- Page 1 INSTRUCTION MANUAL FOR ENGLISH LINDR CONTACT DRY COOLER Number 004-2019 REV01 Valid 2020-02-06 KCH 01582 Kontakt 70-K-us Green Line...
- Page 2 + 420 778 070 276 tel. : +420 495 447 239 e-mail: info@lindr.cz web: www.lindr.cz, www.lindr.eu This manual contains instructions for installing, using and operating the machine. This manual is an integral part of the machine. It must be stored at the equipment for the life of the equipment and provided to the user whenever it is installed, moved, used, or maintained.
-
Page 3: Table Of Contents
Contents: …............... Introduction …............... Description of the cooler …............... Product label General instructions, measures …............... and safety instructions …............... Installation and placement …............... Electrical connection …............... Testing …............... Warranty …............... Description of the cooler …............... 10 10. Package contents …............... 11 11. - Page 4 Symbols and Markings Used in the Manual WARNING: Not following instructions may cause injury or damage the device. WARNING: Risk of injury by electrical current. NOTE: This symbol indicates information and recommendations for users. WARNING: cooling system contains flammable coolant R290 (propane)!
-
Page 5: Introduction
Time needed to accumulate energy is ca. 10 min. Lindr cooling technology has 45 % higher output than is its input energy. The... -
Page 6: General Instructions, Measures And Safety Instructions
WARNING: Cleaning 4. General Instructions, maintenance of the appliance on Measures and Safety the part of the user must not be done Instructions by unsupervised children. WARNING: Before connecting to When using the device, follow basic main electrical supply, check that the safety instructions stated... -
Page 7: Installation And Placement
WARNING: When unplugging WARNING: After unpacking, the device from the socket, grab place the cooler so that heat created the plug and pull it out. Do not under by the cooling unit can be vented any circumstances pull at the cable; sufficiently. -
Page 8: Electrical Connection
WARNING: The cooler must be 8. Warranty placed indoors (in a roofed area) on a The device comes with a warranty in dry, level, stable surface. accordance with general legal regulations of the Czech Republic or in WARNING: Protect the cooler accordance with the trade agreement. -
Page 9: Description Of The Cooler
9. Description of the cooler : Kontakt 70-K-us Green Line 1 Cooler handle 7 Air compressor switch 2 Tap 8 Air outlet (5/16" speed fitting) 3 Thermostat 9 Beverage outlet (3/8" speed fitting) 4 Drip tray 10 Product label 5 Condenser vent grid... -
Page 10: Package Contents
10. Package Contents The package contains: 1. Tap 2. Tap wrench 3. Drip tray and sieve... -
Page 11: Tap Installation
11. Tap Installation Fit the tap perpendicularly onto the spline coupler. Secure with a flare nut and turn to the left. (loosen to the right). Tighten with the enclosed wrench. ˇ... -
Page 12: Keg Coupler Assembly
12. Keg Coupler Assembly 12.1 Outlet for keg pressurisation: Connection variant with bushing: hose is fitted onto the bushing and affixed with a clip. Connection variant with rapid coupling: Screw an F 5/8“ x 5/16“ (8 mm) rapid coupling onto the keg coupler... - Page 13 WARNING: Before you screw the rapid coupling onto the 5/8“ thread, make sure the keg coupler (air inlet for delivery medium) has a non-return valve fitted on it. ˇ...
- Page 14 12.2 Outlet for beverage: Screw an F 5/8“ x 3/8“ (9.5 mm) speed fitting onto the keg coupler...
-
Page 15: Beverage Supply Connection And Pressurisation
13. Beverage Supply Connection and Pressurisation Connect the cooling device to the keg coupler by plugging a 3/8“ beverage hose into the speed fitting located on the rear of the cooler marked inlet 1, inlet 2. Connect the cooling device to the keg coupler by plugging a 5/16“... -
Page 17: Inlet And Outlet Marking
14. Inlet and Outlet Marking Tap – outlet 2 Tap – outlet 1 ˇ... -
Page 18: Keg Tapping And Untapping
15. Keg Tapping and Untapping WARNING: Make sure the adapter is clean before tapping the keg! S system keg coupler Procedure for tapping and untapping a keg with an S system keg coupler: 1. Keg tapping:... - Page 19 ˇ...
- Page 20 2. Keg untapping:...
- Page 21 A system keg coupler: ˇ...
- Page 22 Procedure for tapping and untapping a keg with an A system keg coupler: 1. Keg tapping:...
- Page 23 2. Keg untapping: ˇ...
-
Page 24: Putting Into Operation
16. Putting into Operation 1. Connect air supply and beverage supply according to point 13. 2. Set the thermostat to 0 position. 3. Connect the cooler to the power mains. 4. Tap the keg in accordance with point 15. 5. Turn the air compressor on using the switch and pressurise it to the required pressure of 1.0-3.4 bar (in models with built-in compressor, pressure is automatically set to 2.8-3.4 bar). -
Page 25: Thermostat Placement
17. Thermostat Placement Mechanical thermostat with 1 – 7 numerical scale located on the front of the cooler. 18. Temperature and Adjustment The temperature of the cooled beverage is controlled by a mechanical thermostat in temperature range of 2 °C to 8 °C. -
Page 26: Built-In Air Compressor
19. Built-in Air Compressor The air mini-compressor is built into the cooling device itself. The compressor can be turned off separately with a switch. Air pressure is controlled automatically in 2.8 – 3.4 bar range. The air outlet from the cooler terminates in a 5/16“ (8 mm) rapid coupling marked AIR. -
Page 27: Environmental Protection
21. Environmental Protection Waste Sorting This product must not be disposed of in communal waste. Electrical waste in Czech Republic disposed within Rema System (www.remasystem.cz), tel.: +420 225 988 001(002). In countries other than the Czech Republic, waste sorting is subject to local regulations Sorted waste enables recycling and reusing used products and packaging materials. -
Page 28: Periodic Checks
24. Periodic Checks • 1x a week: check that the lead-in cable is undamaged and that the plug is firmly in the socket. • 1x a week: check that the device is not exposed to radiant heat. • 1x a week: check that air circulation is not obstructed. •... -
Page 29: Sanitation By Water
26. Sanitation by Water (Sanitation Adapter) Connect the sanitation adapter (not included) to water mains using a hose. WARNING! Maximum water temperature must not exceed 25 °C. NOTE: Sanitation adapter is not included. Can be purchased as an accessory for the cooler. -
Page 31: Table Of Defects
27. Table of Defects DEFECT CAUSE REMOVAL beverage does keg tapped incorrectly check that the keg coupler lever is not flow pushed down device with built-in compressor - turn on the switch water from sanitation turn off the device; then you have to froze wait until the beverage starts flowing again (may take a few minutes, or... -
Page 32: Spare Parts
Do not forget to specify the following: • type of defect • type of product • production year • product's serial number (found on the label) Ordering components: ALWAYS USE ORIGINAL COMPONENTS. The manufacturer or supplier bear no responsibility for non-original components or components not recommended by the manufacturer. -
Page 33: Wiring Diagram
30. Wiring Diagram ˇ... -
Page 34: Cooling Diagram
31. Cooling Diagram... - Page 35 ˇ...
