GWTR493-1316
334
328
VORSICHT
Connection to power supply should be carried out only by a qualified technician
and according to both IEC 60364 and national regulations in force!
CAUTION
NOTICE: Technical changes and errors reserved! Latest status at www.pelipal.com
21.05.2014
HUEVO
drilling point for screw hooks, dimensions for mounting and drain
Waschtischbreite 1316
632
660
These instructions are intended to prevent personal injury or property damage.
We will not be held responsible in case of disregard.
GWTR493-1316
334
328
HUEVO
www.pelipal.com
