slot © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 75...
- Page 76 Inductive powering Chapter 9 Inductive Power head XXL Coil distances © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 76...
- Page 77 9.3.5.2 Caution for use of XXL power heads with slot Warning Caution for use of power heads! Cable must be unrolled before use, otherwise they will warm up! © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 77...
- Page 78 Inductive powering Chapter 9 9.3.5.3 Dimensions of inductive power head XXXL with slot © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 78...
- Page 79 9.3.5.4 Caution for use of XXXL power heads with slot Warning Caution for use of power heads! Cable must be unrolled before use, otherwise they will warm up! © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 79...
-
Page 80: Table 7: Inductive Power Generator Specifications
20 to 80% not condensing Vibration Static acceleration 10 g in all directions Shock 100 g in all directions Table 7: Inductive power generator specifications © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 80... - Page 81 Inductive powering Chapter 9 9.3.6.2 Dimensions of IND-Power generator for L, XL and 2XL © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 81...
- Page 82 Inductive powering Chapter 9 9.3.6.3 Dimensions of IND-Power generator for 3XL and 4XL © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 82...
- Page 83 9.3.6.4 Pin connection of IND-Power generator CONTROL - not used DC 10 to 30 V AC 25 to 35 kHz output typ. 24 V, 5 A power head © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 83...
- Page 84 Inductive powering Chapter 9 9.3.7 Inductive power with RING COIL © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 84...
- Page 85 Data cable CAT. 7A S/FTP 4P AWG22 (= solid bare copper wire 0.64 mm-diameter) recommend Data cable CAT. 7 S/FTP 4P AWG23 (= solid bare copper wire 0.55 mm-diameter) © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 85...
- Page 86 Inductive powering Chapter 9 9.3.7.2 Uncouple the 45MHz frequency to reach better transmitting range © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 86...
- Page 87 Inductive powering Chapter 9 9.3.7.3 Wire connection © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 87...
- Page 88 Inductive powering Chapter 9 9.3.7.4 Distance from coil to power head © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 88...
- Page 89 Inductive powering Chapter 9 9.3.7.5 Example of a Ring Coil diameter © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 89...
- Page 90 Table 4: Technical Specs: MTP-NT-DIG-DEC-V2 ........................38 Table 5: MTP-NT-THERMO2 Specifications ........................49 Table 6: Optimum windings for steel shafts ........................68 Table 7: Inductive power generator specifications ......................80 © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 90...
-
Page 91: Index
Power head XXXL Caution dimension IEPE IND-PWR-HEAD-XL IND-PWR-HEAD-XXL Quality Management IND-PWR-HEAD-XXXL Inductive powering Diameter Radio transmission Installation of components Restriction of Hazardous Substances Magnetic field RoHS © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 91... - Page 92 Inductive power generator L Inductive power generator XL Telephone numbers: Hotline Warranty Waste on Electric and Electronic Equipment WEEE Restriction of Hazardous Substances Weight Wireless © 2023 imc Test & Measurement GmbH imc MTP-NT - Manual, Edition 2 - 2023-11-09 Page 92...
