Instruction Manual Lateral Mounting Type OCA-S300BC OCA-S300BCS OCA-S600BC OCA-S1000BC OCA-S1600BC Caution Please read this brochure carefully before use and keep at hand for future reference. ≪Contents≫ 1. Safety Precautions ・・・・・・・・・・・・・・・・・・・・・・・・・ 2. Mounting ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3. Wiring ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 9-14 4. Operation ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 5.
1. Safety precautions - This product is an industrial cooling unit for control panel. Do not use this for any other purposes. - Be sure to read these precautions carefully before starting operation for proper use. - All the warnings and cautions described herein must be observed in order to use the product safely. The marks and their meanings shown in this manual are as follows.
2. Mounting 2-1 Caution Danger For prevention of electrical shock, power supply to the control panel should be disconnected before installation work. Caution For installation, do not use any parts other than originally supplied ones. Failure to this may result in injury or breakdown of the cooling unit. In case screws are used for installation instead of the original bolts, put a plate between the screw and the cap nut so as the direct torque not to be transmitted.
Page 28
2-2 Mounting procedure A. External mounting (1) Process the mounting surface to cut out the openings in accordance with the respective mounting cutout drawings in Page 5. (2) Fit the enclosed bolts to the unit. The number of bolts differs depending on the model. (3) Attach the enclosed packing on the rear side of the unit.
Page 29
Caution OCA-S1000BC and Nut for eyebolt OCA-S1600BC has two nuts on top installation for installation of eyebolts. Please lift up evenly using eyebolts whenever lifting up a cooling unit. Lifting up one side only may result in breakdown or damage of the product.
Page 30
Cutouts for Embedded Mounting OCA-S300BC OCA-S300BCS OCA-S600BC OCA-S1000BC OCA-S1600BC ●Arrangement of packing (Ex. OCA-S600BC) Arrangement for external mounting Arrangement for embedded mounting Packing (shaded area) Packing (shaded area)
Page 31
2-3 Attachment of drain hose Moisture arisen from dehumidification by COOLCABI is discharged through a drain hose. Pay attention to the following notices in order to attach the drain hose properly. Caution If the drain hose is not attached properly, water collected in the drain pan inside the COOLCABI may overflow into the control panel interior.
3. Wiring Caution - Please observe all the local regulations in installation of the cooler. - Supply voltage should be as specified on the rating plate. - Allowable power fluctuation is +/- 10% from the rated voltage. Pay attention the maximum fluctuation should be stayed within this range.
3-3 Overcurrent protection Caution Do not forget to fit an earth leakage breaker. → Failure to this may lead to tripping of the earth-leakage breaker for the enclosure in the event of electric leakage. Selection of a breaker should be made so as to fit the type of the cooler. Earth leakage Breaker a.
Page 34
4-5 Parameter setting Normally, there is no need to change the setting of the parameters. If necessary, follow the procedures described below. Push the SET button for more than 3 seconds in a status that the internal temperature is indicated. The parameters are indicated in the following order.
Page 35
- Setting assignment of alarm output terminals Initial setting: 0 Setting range : 0-3 Alarm output terminals output once an alarm is detected. This is to assign the terminals for each alarm. 0 : Monitoring of alarm outputs 1 : Monitoring of cooling operation and alarm outputs 2 : Monitoring of need for power shutdown and restoration in the event of alarm output 3 : Monitoring of continued operation when an alarm occurs...
Page 36
Assignment table of Alarm output terminals [Ao:0] Terminals 1-2 Terminals 2-3 Operation behavior State of Operation behavior State of Description Description of cooling unit contact of cooling unit contact Contact changes Contact changes Alarm OFF CLOSE Alarm OFF OPEN over by the state of over by the state of Alarm ON OPEN...
Page 37
4-7 Operation mode setting Following to power connetion, COOLCABI starts operation in the each setting mode. Factory setting for the setting temperature is 35℃ with 5℃ differential, which means the compressor starts for cooling when the temperature inside the enclosure reached 35℃and stops at 30℃.Four operation modes of continuous run and three different energy saving mode are available.
Page 38
(3)Energy-saving mode 2 The internal fan runs in conjunction with cooling operation. Effective for energy saving when cooling operation is stopped under a low temperature like winter season. The values in the ( ) show the default setting. Setting temperature (35℃) Differential temp.
5. Alarm/Safeguard 5-1 Alarm (1) E1:High Temp. Alarm When the internal temperature reaches 45 ℃ (factory setting), the alarm output terminals will break and make contact as set in AS and Ao to light alarm lamp (See the assignment table of alarm output terminals in page 12). The display shows the current internal temperature and E1 by turns to indicate that the internal temperature is too high.
6. Maintenance Caution Be sure to disconnect power before carrying out any maintenance work. Use the specified filter for replacement. Use of fine filters will cause efficiency loss in heat releasing which leads to reduced cooling performance and/or breakdown of the unit. Cleaning and user maintenance shall not be made by children.
Page 41
◎Replacement fan Model Applicable COOLCABI models Internal fan External fan OCA-S300BC-A200 FM-300BCIN-200V FM-300BCOUT-200V OCA-S300BCS-A200 FM-300BCSIN-200V FM-300BCSOUT-200V OCA-S600BC-A200 FM-600BCIN-200V FM-600BCOUT-200V OCA-S1000BC-A200 FM-1000BCIN-200V FM-1000BCOUT-200V OCA-S1600BC-A200 FM-1600BCIN-200V FM-1600BCOUT-200V OCA-S300BC-A100 FM-300BCIN-100V FM-300BCOUT-100V OCA-S600BC-A100 FM-600BCIN-100V FM-600BCOUT-100V OCA-S1000BC-A100 FM-1000BCIN-100V FM-1000BCOUT-100V OCA-S1600BC-A100 FM-1600BCIN-100V FM-1600BCOUT-100V 6-4 Troubleshooting Failure Cause Remedy - Internal...
Page 45
7-3 Outline drawing OCA-S300BC Adjustable louver <Front view> <Side view> <Rear view> Operation panel Cool air Terminal Air from Warm air board Inside(*) Air from Air from inside outside Cool air(*) 4-M6 Depth 14mm External air inlet filter (White) For fixing bolt <Bottom view>...
Page 46
OCA-S600BC Adjustable louver <Front view> <Side view> <Rear view> Operation panel Cool air Terminal Warm air Air from board Inside(*) Air from Air from inside outside Cool air(*) External air inlet filter (White) 4-M6 Depth 14mm For fixing bolt <Bottom view> Drain pipe(Outer dia.φ12) OCA-S1000BC <...
Page 47
OCA-S1600BC < Top view > 2-M8 Depth 13mm For eyebolt Adjustable louver <Front view> <Side view> <Rear view> Operation panel Cool air Terminal Air from Warm air board Inside(*) Air from Air from outside inside Cool air(*) External air inlet filter (White) 6-M6 Depth 14mm <Bottom view>...
8. Warranty period This product is covered with 1-year warranty from the date of shipment, provided that such warranty does not apply to damages malfunctions resulted from other than normal use. 9. Waste disposal This products uses chlorofluorocarbon (HFC) as a refrigerant which requires special handling for its disposal.
