Operation
TexSprayt 1030 FC
0.9 to 3.0 gpm (3.4 to 11.4 lpm) Flow Rate
Model 234113, Series A
TexSpray 1030 FC sprayer, TexSpray gun
and 50 ft (15 m) air and fluid hose set
Contents:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
Copyright 2002, Graco Inc. is registered to I.S. EN ISO 9001
TI3005
Read warnings and instructions.
3
. . . . . . .
309662
4
7
12
. . . . . . .
309661
12
309663
Rev. A

Advertisement

loading
Need help?

Need help?

Do you have a question about the 234113 and is the answer not in the manual?

Questions and answers

Related Manuals for Graco 234113

Summary of Contents for Graco 234113

  • Page 1: Table Of Contents

    ......GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441 Copyright 2002, Graco Inc. is registered to I.S. EN ISO 9001...
  • Page 2 ADVERTÊNCIA WARNING Perigo de incêndio e explosão: os solventes e os vapores da pintura Fire and explosion hazard: Solvent and paint fumes can ignite or poderão explodir ou incendiar. explode. Para ajudar a evitar incêndio e explosão: To help prevent a fire and explosion: DUtilize unicamente em áreas extremamente bem ventiladas.

  • Page 3: Controls

    CONTROLS On/Off Switch Engine Controls Air Regulator TI3036A TI3037A Smart Control TI3038A TI3039A Digital Display TI3005 TI3040A Flow Control Prime Valve TI3041A TI3042A 309663...

  • Page 4: Setup

    Setup Connect Graco material hose (A) to sprayer. Tighten securely. TI3045A TI3044A Connect other end of hose to gun. Tighten securely. TI3046A TI3047A Connect Graco air hose (B) to sprayer. Tighten securely. TI3048A TI3049A Connect other end of air hose to spray gun.
  • Page 5 Connect suction hose (D) to pump. Connect drain hose (E) to drain valve. TI3053A Install clean inlet strainer. TI3054A Fill throat packing nut with TSL to prevent premature packing wear. Do this each time you spray and store. Approximate Fill Level TI3055A Check engine oil level.
  • Page 6 WARNING MISE EN GARDE Fill fuel tank. ADVERTENCIA ADVERTÊNCIA TI3057A WARNING MISE EN GARDE Attach sprayer grounding ADVERTENCIA ADVERTÊNCIA clamp to earth ground. TI3058A Air Cap and Nozzle Changes See Manual 309661 for information on how to make air cap and nozzle changes to 245872 TexSpray Gun. 309663...

  • Page 7: Startup

    Startup Place suction tube and drain tube in grounded metal container partially filled with flushing fluid. Attach ground wire to container and to earth ground. FLUSH TI3059A Turn flow control to OFF. TI3060A Turn spray gun air control valve (F) in fully, in clockwise (cw) direction (stops air flow out of nozzle).
  • Page 8 Start engine Move fuel valve to open Move choke to closed Set throttle to fast Set engine switch ON Pull starter cord After engine starts, move choke to open Set throttle to desired setting 309663...
  • Page 9 Turn flow control to PRIME. Allow fluid to flow constantly. TI3069A Turn flow control to LOW/MED/HIGH. TI3073A Trigger gun into waste container. When flushing material appears, direct fluid into flushing container. FLUSH TI3070A Inspect fittings for leaks. Do not stop leaks with your hand or a rag! If leaks occur, WARNING MISE EN GARDE ADVERTENCIA...
  • Page 10 Set compressor air ON. Adjust spray gun air control valve (F) and flow control LOW/MED/HIGH for desired pattern. TI3073A TI3075A When finished spraying, release trigger and turn flow control OFF. Turn engine OFF. TI3076A 309663...
  • Page 11 View Fluid or Air Pressure Sprayer displays air pressure at startup, designated as A at left side of display. Press display button and F appears with fluid pressure displayed in psi. Press display button again and A appears with air pressure displayed in psi.

  • Page 12: Cleanup

    Cleanup WARNING MISE EN GARDE Pressure Relief ADVERTENCIA ADVERTÊNCIA Turn flow control OFF. Turn engine OFF. Pressure Relief WARNING MISE EN GARDE ADVERTENCIA ADVERTÊNCIA Pressure is relieved by prime valve every time gun trigger is released. Material is flushed to container by drain tube. MATERIAL TI3071A Start engine (page 8).
  • Page 13 Release spray gun trigger. Turn flow control to PRIME. Circulate flushing fluid until pump suction hose and drain hose are clean. Direct gun into flushing container and turn flow control to LOW/MED/HIGH and continue to flush until pump and line are clear.
  • Page 14 Graco distributor to the original purchaser for use. With the exception of any special extended or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
